Changing the Lower Compartment Temperature:
1. Press and hold the SET button until the display shows St1
with"F" flashing.
2. Press SET again to display the lower compartment's current
temperature ("F" will continue to flash).
3. Use the UP or DOWN arrow key to scroll to the desired
temperature. The controller will memorize the new
temperature.
Changing the Upper Compartment Temperature:
1. Press and hold the SET button until the display shows St1
with"F" flashing. Press the DOWN arrow once; the display
will read St2.
2. Press SET again to display the upper compartment's current
temperature ("F" will continue to flash).
3. Use the UP or DOWN arrow key to scroll to the desired
temperature. The controller will memorize the new
temperature.
NOTE: Dependent on the model and configuration, the
controllers have been programmed to only allow a lower
compartment temperature adjustment range as specified within
the chart below. The upper compartment range is not limited,
but should always be kept within the specified range shown in
the table for the upper compartment. See the chart below for
the specified range allowed for your unit.
Signature Series – Dual-Zone Units
Model
HP24Z Upper 30° - 42°F / Lower -10° - 10°F
HP24C Upper 45° - 65°F / Lower 30° - 42°F
HP24D Upper 51° - 65°F / Lower 45° - 60°F
Dual-Zone Temperature Scale
To change F to C, press and hold the down arrow for 3 seconds.
To Start A Manual Defrost (HP24Z Models Only)
Press and hold the DEFROST button (melting snowflake) for 3-5
seconds. Melting snowflake will illuminate.
6 | perlick.com/residential
PERLICK RESIDENTIAL UNDERCOUNTER REFRIGERATION USE & CARE GUIDE
TOUCH-SCREEN CONTROL OPERATION - REFRIGERATOR MODELS
Range (F)
Signature Series 15", 24" Single-Zone and Sottile,
and 48", ADA Freezer Control Instructions
To Set Target Temperature
Press and release the SET button. Display will show the current
temperature setpoint.
To Change Setpoint Temperature
1. Press and hold the SET button until the display shows the
current setpoint temperature with the "F" flashing.
2. Use the UP and DOWN arrow button to scroll to the desired
temperature.
To Start A Manual Defrost (Freezer Models Only)
Press the DEFROST button (melting snowflake).
To See Maximum Stored Temperature
Press the UP arrow button to see the maximum stored
temperature. To reset the maximum stored temperature, while
displayed, press and hold the SET button until 'rst' flashes in the
display.
To See Minimum Stored Temperature
Press the DOWN arrow button to see the minimum stored
temperature. To reset the minimum stored temperature, while
displayed, press and hold the SET button until 'rst' flashes in the
display.
On/Off
Press the ON/OFF button to turn the unit on or off.
NOTE: Dependent on the model and configuration, the
controllers have been programmed to only allow a temperature
adjustment within a specified range. See the chart below for the
specified range allowed for your unit.
