- Page 1 Mira Sport Max with Airboost 9.0 and 10.8 kW For SPARES, ADVICE or REPAIRS please call us free on 0800 001 4040 (UK only) Installation and User Guide These instructions must be left with the user 1493936-W2-A...
-
Page 2: Important Safety Information
Important Safety Information WARNING - This shower can deliver scalding temperatures, cause fire, electric shock or other personal injury if not operated, or maintained in accordance with the instructions, warnings and cautions contained in this guide and on the appliance. Please read the important safety information and the operation section of this guide before using the shower. - Page 3 9. Installation of the shower must be carried out in accordance with these instructions by qualified, competent personnel. Read all instructions before installing the shower. 10. DO NOT switch the shower on if water starts leaking from the shower case. Isolate the electrical supply to the shower immediately. 11.
- Page 4 Only Kohler Mira recommended accessories should be used. 23. DO NOT perform any unspecified modifications, or drill or cut holes in the product other than instructed by this guide.
-
Page 5: Pack Contents
Pack Contents Tick the appropriate boxes to familiarize yourself with the part names and to confirm that the parts are included. 1 x Mira Sport Max with Airboost Electric Shower 1 x Olive 1 x Compression Nut 3 x Fixing Screws ... -
Page 6: Products Covered
To enjoy the full potential of your new shower, please take time to read this guide thoroughly, and keep it handy for future reference. Products manufactured by Kohler Mira Ltd are designed to be safe provided, that they are installed used and maintained in good working order, in accordance with our instructions and recommendations. -
Page 7: Specifications
Specifications Sport Max with Airboost Variant Plumbing 10.8 Minimum Dynamic Pressure 70 kPa (0.7 bar) 100 kPa (1.0 bar) Maximum Dynamic Pressure * 500 kPa (5 bar) Minimum Static Pressure 20 kPa (0.2 bar) Maximum Static Pressure * 1000 kPa (10 bar) Maximum Inlet Temperature 30°C Minimum Inlet Temperature... -
Page 8: Disposal And Recycling
Guarantee The Mira Sport Max with Airboost has been designed for domestic use only, Mira Showers guarantee the Mira Sport Max with Airboost against any defect in materials or workmanship for a period of two years from the date of purchase (shower fittings for one year). -
Page 9: Installation Requirements
Installation Requirements Plumbing 1. The plumbing installation must comply with all national or local water regulations and all relevant building regulations, or any particular regulation or practice specified by the local water supply company. 2. DO NOT use sealing compounds on any pipe fitting or joints. 3. - Page 10 17. A water treatment device should be installed where the water hardness may exceed 200 ppm. Malfunctions caused by excessive limescale formation are not covered by this shower’s guarantee (see back page for details). 18. The installation must not cause the hose to be sharply kinked during normal use.
- Page 11 Electrical 1. The electrical installation must comply with BS 7671 (commonly referred to as the IEE Wiring Regulations) and all relevant building regulations, or any particular regulation or practice specified by the local electricity supply company. 2. Ensure that all circuit protection devices, switches and cabling is adequate for the rated current of the shower and that the rating of the electricity supply company fuse and the consumer unit are adequate for the additional demand.
-
Page 12: Installation
Installation Warning! Turn off the electrical and water supplies before proceeding with the installation of the shower. Remove the three screws that Screws hold the cover on and remove Service the cover. Tunnel Remove the service tunnel. Using the installation template supplied, mark the positions of the three fixing holes. - Page 13 Determine the direction and route of the incoming water supply: falling (entering the shower from the top), or rising (entering the shower from the bottom). N O T E : - D O N O T use an incoming supply entering the shower directly from the back.
- Page 14 Connect the inlet supply pipe to the inlet connector using Inlet the compression nut and olive Connector (supplied). Always provide mechanical support when making plumbing connections. Upon Olive completion of the installation ensure connections and back Compression case are not under any stress due to misaligned pipework or Inlet Supply electrical cables.
- Page 15 Screws Ensure the earth bonding complies with relevant regulations. Cover Replace the service tunnel. Plug the multi-connector into the Multi- cover PCB socket Note: The Connector multi-connector will only locate correctly into the socket in one direction. Ensure the temperature control dial is aligned with the spindle Screw Spindle...
