  • Page 1 OPERATING INSTRUCTIONS Translation of the Original RPT 010...
  • Page 2 Dear Customer, Thank you for choosing a Pfeiffer Vacuum product. Your new sensor is designed to support you in your individual application with maximum performance and without malfunctions. The name Pfeiffer Vacuum stands for high-quality vacuum technology, a comprehensive and complete range of top-quality products and first-class service.

  • Page 3: Table Of Contents

    Operation Evaluating the measurement signal Determining the effective pressure with calibration factors Maintenance Removing components Cleaning of components Calibrating the pressure sensor Shipping Recycling and disposal General disposal information Disposal of sensors Service solutions by Pfeiffer Vacuum Spare parts 3/32...
  • Page 4 Table of contents Technical data and dimensions 12.1 General 12.2 Technical data 12.3 Dimensions Certification Declaration of conformity 4/32...

  • Page 5: About This Manual

    1.1.2 Variants This document applies to products with the following part numbers: Article number Designation Connection PT R71 035 RPT 010 (G1/8", 0.35 m cable) Molex PT R71 050 RPT 010 (G1/8", 0.5 m cable) Molex PT R71 100 RPT 010 (G1/8", 1.0 m cable)

  • Page 6: Conventions

    1.3.3 Stickers on the product This section describes all the stickers on the product along with their meanings. Rating plate D-35614 Asslar The rating plate is located on Mod. RPT 010 PT R71 xxx the side of the sensor. xxxxxxxx TÜV Rheinland Input 5 V DC 0.25 W...

  • Page 7: Trademark Proof

    Turbopump electronic drive unit (turbo controller) Measuring signal [V] (output voltage) Underrange Tbl. 3: Abbreviations used 1.4 Trademark proof ● HiPace ® is a registered trademark of Pfeiffer Vacuum GmbH. ● Molex ® is a registered trademark of Molex Incorporated, Lisle, Illinois, USA. 7/32...

  • Page 8: Safety

    ► Only operate the device in a dry environment. ► Operate the device away from fluids and humidity sources. ► Do not switch on the device if fluid has penetrated into it, instead contact Pfeiffer Vacuum Serv- ice. ► Always disconnect the current supply before cleaning the device.

  • Page 9: Safety Precautions

    Safety WARNING Health hazard through poisoning from toxic contaminated components or devices Toxic process media result in contamination of devices or parts of them. During maintenance work, there is a risk to health from contact with these poisonous substances. Illegal disposal of toxic sub- stances causes environmental damage.

  • Page 10: Proper Use

    ► Inform yourself about any contamination before starting work. 2.4 Proper use The sensor is used for the integrated pressure measurement at the Pfeiffer Vacuum HiPace or HiScroll within the permissible total pressure range. Use the product according to its intended purpose 1.

  • Page 11: Product Description

    ● Piezo-resistive measurement system The sensor responds to measured value requests, type requests and adjustment commands. Signals are evaluated via the interfaces of the electronic drive unit using a Pfeiffer Vacuum display and control unit or external units (e.g. PLC or PC).

  • Page 12: Transport And Storage

    Transport and storage 4 Transport and storage 4.1 Transporting the product NOTICE Damage caused by incorrect transportation Transportation in unsuitable packaging, or failure to install all transport locks, can damage the prod- uct. ► Comply with the instructions for safe transportation. Packing We recommend keeping the transport packaging and original protective cover.

  • Page 13: Installation

    Installation 5 Installation 5.1 Establishing the vacuum connection NOTICE Impairment from contamination and damage Touching the devices or components with bare hands increases the desorption rate and leads to in- correct measurements. Dirt (e.g. dust, fingerprints, etc.) and damage impair the function. ►...

  • Page 14: Connecting The Sensor To Hiscroll

    Installation Procedure 1. Remove the protective cap from the sensor and store it in a safe place. 2. Remove the locking screw from the desired connector of the turbopump. 3. Mount the sensor on the vacuum side on the desired G 1/8" connector of the turbopump. –...

  • Page 15: Establishing The Electric Connection

    Installation 5.2 Establishing the electric connection NOTICE Property damage to the electronics or the sensor Disconnecting the plug-and-socket connection with the voltage supply switched on may lead to the destruction of electronic components. ► Always interrupt the voltage supply before you plug in or unplug the sensor connection cable. 5.2.1 Connecting the sensor with TIC 010 to HiPace Electronic drive unit operating instructions Observe the information on the connection in the operating instructions for the electronic...

