- Page 1 User manual Prone, supine and upright stander BS-300 Standing aids edition 24/21...
-
Page 3: Foreword
The prone, supine and upright stander BS-300 distinguishes itself by its quality, security, easy operation and modern design. For optimal use of this aid, we ask you and possible other users to carefully read this operating manual. -
Page 4: Table Of Contents
Table of contents Table of contents Topic Page Foreword ……………………………………… Table of contents ……………………………… Safety instructions …………………………… Warranty and product liability ……………… CE sign and position ………………………… Indications and prophylaxis ………………… 10 Purpose of use ………………………………… 11 Product overview ……………………………… 12 ………………………………... -
Page 5: Safety Instructions
Safety instructions Safety instructions The prone, supine and upright stander which they gained from (for example) BS-300 is CE-marked and fulfils the training courses. requirements of the latest directives. It was In the event of specific or difficult developed in line with most recent findings. - Page 6 • The operating manual is intended • The BS-300 may only be used by persons for retailers and users of the prone, of a suitable stature and physical aptitude. supine and upright stander BS-300, (or their carers), it contains the required •...
- Page 7 BS-300 in accordance with user. the instructions given in the chapter • Do not use the BS-300 before checking „cleaning”. the wheels of the aid. • Please ensure before use the product is cleaned according to the cleaning •...
- Page 8 We constantly develop new aids and improve existing products. We are happy to receive your suggestions of every description. Page 8/36 (24/21)
-
Page 9: Warranty And Product Liability
ATO FORM reserves the right to inspect the The warranty can only be sustained if the product being claimed for and the relevant ATO FORM product is in use in the same documentation before agreeing to the country where it was purchased and if... -
Page 10: Indications And Prophylaxis
Only compliance of the regulations specialist, who has tested beforehand and and instructions can lead to positive ergo- determined if the BS-300 is suitable for the nomically effects. individual therapeutic goal of the patient. We wish you every success when using the Furthermore, the medical specialist has Prone, supine and upright stander BS-300. -
Page 11: Product Overview
Product overview Product overview 8.1 Basic model 8.2. Accessories / options A Standard support cushion (large) H Therapy table with holder B Standard support cushion (small) Extension cushion wide/low C Belts Knee supports D Foot pedal for tilt settings K Posterior support Swivel wheels (lockable) Abductor wedge Heel support partitioned... - Page 12 (W 46 x H 17 cm) Without pictures: Electric motor, rechargeable Foot shells For a complete overview of our extensive range of accessories for the BS-300 see item 11.2 Ty- pes and accessories on page 24. Page 12/36 (24/21)
-
Page 13: Initial Operation
Initial operation Initial operation The reseller is to unpack the unit, ensure that the components and accessories listed in the scope of delivery are all present and undamaged, and give the buyer the initial instructions on use of the aid. This way, with help of the reseller, the user as well as the attendant must become famil- iar with the correct operation of the aid. -
Page 14: Assembly And Adjustment
Assembly and adjustment 10 Assembly and adjustment 10.1 Basic model Preparation: Unpack the product and remove the pack- ing materials. The device is completely assembled. Ensure that the product is complete and undamaged. Belts The belt is moved freely guided through the rail and fixed by a star grip. - Page 15 Assembly and adjustment Tilt settings Firstly loosen the clamping lever on the connection bar between the frame and board. Hold on to the tilt table and pull out the security lock. Release the locking pin when the stander is in the required position and ensure the locking pin clicks into place.
-
Page 16: Accessories / Options
Assembly and adjustment 11.2 Accessories / options Heel supports for the prone position The heel support is guided through the slot from underneath the foot rest and fastened. Chin support Mount the chin support onto the bars (as shown) and fasten screws carefully. Page 16/36 (24/21) - Page 17 Assembly and adjustment Thorax- and pelvic supports Place the thorax and pelvic supports fittings into the lateral guides as shown and fasten the allen screws into the desired height. Then push the side supports into the holder and fasten using the star grip. Page 17/36 (24/21)
- Page 18 Assembly and adjustment Headrest with facial aperture Push the long guide rails about 15 cm up- wards and secure the headrest into the mid pipes, fasten by use of the clamping screws. Abductor wedge Push the abductor wedge through the slot centered in the lying surface.
