- Page 1 User Manual prone, supine and upright stander BS 100 Standing Aids Issue 29/13...
-
Page 3: Foreword
We would like to thank you for your trust extended to us and for purchasing our product. The BS 100 prone, supine and upright stander distinguishes itself by its quality, se- curity, easy operation and modern design. For optimal use of this aid, we ask you and other possible users to carefully read this operating manual. -
Page 4: Table Of Contents
Index Topic Page Foreword ……………………………… 3 Index …………………………………… 4 Safety instructions ……………………… 5 Important warnings ………………… 6-7 Warranty and product liability ………… 8 Purpose of use ………………………… 9 Position of CE-sign …………………… 9 Indications ……………………………… 9 Equipment overview …………………… 10 Delivery …………………………………... -
Page 5: Safety Instructions
Safety instructions Safety instructions The prone, supine and upright stander BS 100 is labeled with the CE mark and complies with the requirements of Directive the user manual represents a guide to 93/42/EWG. It was developed in line with the most important handling, with the most recent findings. -
Page 6: Important Warnings
Important warnings Important warnings When using a prone, supine and upright • The given instructions of the operating stander the center of gravity is always manual refer to the point in time of the device being placed on the market. relatively high up. - Page 7 Important warnings • Always ensure there are no obstacles in • Be careful when moving the standing operating range of the BS, such as car- aid, whilst a patient is standing in the pets, stairs or objects on the floor, which device.
-
Page 8: Warranty And Product Liability
ATO FORM homepage/download www. ato-form.com. The warranty can only be sustained if the ATO FORM product is in use in the same country where it was purchased and if the product can be identified by the serial number. The warranty does not cover acci- dental damage, including damage caused by misuse or neglect. -
Page 9: Purpose Of Use
Purpose of use Position of CE-sign Indications Purpose of use The prone, supine and upright stander BS is only intended for indoor use. It offers a variety of therapeutic applications such as, standing frame, prone board, and supine board or as a drainage support. -
Page 10: Equipment Overview
Eqipment overview Equipment overview A Extension cushion, wide/low (Accessories) F Foot plate partitioned B Pelvis support (Accessories) G Therapy table with holder (Accessories) C Abductor wedge (Accessories) H Swivel wheels (lockable) D Standard support cushion (large) I Chin support (Accessories) E Heel support partitioned (Accessories) Page 10... -
Page 11: Delivery
Delivery Belts and foot support Delivery All BS prone, supine and upright standers are delivered in a robust carton and operational immediately after unpacking. Belts and foot support The belt is moved freely guided through the rail and fixed by a star grip. The height and angle of the foot rest is adjusted using a clamping lever. -
Page 12: Assembly Of Heel Support
Assembly of heel support Assembly of heel support (Accessories) The heel support is guided through the slot from underneath the foot rest and fastened. Page 12... -
Page 13: Assembly Of Chin And Thorax
Assembly of chin and thorax supports Assembly of chin and thorax supports (Accessories) Chin support: mount the chin support onto the bars (as shown) and fasten screws carefully. Place the thorax supports fittings into the lateral guides as shown and fasten the allen screws into the desired height. -
Page 14: Assembly Of Headrest
Assembly of headrest with facial aperture Assembly of headrest with facial aperture (Accessories) Push the long guide rails about 15 cm upwards and secure the headrest into the mid pipes, fasten by use of the clamping screws. Page 14... -
Page 15: Assembly Of Abductor Wedge
Assembly fo abductor wedge Assembly of abductor wedge (Accessories) Push the abductor wedge through the slot centered in the lying surface. Fasten on the backside using the allen screw. Page 15... -
Page 16: Extension Cushion And Posterior Support
Extension cushion and posterior support Extension cushion and posterior support (Accessories) The extension cushion is mounted onto the two guide rails between the lower and upper standard support cushion. The supporting adaptor for the posterior support is mounted - as shown - onto the long guide rails. -
Page 17: Therapy Table For Prone
Therapy table for prone and supine position Therapy table for prone and supine position Start by removing the upper supporting cushion by loosening both locking screws. Mount the painted table holder (adjusting screws are on the top) onto the long guide rails and tighten the adjusting screws. -
Page 18: Tilt Settings
Tilt settings Tilt settings You can adjust tilt, by pressing the foot pedal down. It is important to hold on to the tilt table before the foot pedal is activated and while the angle is being adjusted. Remove your foot from the pedal, to fixate the desired position. -
Page 19: Knee Supports For Supine Position
Knee supports for supine position Knee supports for supine position (Accessories) Knee supports: You need to shape (cut out) the knee blocks according to the individual needs of the user. Please adjust the knee supports to suit the individual needs of the user. Place the fitting in the slot and fasten in the desired height. -
Page 20: Types
Types / Accessories Cleaning /Maintenance Types BS-1000-4 BS prone, supine and upright stander size 1, frame yellow Accessories Following accessories are available for the BS prone, supine and upright stander: BS-0810-4 Therapy table for prone and supine position BS-0100-4 Abductor wedge (12 x 7,5 x 9 cm) BS-0200-4 Heel support (pair) for prone position BS-0300-4... -
Page 21: Technical Details
Technical details Re-use Technical details: prone, supine and upright stander BS Size 1 Article number: BS-1000-4 Armpit height: 70-101 cm Overall width: 51 cm Overall length: 70 cm Overall height, basic model: max. 86 cm Overall height, including all accessories*: max. -
Page 22: Spare Parts
In these cases, any product liability granted by the manufacturer (ATO FORM GmbH, Zur Lauterhecke 34, D-63877 Sailauf) voids in advance. For all questions about spare parts and... - Page 24 Thank you for your interest in our products. For questions please contact ATO FORM GmbH or your specialist dealer. Your ATO FORM Team Your specialist dealer ATO FORM GmbH, Zur Lauterhecke 34, D-63877 Sailauf www.ato-form.com phone 0049 6093 944 0, E-Mail: info@ato-form.com...
