- Page 1 User manual Series CareWell universal transfer- and changing bench MobiCare Bath and wc edition 24/21...
-
Page 3: Foreword
We would like to thank you for your trust extended to us and for purchasing our product. The Changing bench CareWell MobiCare distinguishes itself by its quality, security, easy operation and modern design. For optimal use of this aid, we ask you and possible other users to carefully read this operating manual. -
Page 4: Table Of Contents
Table of contents Table of contents Topic Page Foreword ……………………………………… Table of contents ……………………………… Safety instructions …………………………… Warranty and product liability ……………… CE sign and position ………………………… Indications and prophylaxis ………………… 10 Purpose of use ………………………………… 10 Product overview ……………………………… 11 ………………………………... -
Page 5: Safety Instructions
Safety instructions Safety instructions The Changing bench CareWell MobiCare In the event of specific or difficult is CE-marked and fulfills the requirements applications, the user manual represents a of the lastest directives. It was developed in guide to the most important handling. - Page 6 This operating manual is an indispensable manual. component of the delivery and should be • The CareWell MobiCare may only be stored carefully for further use. used by persons of a suitable stature and • The operating manual is intended for physical aptitude.
- Page 7 • Clean the Changing bench CareWell carer or user. MobiCare in accordance with the • Do not use the CareWell MobiCare instructions given in the chapter before checking the wheels of the aid. „cleaning”.
- Page 8 Safety instructions We constantly develop new aids and improve existing products. We are happy to receive your suggestions of every description. Page 8/32 (24/21)
-
Page 9: Warranty And Product Liability
ATO FORM reserves the right to inspect the The warranty can only be sustained if the product being claimed for and the relevant ATO FORM product is in use in the same documentation before agreeing to the country where it was purchased and if... -
Page 10: Indications And Prophylaxis
Purpose of use The device must be prescribed by a medical specialist, who has tested beforehand and determined if the CareWell MobiCare is suitable for the individual therapeutic goal of the patient. Furthermore, the medical specialist has determined the aid to be suita- ble according to measurements, weight and willingness of the patient to use the aid. -
Page 11: Product Overview
Product overview Product overview 8.1 Basic model 1. Basic frame with safety skirt 5. Remote control 2. Safety casters individually lockable 6. Paper roll holder 3. Battery unit 7. Side rails 4. Control box 8. CE label Page 11/32 (24/21) -
Page 12: Accessories / Options
Product overview Accessories / options According to the current status, there are no accessories for this product available. For a complete overview of our extensive range of accessories for the CareWell Mo- biCare see item 11.2 Types and accessories on page 18. Page 12/32 (24/21) -
Page 13: Initial Operation
Initial operation Initial operation The reseller is to unpack the unit, ensure that the components and accessories listed in the scope of delivery are all present and undamaged, and give the buyer the initial instructions on use of the aid. Above all the reseller should read through the complete present user manual carefully, in order to then explain it to the customer in detail. -
Page 14: Assembly And Adjustment
Assembly and adjustment 10 Assembly and adjustment 10.1 Basic model Preparation: Unpack the product and remove the pack- ing materials. The device is completely assembled. Ensure that the product is complete and undamaged. Electrical system The universal transfer and changing table is equipped with a control unit and a battery unit. - Page 15 Assembly and adjustment LED operation display Solid yellow: Charging (battery not ready) LED is off: fully charged (battery ready) The charger integrated in the battery unit is only supplied with power via the control unit. The switch-mode power supply of the control unit is equipped with a wide-range input for the voltage range 100 - 240V AC 50/60Hz.
- Page 16 Assembly and adjustment Use of the universal transfer and changing table Moving the patient from a wheelchair Lift the side guard and fold it down. Store the side guard under the table. Move the table down to the height of the wheel- chair seat.
- Page 17 Assembly and adjustment Paper roll holder The paper roll holder can accommodate a paper roll with a length of 70.0 cm, an inner diameter of at least 2.2 cm and an outer diameter of maximum 14.5 cm. For this purpose, loosen the screws (A) on the paper roll holder and pull the paper roll holder apart.
-
Page 18: Types And Accessories
Mobile changing bench CareWell MobiCare 1800 laying surface 180 x 75 cm, basic frame steel powder-coated CW-MC-2000E Mobile changing bench CareWell MobiCare HD 2000 laying surface 200 x 96 cm, basic frame stainless steel CW-MC-2000 Mobile changing bench CareWell MobiCare HD 2000... - Page 19 The most up-to-date overview of our extensive range of accessories for Care- Well MobiCare and their description as well as much more useful information can be found on our homepage www. ato-form.com. For special problems, or if it seems the accessories you require are not demons- trated nor described, please contact us.
-
Page 20: Technical Details
Technical details Page 20/32 (24/21) - Page 21 Technical details Construction Operating conditions Standby power consumption: approx. The basic framework consists of pow- 0.5 W (230 V). der-coated steel or stainless steel, depend- ing on the model and version. The padded Duty cycle: maximum 10% (or 2 minutes) surface is made of fireproof synthetic use, then 18 minutes break.
-
Page 22: Cleaning And Disinfection
Cleaning and disinfection 13 Cleaning and disinfection Leftovers, dirt and dust are always to be Disinfection: removed. Moving parts work easier, if you For disinfecting, use household disinfectants apply one drop of oil after cleaning. and consider the following indications: Cleaning the metal parts: The assistant must wear suitable protective The painted and chromed parts of the... - Page 23 Page 23/32 (24/21)
-
Page 24: Maintenance And Overhaul
Full brake function Please contact your specialist dealer to carry • No signs of damage or wear out corrective maintenance works for your CareWell MobiCare. Frame The device should be checked by the • Metal parts; no signs of damage or wear, manufacturer at the latest after 5 years. - Page 25 Maintenance and overhaul Date Service performed Name Sign Page 25/32 (24/21)
-
Page 26: Operating Life And Re-Use
Operating life and Re-use 15 Operating life and Re-use The CareWell MobiCare is made from high The product CareWell MobiCare was quality designed so it could be reused after the materials and is subject to a continuous application of various measures. -
Page 27: Faults, Repairs, Spare Parts
Faults, repairs, spare parts 16 Faults, repairs, spare parts If your toilet seat lift CareWell MobiCare Only original accessories and original spare cannot be operated? parts may be used. Non-compliance with these instructions and repairs carried out Please ensure….. or modifications made to the CareWell •... -
Page 28: Storage
17 Storage Keep this operating manual in a safe place, The current version of these where you or care and maintenance staff instructions for use can be have access to it. found on our homepage in the download area. You can find more informati- on about the product on our homepage at www.ato-form. - Page 29 Page 29/32 (24/21)
- Page 30 Page 30/32 (24/21)
- Page 31 Disposal of battery operated devices The battery pack must not be disposed of together with normal household waste at the end of its service life. Please observe the legal requirements in your area. Your municipal government and locally based waste disposal companies will be happy to provide you with information in this regard.
- Page 32 Hoists ■ Customized solutions ■ Thank you for your interest in our products. For questions please contact ATO FORM GmbH or your specialist dealer. Your ATO FORM Team ATO FORM GmbH Zur Lauterhecke 34, 63877 Sailauf, Germany Tel. +49 6093 944-0, Fax +49 6093 944-444 E-Mail: info@ato-form.com...