- Page 19 Assembly and adjustment Extension cushion The extension cushion is mounted onto the two guide rails between the lower and upper standard support cushion. Page 19/36 (24/21)
- Page 20 Assembly and adjustment Posterior support The supporting adaptor for the posterior support is mounted - as shown - onto the long guide rails. Lead the bars through the extension cush- ion and the posterior support. Fasten with the handle. The posterior support can be adjusted (as shown).
- Page 21 Assembly and adjustment Therapy table for prone and supine position Start by removing the upper supporting cushion by loosening both locking screws. Mount the painted table holder (adjusting screws are on the top) onto the long guide rails and tighten the adjusting screws. Now assemble the upper standard support cushion again.
- Page 22 Assembly and adjustment Knee supports for supine position Knee supports: You need to shape (cut out) the knee blocks according to the individual needs of the user. Please adjust the knee supports to suit the individual needs of the user. Place the fitting in the slot and fasten in the desired height.
- Page 23 Assembly and adjustment Electric tilt adjustment Mounting of the electro box only needs to be carried out, if the electric drive is ordered separately. When ordering a BS prone, supine and upright stander with electric tilt adjustment, it is delivered completely mounted. Firstly, dismount the connection bar for the manual tilt from the top of the stander and frame (Fig.
-
Page 24: Types And Accessories
11 Types and accessories 11.1 Basic model BS-300-9550-6 Prone, supine and upright stander, Size 3, green 11.2 Accessories / options Following accessories are available for the BS-300 prone, supine and upright stander: BSZ-301-8550-6 Abductor wedge BSZ-302-1550-6 Heel support (pair) for prone position... - Page 25 Types and accessories The most up-to-date overview of our extensive range of accessories for BS 300 and their description as well as much more useful information can be found on our homepage www.ato- form.com. For special problems, or if it seems the accessories you require are not demons- trated nor described, please contact us.
-
Page 26: Technical Details
Technical details 12 Technical details BS-300 Prone, supine and upright stander Armpit height: 115 bis 153 Overall width: Overall length: Overall height, basic model: max. 135 Overall height including all accessories*: max. 195 Overall height (horizontal position): Access height: 10 bis 15... -
Page 27: Cleaning And Disinfection
Cleaning and disinfection 13 Cleaning and disinfection Leftovers, dirt and dust are always to be Disinfection: removed. Moving parts work easier, if you For disinfecting, use household disinfectants apply one drop of oil after cleaning. and consider the following indications: Cleaning the metal parts: The assistant must wear suitable protective The painted and chromed parts of the... -
Page 28: Maintenance And Overhaul
No signs of damage or wear Please contact your specialist dealer to carry out corrective maintenance works for your Frame BS-300. • Metal parts; no signs of damage or wear, The device should be checked by the especially for adustable parts manufacturer at the latest after 5 years. - Page 29 Maintenance and overhaul Date Service performed Name Sign Page 29/36 (24/21)
-
Page 30: Operating Life And Re-Use
Operating life and Re-use 15 Operating life and Re-use The BS-300 is made from high quality The product BS-300 was designed so it materials and is subject to a continuous could be reused after the application of quality control in our house. Because of various measures. -
Page 31: Faults, Repairs, Spare Parts
Faults, repairs, spare parts 16 Faults, Repairs, spare parts If your toilet seat lift BS-300 cannot be Only original accessories and original spare operated? parts may be used. Non-compliance with these instructions and repairs carried out Please ensure….. or modifications made to the BS-300 or its •... -
Page 32: Storage
17 Storage Keep this operating manual in a safe place, The current version of these where you or care and maintenance staff instructions for use can be have access to it. found on our homepage in the download area. You can find more informati- on about the product on our homepage at www.ato-form. - Page 33 Page 33/36 (24/21)
- Page 34 Page 34/36 (24/21)
- Page 35 Disposal of battery operated devices The battery pack must not be disposed of together with normal household waste at the end of its service life. Please observe the legal requirements in your area. Your municipal government and locally based waste disposal companies will be happy to provide you with information in this regard.
- Page 36 Hoists ■ Customized solutions ■ Thank you for your interest in our products. For questions please contact ATO FORM GmbH or your specialist dealer. Your ATO FORM Team ATO FORM GmbH Zur Lauterhecke 34, 63877 Sailauf, Germany Tel. +49 6093 944-0, Fax +49 6093 944-444 E-Mail: info@ato-form.com...
