Bison NVH-150-T Operator's Manual

Read blades
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
R E A R
R E A R
BLADES
BLADES
NVH-150-T
NVH-180-T
NVH-210-T
NVH-240-T
O P E R A T O R ' S
M A N U A L
...harvesting better implements!
4350-2113-00 (Rev. 09/06/04)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NVH-150-T and is the answer not in the manual?

Questions and answers

Related Manuals for Bison NVH-150-T

Summary of Contents for Bison NVH-150-T

  • Page 1 R E A R R E A R O P E R A T O R ’ S BLADES BLADES M A N U A L NVH-150-T NVH-180-T NVH-210-T NVH-240-T ...harvesting better implements! 4350-2113-00 (Rev. 09/06/04)
  • Page 2 Use only genuine BISON service parts. Substitute parts will void the warranty and may not meet standards required for safe and satisfactory operation. Record the model number and serial number of your equipment in the spaces...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION GENERAL INFORMATION SPECIFICATIONS SAFETY RULES SAFETY & INSTRUCTIONAL DECALS OPERATION OWNER SERVICE ASSEMBLY PARTS INDEX BOLT TORQUE CHART BOLT SIZE CHART & ABBREVIATIONS WARRANTY GENERAL INFORMATION The purpose of this manual is to assist you in oper- The illustrations and data used in this manual were ating and maintaining your rear blade.

  • Page 4: Specifications

    NVH-150-T / NVH-180-T / NVH-210-T / NVH-240-T SPECIFICATIONS Models NVH-150-T NVH-180-T NVH-210-T NVH-240-T Features & Specifications Angle, tilt, & offset Manually Manually Manually Manually adjusted angle, adjusted angle, adjusted angle, adjusted angle, tilt and offset tilt and offset tilt and offset...

  • Page 5: Safety Rules

    SAFETY RULES ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! PREPARATION Safety is a primary concern in the design and manufacture of our products. Unfortunately, our Check that all hardware is properly installed. efforts to provide safe equipment can be wiped Always tighten to torque chart specifications unless instructed otherwise in this manual.
  • Page 6 SAFETY RULES ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! (Safety Rules continued from previous page) Before working underneath, read manual instructions, securely block up, and check stability. Always comply with all state and local lighting and Secure blocking prevents equipment from dropping marking requirements.

  • Page 7: Safety & Instructional Decals

    SAFETY & INSTRUCTIONAL DECALS ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! RB082 1 - Serial Number Plate (1) MODELO / MODEL NUMERO DE SERIE / SERIAL NUMBER www.bison.com.mx ® HECHO EN MEXICO TECNOMEC AGRICOLA Safety Decals...
  • Page 8 4 feet left of center of the tractor when driving on public roads. 6.- TA4310-6020-01 Red Reflector 2’’ x 9’’ (2) 7.- TA4310-6020-02 Yellow Reflector 2’’ x 9’’ (1) 8.- TA4310-1102-03 BISON decal (1) 9.- Model decal (1) Safety Decals 4350-2113-00 (Rev. 09/06/04)

  • Page 9: Operation

    OPERATION WARNING Safety is a primary concern in the design and manufacture of our products. Unfortunately, our efforts to provide safe equipment can be wiped out by an operator’s single careless act. A minimum 20% of tractor and equipment weight must be on the tractor front wheels when In addition to the design and configuration of attachments are in transport position.
  • Page 10 Operation Cont´d MOUNT REAR BLADE TO TRACTOR IMPORTANT The rear blade should be mounted on tractors with a maximum power rating of 65 hp (48 kW). For 4WD tractors, the maximum power rating is 60 hp (45 kW). The rear blade is a 3-point Category 1 implement. It will attach to ASAE standard Category 1 quick-attaching coupler.
  • Page 11 Operation Cont´d CAUTION CAUTION Before changing positions of manual swing, Always secure lock pins with safety pins to tilt, or angle positions: prevent lock pins from bumping out of the • Park tractor on level ground, apply parking positioning holes. Failure to do so may result in brake, level implement boom, shut off tractor, accidents and/or damage to rear blade.
  • Page 12 Operation Cont´d Reverse Blade The blade is reversible without removing it from the tractor. Mechanical Adjustment 1. Remove turn table pin (7) and safety pin (24). 2. Rotate moldboard counter-clockwise 180 degrees (viewed from the top). 3. Insert the turn table pin (7) using the various hole combinations between the offset plate assembly and the turn table holes to achieve angle positions up to 53 degrees each side.
  • Page 13 Operation Cont´d Offset Adjustment Mechanical Adjustment Mechanical adjustment model has five blade offset positions. Hole position combinations between the offset plate assembly (3) and the moldboard (4) allow moldboard to offset to the right or left with a maximum blade offset of 12 inches to either side.
  • Page 14 Operation Cont´d OPERATING TIPS WARNING CAUTION Look down and to the rear and make sure area Stop power unit and equipment immediately is clear before operating in reverse. upon striking an obstruction. Turn off engine, remove key, inspect, and repair any damage Do not operate on steep slopes.

