SPECIFICATIONS

b
▲ Model MCCHP12A
h
Dimensions (H x W x D)
Model
NOTE: Legs add 3.94" (100mm)
MCCHP12A
MCCHP12A-P (363 × 307 × 868 mm)
MCCHP24A
MCCHP24A-P (363 × 610 × 868 mm)
MCCHP36A
MCCHP36A-P (363 × 912 × 868 mm)
c
▲ Model MCCHP36A
14.3" x 12.1" x 34.2"
14.3" x 24" x 34.2"
14.3" x 35.9" x 34.2"
a
e
▲ Model MCCHP24A
g
i
Thermal Power
(BTU/KW)
60,000/17.6
120,000/35.2
180,000/52.8
7
f
a. 14.3" (363 mm)
b. 12.1" (307 mm)
c. 34.2" (868 mm)
d. 14.3" (363 mm)
e. 24" (610 mm)
f. 34.2" (868 mm)
g. 14.3" (363 mm)
h. 35.9" (912 mm)
i. 34.2" (868 mm)
Burners Net Weight
52.9 lbs.
2
(24kg)
105.8 lbs.
4
(48 kg)
167.6 lbs.
6
(76 kg)
Figure 1
d
