ZURN AquaSense Z6920-XL-W1 Installation, Operation, Maintenance And Parts Manual
Hide thumbs
Also See for AquaSense Z6920-XL-W1:
Advertisement
Quick Links
Z6920-XL-W1
Sensor-Operated Lavatory Faucets with Smart Connected Features
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov
AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov
All goods sold hereunder are warranted to be free from defects in material and factory workmanship for a period of three years from the
date of purchase. Decorative finishes warranted for one year. We will replace at no costs goods that prove defective provided we are
notified in writing of such defect and the goods are returned to us prepaid at Sanford, NC, with evidence that they have been properly
maintained and used in accordance with instructions. We shall not be responsible for any labor charges or any loss, injury or damages
whatsoever, including incidental or consequential damages. The sole and exclusive remedy shall be limited to the replacement of the
defective goods. Before installation and use, the purchaser shall determine the suitability of the product for his intended use and the
purchaser assumes all risk and liability whatever in connection therewith. Where permitted by law, the implied warranty of merchantability
is expressly excluded. If the products sold hereunder are "consumer products," the implied warranty of merchantability is limited to a
period of three years and shall be limited solely to the replacement of the defective goods. All weights stated in our catalogs and lists
are approximate and are not guaranteed.
NOTICE: READ ENTIRE MANUAL PRIOR TO INSTALLING PRODUCT.
AquaSense
Connected EZ Gear Hardwire
Powered Sensor Faucets
Installation, Operation, Maintenance
and Parts Manual
Patented and Patents Pending
LIMITED WARRANTY
®
Z6922-XL-W1
Advertisement
Related Manuals for ZURN AquaSense Z6920-XL-W1
Summary of Contents for ZURN AquaSense Z6920-XL-W1
- Page 1 AquaSense ® Connected EZ Gear Hardwire Powered Sensor Faucets Installation, Operation, Maintenance and Parts Manual Patented and Patents Pending Z6920-XL-W1 Z6922-XL-W1 Sensor-Operated Lavatory Faucets with Smart Connected Features WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov LIMITED WARRANTY All goods sold hereunder are warranted to be free from defects in material and factory workmanship for a period of three years from the...
-
Page 2: Required Tools
(2) this device must accept any interference received, including interference that may cause undesired operation. The following information refers to Zurn Smart Connected Products, types: -W1. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference intended for use in non-residential/non-domestic environments. - Page 3 Spout Installation Instructions Endpoint & Electronic Module Installation Instructions 1.a. Install endpoint on wall surface within 2 feet radius of faucet 2. Connect endpoint and DC power cable. NOTE: Before installation, turn off water supplies to existing faucet and remove faucet if replacing an existing device. with dry wall anchors &...
- Page 4 Install Zurn Gateway per the Gateway Instructions Manual Request plumbSMART Administrator Account at 844-987-6737 Zurn creates your Enterprise Account for you! (You will be required to identify your building location, number of floors, and number of rooms.) Log in to plumbsmart.zurn.com Register each Connected Product in plumbSMART (Watch How-To Videos to Get Started.
- Page 5 Check/clean sensor lens of any debris or buildup. If possible, ad- or environmental factors such as just lighting conditions and/or remove nearby reflective surfaces if If listed as “Deactivated”, contact Zurn Custom Service at 1.855. highly reflective surfaces and/or sunlight or IR interference is a factor.
- Page 6 If LORA LED does not turn ON solid and ethernet cable connected, contact facility IT administrator to modify port rules to allow Zurn gateway to access the internet via local router. Step 2 Test activate the faucet and confirm single usage event data is...
- Page 7 Spout Replacement Filter and Mixing Valve Installation To replace spout body, you must first turn water off, then remove spout. Control Box Attach adapter here with -MV P6900-120BC, Filter in standard faucet installation Turn the spout nut to loosen the spout for removal. Lift spout up to remove spout.
- Page 8 Z6920-XL-W1 & Z6922-XL-W1 Parts List This Page Intentionally Left Blank Description Product No. Description Product No. 5 3/8” Gooseneck Spout with Nut, Item 1 P6900-GB Filter Kit, Item 9 P6900-120BC 0.5 GPM Vandal Resistant Aerator, Item 2 P6900-20F-GN Filter Screen, Item 10 P6900-MV-7 Z6920 No Lead Spout Base with Sensor Mixing Valve with Filter, Item 11...
- Page 9 ZURN INDUSTRIES, LLC W. Freshwater Way, Milwaukee, WI U.S.A. 53204 · Ph. 1-855-ONE-ZURN, Fax 919-775-3541 In Canada: ZURN INDUSTRIES LIMITED 7900 Goreway Drive, Unit 10, Brampton, Ontario L6T 5W6, Ph. 905-405-8272, Fax 905-405-1292 ZURN.COM Rev. E Date: 07/02/21 C.N. No. 143882 Prod.