  • Page 16: Connecting The Sensor With A D-Sub Adapter To Hiscroll

    Installation 5.2.2 Connecting the sensor with a D-Sub adapter to HiScroll HiScroll RPT 010 n.c. 24 V DC* (V+) n.c. n.c. RPT DaO RS 485 D+ RS 485 D- RPT DaI Fig. 4: D-Sub adapter connection diagram The D-Sub adapter of the sensor guides contacts 2 to 11 and 13 to 15 of the remote interface to the D- Sub socket on the back.

  • Page 17: Operation

    6.1 Evaluating the measurement signal Signal evaluation via output interfaces The output interfaces of the electronic drive unit with the applicable Pfeiffer Vacuum proto- col and the Pfeiffer Vacuum parameter set are used to operate the connected accessory devices on a Pfeiffer Vacuum vacuum pump.
  • Page 18 Operation Gas type Calibration factor (C) Xenon (Xe) Freon 12 The calibration factors provided are mean values. Tbl. 6: Calibration factors for the pressure range < 1 hPa p [hPa] Freon 12 –1 Water vapor –2 –3 –3 –2 –1 [hPa] Fig.

  • Page 19: Maintenance

    Warranty claim Opening the device during the warranty period or damaging/removing the warranty seal will void the warranty. Contact the Pfeiffer Vacuum Service Center in the event of process-related shorter mainte- nance intervals. First read through the sections completely Read the section with the work instructions through completely first before you commence with work.

  • Page 20: Cleaning Of Components

    ► Only operate the device in a dry environment. ► Operate the device away from fluids and humidity sources. ► Do not switch on the device if fluid has penetrated into it, instead contact Pfeiffer Vacuum Serv- ice. ► Always disconnect the current supply before cleaning the device.
  • Page 21 Maintenance Perform HV calibration 1. Operate vacuum system at final pressure. 2. Wait for stabilization period of at least 10 minutes. 3. Read off actual pressure value of reference measurement. 4. Use [P:740] to set actual pressure value to reference value. 5.

  • Page 22: Shipping

    ► Comply with the instructions for safe distribution. Decontamination subject to charge Pfeiffer Vacuum decontaminates products not clearly declared "Free of contamination" at your expense. Instructions for safe shipping ► Do not ship microbiological, explosive or radioactively contaminated products.

  • Page 23: Recycling And Disposal

    9.1 General disposal information Pfeiffer Vacuum products contain materials that you must recycle. ► Dispose of our products according to the following: – Iron –...

  • Page 24: Service Solutions By Pfeiffer Vacuum

    We are always focused on perfecting our core competence – servicing of vacuum components. Once you have purchased a product from Pfeiffer Vacuum, our service is far from over. This is often exactly where service begins. Obviously, in proven Pfeiffer Vacuum quality.
  • Page 25 Service solutions by Pfeiffer Vacuum 5. Prepare the product for transport in accordance with the provisions in the contamination declaration. a) Neutralize the product with nitrogen or dry air. b) Seal all openings with blind flanges, so that they are airtight.

  • Page 26: Spare Parts

    Spare parts 11 Spare parts Ordering spare parts ► Have the part number to hand, along with other details from the rating plate as required. ► Install original spare parts only. Description Order number U sealing ring U 10.4/16 x 2 P 3529 133 -P Tbl.

  • Page 27: Technical Data And Dimensions

    Technical data and dimensions 12 Technical data and dimensions 12.1 General mbar Torr | mm Hg mbar 1 · 10 0.75 1000 1000 1 · 10 0.01 0.01 1 · 10 1 · 10 7.5 · 10 0.75 1 · 10 0.01 1000 Torr | mm Hg 1.33...

  • Page 28: Dimensions

    75 g (with 0.5 m ca- ble) ble) Substances in contact Ceramic, nickel, stainless steel, tungsten, silicon dioxide, glass, araldite, with the media solder Tbl. 10: Technical data, RPT 010 Parameter Value Protection degree IP40 Output voltage 5 V DC Input voltage...
  • Page 29 Technical data and dimensions SW 19 Fig. 9: Dimensions with micro USB plug Dimensions in mm 29/32...

  • Page 30: Certification

    The product RPT 010 with Molex connector - conforms to the UL standard UL 61010-1:2012. TÜV Rheinland - is certified to the CAN/CSA standard CAN/CSA C22.2 No. 61010-1-12. https://www.certipedia.com (Certificate No. 72142403)

  • Page 31: Declaration Of Conformity

    Declaration of conformity Declaration for product(s) of the type: Piezo/Pirani sensor RPT 010 We hereby declare that the listed product satisfies all relevant provisions of the following European Directives. Electromagnetic compatibility 2014/30/EU Restriction of the use of certain hazardous substances 2011/65/EU...
