Z6953-XL-W2
Sensor-Operated Lavatory Faucets with Smart Connected Features
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov
AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov
All goods sold hereunder are warranted to be free from defects in material and factory workmanship for a period of three years from the
date of purchase. Decorative finishes warranted for one year. We will replace at no costs goods that prove defective provided we are
notified in writing of such defect and the goods are returned to us prepaid at Sanford, NC, with evidence that they have been properly
maintained and used in accordance with instructions. We shall not be responsible for any labor charges or any loss, injury or damages
whatsoever, including incidental or consequential damages. The sole and exclusive remedy shall be limited to the replacement of the
defective goods. Before installation and use, the purchaser shall determine the suitability of the product for his intended use and the
purchaser assumes all risk and liability whatever in connection therewith. Where permitted by law, the implied warranty of merchantability
is expressly excluded. If the products sold hereunder are "consumer products," the implied warranty of merchantability is limited to a
period of three years and shall be limited solely to the replacement of the defective goods. All weights stated in our catalogs and lists
are approximate and are not guaranteed.
NOTICE: READ ENTIRE MANUAL PRIOR TO INSTALLING PRODUCT.
AquaSense
Connected Battery Powered
Sensor Faucets-W2
Installation, Operation, Maintenance
and Parts Manual
Patented and Patents Pending
LIMITED WARRANTY
®
Z6956-XL-W2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ZURN AquaSense W2 Series
Summary of Contents for ZURN AquaSense W2 Series
- Page 1 AquaSense ® Connected Battery Powered Sensor Faucets-W2 Installation, Operation, Maintenance and Parts Manual Patented and Patents Pending Z6953-XL-W2 Z6956-XL-W2 Sensor-Operated Lavatory Faucets with Smart Connected Features WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov LIMITED WARRANTY All goods sold hereunder are warranted to be free from defects in material and factory workmanship for a period of three years from the...
-
Page 2: Electronic Emission Notices
• Consult an authorized dealer or service representative for help. Zurn is not responsible for any radio or television interference caused by using other than specified or recommended cables and connectors or by unauthorized changes or modifications to this equipment. Unauthorized changes or modifications could void the user's authority to operate the equipment. -
Page 3: Specifications
Unit is furnished with a standard 0.5 GPM aerator, and mounting hardware. Zurn Lead Free products (-XL) are designed and manufactured to comply with Section 1417 of the Safe Drinking Water Act (SDWA) which mandates the weighted average lead content of no more than 0.25% of the wetted surface... -
Page 4: Required Tools
AquaSense® Package Contents Spout Assembly Z6953-XL-W2 Z6956-XL-W2 Aerator Spout Assembly and Key Aerator and Key Base Gasket Batteries Shank Batteries Base Gasket Mounting Kit Shank Hydrogenerator Mounting Kit Y-Cable Y-Cable Hydrogenerator Electronics Box with Solenoid Electronics Box Valve with Solenoid Filter Filter Monitor... - Page 5 Cover Plate Installation Instructions 1. (For faucets with -CP4 or -CP8 suffix). Pass sensor connector wire and shank through gasket. Align gasket with faucet bottom and press firmly together. Pass sensor connector and shank through cover plate and fasten to the faucet with the provided screws.
- Page 6 Monitor & Electronic Module Installation Instructions Install Monitor on wall surface within 2 feet radius of faucet Loosen lid screw with supplied 3mm Allen wrench. Open lid with dry wall anchors & screws or doubled sided VHB tape and install supplied batteries. Close lid and tighten lid screw. Use AA Lithium Batteries or AA Alkaline batteries, but do not mix Lithium with Alkaline.
-
Page 7: Care And Cleaning Instructions
Open battery module using supplied 3mm Allen wrench and Tighten electronics module assembly to shank and connect install supplied batteries in the electronics module. Then close water line(s). and tighten battery module. Use AA Lithium Batteries or AA Alkaline batteries, but do not mix Lithium with Alkaline. - Page 8 Install Zurn Gateway per the Gateway Instructions Manual Request plumbSMART Administrator Account at 844-987-6737 Zurn creates your Enterprise Account for you! (You will be required to identify your building location, number of floors, and number of rooms.) Log in to plumbsmart.zurn.com Register each Connected Product in plumbSMART (Watch How-To Videos to Get Started.
- Page 9 Adjustable modes and features selection To adjust features from default configuration, you must remove the battery tray. Once battery tray is removed you will see the switches. Switch Position: Purge (Hours) Disable: Time (Seconds) Less Time-out Mode Select Sensing Mode: Metering Mode: All switches shown in default mode.
- Page 10 If not, install washer. If a bles to the faucet shank. washer is damaged, replace with new. For further assistance with troubleshooting visit http://www.zurn.com FV801 Rev. A 06/21/21 Page 9...
- Page 11 Details tab listed as “Activated” NETWORK: Senet SUBSCRIPTION STATUS: Activated LAST HEARD FROM: 07/14/2020, 04:29 PM CDT If listed as “Deactivated”, contact Zurn Custom Service at 1.855. ONE.ZURN (1.855.663.9876) for assistance. Step 1 “Status – Good” posted in plumbSMART and faucet not actuating Verify LoRa Monitor’s cables are connected to IR sensor...
- Page 12 If LORA LED does not turn ON solid and ethernet cable connected, contact facility IT administrator to modify port rules to allow Zurn gateway to access the internet via local router. If gateway model is ETH/LTE, visually verify SIM card is installed in designated slot on the side of gateway.
- Page 13 Verify product image and model number from plumbSMART product page “Details” tab against model number cited on product literature and packaging. If incorrect, contact Zurn Custom Service at 1.855.ONE.ZURN (1.855.663.9876) for assistance. “High Daily Faucet Activate Rate” posted in plumbSMART Step 1 Verify faucet is not falsely triggering.
- Page 14 Accessing the Solenoid To service solenoid use Phillips head screw driver to remove the With screws removed, the electronics box can slide off and allow screws on both sides of the electronics box. access to the solenoid for service. FV801 Rev. A 06/21/21 Page 13...
- Page 15 Filter and Mixing Valve Installation Control Box Attach adapter or Braided Hose (-SSH) here with -MV and TMV-1 options P6900-120BC, Filter in standard faucet installation -SSH suffix option P6900-12BC Filter Need to hold at pointed area by suitable wrench or by hand while applying torque to the supply hose nut.
- Page 16 Plunger spring, Item 20 ZURN INDUSTRIES, LLC W. Freshwater Way, Milwaukee, WI U.S.A. 53204 · Ph. 1-855-ONE-ZURN, Fax 919-775-3541 In Canada: ZURN INDUSTRIES LIMITED 7900 Goreway Drive, Unit 10, Brampton, Ontario L6T 5W6, Ph. 905-405-8272, Fax 905-405-1292 ZURN.COM Rev. A Date: 06/21/21 C.N.