- Page 16 Identify the different ends of the air pipe tube: • Air pipe adapter is inserted into the shower outlet • Air pipe diffuser is inserted into the showerhead Adapter Diffuser Fit the air pipe adapter into the outlet connector, then carefully tighten the shower hose onto the Note: Make outlet connector.
- Page 17 Commissioning TEMPERATURE Turn temperature control Switch on the electrical Push START/STOP to the cold position. supply. button. Light in the button illuminates. COLD 0 - 15 secs TEMPERATURE Push LOW button. Low Water flows freely within a Slowly turn the button illuminates.
- Page 18 HIGH COLD 5 - 10 secs Temperature will rise slightly. Push HIGH button. High button illuminates COLD 5 - 10 secs TEMPERATURE Temperature will rise further. Adjust temperature as required. Flow rate will adjust automatically. Normal Flow AIRBOOST Airboost Enabled Check Airboost function.
-
Page 19: Operation
Operation Read the section “IMPORTANT SAFETY INFORMATION” first. BOOST HIGH POWER Switch on the electrical P u s h S TA R T / S T O P Push power button for the supply. button. Light in the button desired output. The button illuminates.* illuminates. - Page 20 The Effect of Seasonal Changes Incoming mains water temperature is not constant throughout the seasons of the year i.e. cooler during the winter, warmer during the summer, these changes can affect the outlet temperature of the shower, therefore the shower temperature may need to be increased or decreased to maintain the desired showering temperature.
-
Page 21: Fault Diagnosis
Fault Diagnosis In the event of a malfunction of the shower, the troubleshooting information below provides details on possible causes and remedies that may be carried out by qualified, competent personnel. WARNING There are no user serviceable components beneath the cover of the shower. Only qualified competent personnel should remove the front cover Start/Stop Power... - Page 22 Start/Stop Power Symptom Light is Control Possible Cause Possible Remedy ON or OFF Position Unable to Due to the rise in mains Turn the power control select a water supply temperature, to Eco or turn the cool enough the power control setting temperature control until shower.
- Page 23 Start/Stop Power Symptom Light is Control Possible Cause Possible Remedy ON or OFF Position Operation of Showerhead blocked. Remove and descale Temperature showerhead. Control Hose kinked or blocked. Check hose and replace if ECO/ has little or necessary. HIGH no effect on water Flow valve faulty.
-
Page 24: User Maintenance
Start/Stop Power Symptom Light is Control Possible Cause Possible Remedy ON or OFF Position Airboost Air pump or control Check connection plug function fails electronics faulty. between air pump and to operate or PCB. will not shut Replace air pump. off. - Page 25 1. Unscrew the shower hose from the shower then pull the Air Pipe Adaptor from the shower outlet. 2. Unscrew the shower hose from the Showerhead, pull out the Air pipe Diffuser. Ensure the diffuser holes are free from scale, clean if necessary. 3.
- Page 26 Servicing Warning! There are no user serviceable parts inside the shower. Servicing of the shower must only be carried out by qualified, competent personnel following the instructions provided in this guide and those provided with any spare part. Before replacing any parts, ensure that the underlying cause of the malfunction has been resolved.
-
Page 27: Spare Parts
Spare Parts 1746.436 Thermal Switch 1746.449 Terminal 1746.710 (9.0kW) Block 1746.711 (10.8kW) Heater Tank/PCB Max 1746.521 * 1746.522 * Flow Valve 1746.524 Outlet Connector 1746.435 Inlet Clamp 1829.062 Inlet Filter 1746.437 Coil 1746.434 Inlet Connector 1746.529 Air Pump 1746.526 1746.448 Air Pipe 1746.523 Service Tunnel... -
Page 28: Customer Support
Kohler Mira Limited. Cromwell Road, K/E S.A.S. Cheltenham, 3 rue de Brennus, The company reserves the right Gloucestershire 93631, La Plaine Saint-Denis, to alter product specifi cations GL52 5EP France without notice. 14648 © Kohler Mira Limited, September 2021 1473739-W6-A 1493936-W2-A...