  • Page 15: Owner Service

    OWNER SERVICE WARNING Safety is a primary concern in the design and manufacture of our products. Unfortunately, our efforts to provide safe equipment can be wiped Before dismounting power unit or performing out by an operator’s single careless act. any service or maintenance, follow these steps: disengage power to equipment, lower the 3-point In addition to the design and configuration of hitch and all raised components to the ground,...
  • Page 16 Owner Service Cont´d Blade Cutting Edge To reverse the cutting edge 1. Remove the 5/8 plow bolts. 2. Remove the cutting edge from the moldboard and reinstall with the sharp edge down. 3. Replace cutting edge when both edges are worn. Lubrication Monthly 1.

  • Page 17: Assembly

    Assembly of this equipment is the responsibility of the BISON dealer. It should be delivered to the owner Keep all persons away from operator control completely assembled, lubricated, and adjusted for area while performing adjustments, service, or normal operating conditions.
  • Page 18 Assembly Cont´d MAIN ASSEMBLY These instructions illustrate the sequence of assembling the parts of the rear blade. We suggest that you follow this sequence carefully. Assembly of the rear blade should be done with no less than two people and the appropriate equipment for making assembling easier.
  • Page 19 Assembly Cont´d Remove Parts from Crate NOTE: The shipping crate base can be used to aid in the assembly of the rear blade. 1. Remove top and sides from crate. 2. Remove box of parts and mechanical linkages from base. RB089 Attach Main Frame to Turn Table and King Pin A.
  • Page 20 Assembly Cont´d Assembly Cont´d Attach Turn Table to Moldboard C. Secure king pin (10) to the moldboard (4) by using the king pin cap (21) and castle nut (22). Secure using cotter pin (16). NOTE: Remove paint from the moldboard (4) hole where the king pin (10) goes through if necessary.
  • Page 21 Assembly Cont´d Attach Parking Stand Attach parking stand (31) to the main frame (1) and insert the parking stand pin (32) through the hole of the parking stand (31). Use safety pin (24) to secure parking stand (31) in position. Main Frame Safety Pin, 1/8 Parking Stand...
  • Page 22 Assembly Cont´d 3-Point Hitch Mast and Main Frame Pin Installation G. Insert the two lower hitch pins (5) through the main frame (1) ear holes and secure using lock washers (11), and hex nuts (12). Place the klik pins (17) into the lower hitch pins (5).
  • Page 23 Assembly Cont´d END PLATES C6200001 ASSEMBLY (OPTIONAL) A. Attach rear blade to tractor. D. Assemble the end plates (1) to the moldboard using bolts (3), spacers (2), hex nuts (4), and lock B. Raise the blade a few inches off the ground by washers (5) making sure the holes of the end plate operating the lift control lever of the tractor.
  • Page 24 Assembly Cont´d Assembly Cont´d Assembly Cont´d SKID SHOES C6100001 ASSEMBLY (OPTIONAL) A. Attach rear blade to tractor and level the main F. Insert the skid shoe parking stands (2) through the frame. skid shoes (1) and stack the fifteen flat washers (3) on top of each skid shoe parking stand (2) and secure B.
  • Page 25 Assembly Cont´d PRE-DELIVERY CHECK LIST DELIVERY CHECK LIST (DEALER’S RESPONSIBILITY) (DEALER’S RESPONSIBILITY) Inspect the equipment thoroughly after assembly to Show customer how to make adjustments. ensure it is set up properly before delivering it to the customer. Point out the safety decals. Explain their meaning and the need to keep them in place and in The following check lists are a reminder of points to good condition.
  • Page 26 NOTES Notes 4350-2113-00 (Rev. 09/06/04)
  • Page 27 NOTES Notes 4350-2113-00 (Rev. 09/06/04)

