Garden Furniture Direct Newland SRTPB Assembly Instructions

Steel picnic bench

Table of Contents

Download this manual

G G a a rden

Fu u

03333 448 121

Before you commence the assembly process we recommend that you read these instructions

thoroughly beforehand to familiarise yourself with the assembly process and to also check that you have

the correct components. If for any reason you need assistance, you can find our contact details on the

final page of these instructions.

We highly recommend that any assembly is carried out on a flat, level surface if possible and that you

use another person to assist you if necessary.

Package contents

1 x Table top

2 x Seat panels

2 x Table leg-frames

2 x Cross braces

4 of M8 x 60mm Bolts and self locking nuts

2 of M8 x 50mm Coach screws

12 of M8 x 70mm Coach screws

Cover caps and washers

rnitu re

Direct

Newland steel picnic bench

ASSEMBLY

INSTRUCTIONS

10mm socket or spanner

Table of Contents

Do you have a question about the Newland SRTPB and is the answer not in the manual?

Page 1 ASSEMBLY G G a a rden INSTRUCTIONS Fu u rnitu re Direct 03333 448 121 Newland steel picnic bench Before you commence the assembly process we recommend that you read these instructions thoroughly beforehand to familiarise yourself with the assembly process and to also check that you have the correct components.
Page 2 Newland steel picnic bench Step 1 Step 2 Ensure that you have all of the correct parts as listed Lay the table top upside down on a clean, flat surface on the front page of these instructions, including any taking care not to damage it. Now line up one of the fixings.
Page 3 Newland steel picnic bench Step 5 Step 6 In preparation for attaching the cross brace (as ...and then offer up the the cross brace and loosely shown in figure 8) place a bolt and washer through secure using a washer and a locknut for each of the each of the two holes in the leg-frame uprights..
Page 4 Newland steel picnic bench Step 9 Step 10 ...before repeating steps 5 to 8 for the other end of After turning the table right side up, place each of the the table. two seat panels onto the frame assembly, aligning the panels centrally across the support as shown...
