PC, HDMI, DISPLAY PORT INTERFACE CONTROLLER
CONTENTS
Page: 2. Introduction, How to Proceed, Usage Note, Disclaimer
3. System design – Diagram of a suggested system
4. Assembly notes – Important information about system elements
6. Connection & Operation – How to use the controller
10. Connectors, pinouts & jumpers – Essential connection information
19. Controller dimensions
20. Application notes
22. Troubleshooting
23. Specifications
24. Appendix I – Mode Support Table
26. Appendix II – RS-232 control protocols
30. Appendix III – DDC/CI support at ARGB, HDMI & Display port
31. Appendix IV – Mapping definition
33. Appendix V – Auto Color Gain
34. Appendix VI – DV remote control unit work for ALR-1920
35. Warranty, Caution & Limitation of Liability, Trademarks
36. Contact details
It is essential that these instructions are read and understood before connecting or
powering up this controller.
FOR TFT PANEL
Model: ALR-1920
Part number : 41727001X/2X-3 or up
INSTRUCTIONS
Document version release 29 Mar 2016
