- Page 2 EN CONVECTION OVENS - INSTRUCTIONS FOR THE INSTALLATION DFV-511/N DFV-511/TS DFV-511/P RDA-105E RDT-105E DFV-1011/N DFV-1011/TS DFV-1011/P RDA-110E RDT-110E DFV-1511/N DFV-1511/TS RDA-115E RDT-115E...
-
Page 3: Installation
INDEX Dimensions Foreword Declaration of Conformity European Directive ROHS 2012/19/UE Transport of the oven and packaging removal Informative labels INSTALLATION Oven positioning Electrical connection Technical data for electrical connection Water features Technical data table water connection Hydraulic connection water inlet Plumbing –... - Page 4 105E Dimensioni Capacità Distanza teglie Peso a vuoto Dimensions Capacity Trays distance Empty weight Abmessungen Kapazität Einschubabstand Leergewicht Dimensions Capacité Ecartement grilles Poids à vide Dimensiones Capacidad Distancia bandejas Peso en vacío Afmetingen Capaciteit Afstand dienbladen Leeggewicht mm 710 x 828 x h 633 5 x 1/1 GN 67 mm 87 kg...
- Page 5 110E Dimensioni Capacità Distanza teglie Peso a vuoto Dimensions Capacity Trays distance Empty weight Abmessungen Kapazität Einschubabstand Leergewicht Dimensions Capacité Ecartement grilles Poids à vide Dimensiones Capacidad Distancia bandejas Peso en vacío Afmetingen Capaciteit Afstand dienbladen Leeggewicht mm 710 x 828 x h 968 10 x 1/1 GN 67 mm 124 kg...
- Page 6 115E Dimensioni Capacità Distanza teglie Peso a vuoto Dimensions Capacity Trays distance Empty weight Abmessungen Kapazität Einschubabstand Leergewicht Dimensions Capacité Ecartement grilles Poids à vide Dimensiones Capacidad Distancia bandejas Peso en vacío Afmetingen Capaciteit Afstand dienbladen Leeggewicht mm 750 x 847 x h 1667 15 x 1/1 GN 67 mm 165 kg...
-
Page 7: Declaration Of Conformity
FOREWORD The contents of this manual are generic and not all the functions described may be available on your product. The manufacturer declines all responsibility for possible inaccuracies contained in this pamphlet, due to printing or copy errors. We reserve the right to make on our own products those changes to be considered necessary or useful, without jeopardizing the essential characteristics. -
Page 8: Informative Labels
1.4 INFORMATIVE LABELS On each oven there are applied some metal labels, that give important info concerning characteristics of the oven, electric and plumbing connections and eventually the drain connection. On the right hand side panel there is the label A. The info contained on this label are: •... -
Page 9: Technical Data For Electrical Connection
INSTALLATION 1.5 POSITIONING OF THE OVEN The place where the oven will be installed must comply the following requirements: • Be protected from atmospheric agents and have an adequate air circulation; • Comply with regulations concerning safety at work; • Have a room temperature between 5 °C and 35 °C with a humidification not higher than 70%. •... -
Page 10: Hydraulic Connection - Water Inlet
2.4 TECNICAL DATA TABLE FOR THE WATER SYSTEM 5 x 1/1 GN 10 x 1/1 GN 15 x 1/1 GN Water flow rate regulator for steam generation in combi and steam Ø 0.4 mm Ø 0.4 mm cycle Ø 0.4 mm Water flow rate regulator drain steam Ø... -
Page 11: Control And Safety Devices
3.0 CONTROL AND SAFETY DEVICES The ovens are equipped with a set of control and safety devices for the electric and hydraulic circuits. 3.0A 2A fuse: it is in the auxiliary circuit to protect against short circuiting of the electrical system and is inside its own support on the contactor’s fixing bracket.
