SPECIFICATIONS

b
▲ Model MCCHP12
h
Dimensions (H x W x D)
Model
NOTE: Legs add 3.94" (100mm)
MCCHP12
MCCHP12-P (363 × 307 × 868 mm)
MCCHP24
MCCHP24-P (363 × 610 × 868 mm)
MCCHP36
MCCHP36-P (363 × 912 × 868 mm)
c
▲ Model MCCHP36
14.3" x 12.1" x 34.2"
14.3" x 24" x 34.2"
14.3" x 35.9" x 34.2"
a
e
▲ Model MCCHP24
g
i
Thermal Power
(BTU/KW)
50,000/14.6
100,000/29.3
150,000/43.9
7
f
a. 14.3" (363 mm)
b. 12.1" (307 mm)
c. 34.2" (868 mm)
d. 14.3" (363 mm)
e. 24" (610 mm)
f. 34.2" (868 mm)
g. 14.3" (363 mm)
h. 35.9" (912 mm)
i. 34.2" (868 mm)
Burners Net Weight
52.9 lbs.
2
(24kg)
119 lbs.
4
(54 kg)
167.6 lbs.
6
(76 kg)
Figure 1
d