  • Page 28: Parts Index

    PARTS INDEX ...harvesting better implements! REAR BLADES REAR BLADES NVH-150-T NVH-210-T NVH-180-T NVH-240-T NVH-150/180/210/240-T MAIN ASSEMBLY MAIN ASSEMBLY PARTS LIST END PLATES C6200001 ASSEMBLY (OPTIONAL) SKID SHOES C6100001 ASSEMBLY (OPTIONAL) Parts 4350-2113-00 (Rev. 09/06/04)
  • Page 29 NVH-150-T / NVH-180-T / NVH-210-T / NVH-240-T MAIN ASSEMBLY 34,35,36 34,35,36 DECAL SET, SAFETY NVH-150/180/210/240-T DECAL SET, COMPLETE NVH-150/180/210/240-T OPERATOR´S MANUAL NVH-150/180/210/240-T 26,27 RB081 Parts 4350-2113-00 (Rev. 09/06/04)
  • Page 30 TACN06010016K DECAL SET, COMPLETE NVH-150/180/210/240-T TACN06010017K OPERATOR'S MANUAL NVH-150/180/210/240-T † 7 FOR NVH-150-T, 8 FOR NVH-180-T, 9 FOR NVH-210-T, 10 FOR NVH-240-T †† 11 FOR NVH-150-T, 12 FOR NVH-180-T, 13 FOR NVH-210-T, 14 FOR NVH-240-T Standard Hardware; Obtain Locally Parts...
  • Page 31 END PLATES C6200001 ASSEMBLY (OPTIONAL) RB341 PART DESCRIPTION END PLATE SPACER BOLT, 5/8 x 3 1/2 HHCS GR5 HEX NUT, 5/8 - 11 LOCK WASHER, 5/8 LEFT BRACE BOLT, 5/8 x 1 1/2 HHCS GR5 RIGHT BRACE Standard Hardware; Obtain Locally Not Serviced Separately Parts 4350-2113-00 (Rev.
  • Page 32 SKID SHOES C6100001 ASSEMBLY (OPTIONAL) RB342 PART DESCRIPTION SKID SHOE TACN99030200W SKID SHOE PARKING STAND FLAT WASHER, 1 KLIK PIN, 3/8 PLOW BOLT, 5/8 x 2 1/2 GR5 HEX NUT, 5/8 - 11 LOCK WASHER, 5/8 Standard Hardware; Obtain Locally Not Serviced Separately Parts 4350-2113-00 (Rev.

  • Page 33: Bolt Torque Chart

    BOLT TORQUE CHART Always tighten hardware to these values unless a different torque value or tightening procedure is listed for a specific application. Fasteners must always be replaced with the same grade as specified in the manual parts list. Always use the proper tool for tightening hardware: SAE for SAE hardware and Metric for metric hardware. Make sure fastener threads are clean and you start thread engagement properly.
  • Page 34 BOLT SIZE CHART NOTE: Chart shows bolt thread sizes and corresponding head (wrench) sizes for standard SAE metric bolts. SAE Bolt Thread Sizes 5/16 IN IN Metric Bolt Thread Sizes 10MM 12MM 14MM 16MM 18MM ABBREVIATIONS Agriculture National Coarse Automatic Transmission Fluid National Fine BSPP British Standard Pipe Parallel...

  • Page 35: Warranty

    Under these warranties, TECNOMEC will repair or replace, at its discretion, any covered part which is found to be defective in material or workmanship during the applicable warranty term. Warranty service must be performed by an authorized BISON dealer, which will use only new or remanufactured parts or components furnished by TECNOMEC.
  • Page 36 PART NO. 4350-2113-00 ...harvesting better implements! 2004 Tecnomec Agrícola, S.A. de C.V. All rights reserved...
