- Page 1 USER'S MANUAL JETSURF ELECTRIC For models: Jetsurf ELECTRIC - JEA1 Version: 2.4 / ENG Revision date: 09.09.2021...
-
Page 3: Table Of Contents
4�1� JETSURF ELECTRIC DESCRIPTION � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 19... - Page 4 9�6� LEARNING HOW TO TURN ON JETSURF� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 55...
-
Page 5: Introduction
As MSR Engines is committed to continuous product improvement and technology development, MSR Engines reserves the right to make changes to the product, components, specifications or any other aspects of the Jetsurf motosurf without prior notice or request to equip previously manufactured Jetsurf motosurfs with such changes. - Page 6 Please read it carefully and familiarize yourself with the craft before using it. Do not use the Jetsurf unless the expected weather conditions (wind force and wave height) correspond to the design category of your motosurf (see Chapter 14) because you will not be able to operate the craft safely in these conditions.
-
Page 7: Identification And Warning Labels
IMG0022 Please read the following warnings before using this craft. If you have any questions, consult your Jetsurf dealer. 2.2. WARNINGS • The MSR1219 / ED sticker is located on the bottom of the battery. - Page 8 2 IDENTIFICATION AND WARNING LABELS...
- Page 9 2 IDENTIFICATION AND WARNING LABELS...
-
Page 10: Safety Warnings
"craft" in this manual are interchangeable terms and means a craft that uses a built-in electric motor. The motor drives a jet pump, which is the primary source of propulsion. The Jetsurf is designed to be operated by a person ("rider" or "user") standing or kneeling on the board. The direction of the movement of the Jetsurf is controlled by the movement of the rider, the speed is controlled by the throttle control trigger located in the control handle. -
Page 11: 3�2� Common Sense
All work not described and explained in this manual should only be carried out by trained specialists (your authorized Jetsurf dealer will be happy to help you). Do not open either the electric motor or the lithium-ion battery. -
Page 12: 3�4� Motor Preparation
Straps, buckles as well as the edges of fabric can become entangled in the moving parts of the Jetsurf. Long hair should be arranged so that it cannot become entangled in the moving parts of the Jetsurf. -
Page 13: 3�6� Personal Floatation Device (Pfd)
Guard*. State and local laws and statutes may differ from federal requirements. As Jetsurf motorized surfboards are generally defined as passenger crafts, it is essential that all users contact local authorities for any information regarding the use of safety accessories. -
Page 14: 3�12� Jumping With Jetsurf
Owners must not allow any other person to use Jetsurf without prior instruction on its proper use and the risks involved. Owners are strongly advised to obtain appropriate liability insurance and property insurance in case of possible court decisions in these cases. -
Page 15: 3�15� Other Security Issues
3 SAFETY WARNINGS 3.15. OTHER SECURITY ISSUES Riders should: • Be at least sixteen (16) years of age or at the minimum age required in the jurisdiction in which the motorized surfboard is being operated. Motorized surfboards were designed for adults. •... -
Page 16: 3�16� Safe Water Operation
3 SAFETY WARNINGS 3.16. SAFE WATER OPERATION Laws, rules, regulations and how to enforce them have been developed around the world to ensure the safe and proper operation of all crafts. It is the responsibility of the owner and / or user to familiarize themselves with all applicable regulations of the authorities managing the waters in which the motorized surfboard will be operated. - Page 17 "Craft which gives way". To illustrate: in the picture (A) you are the Jetsurf in the middle. You are required to give way to any craft in the white field (you are a "craft which gives way"). Any craft in a darker area must give way to you (you are a "priority craft").
- Page 18 3 SAFETY WARNINGS OVERTAKING When overtaking another craft, you are the "priority craft". The other craft is expected to maintain course and speed, and you are required to stay off course until you overtake it. In the event that another craft overtakes you, you should maintain your direction and speed so that the overtaking craft can safely bypass you.
-
Page 19: Overview Of The Craft
4 OVERVIEW OF THE CRAFT 4.1. JETSURF ELECTRIC DESCRIPTION Grip Battery locks Battery locks Battery locks Battery locks Indicator Binding (Pad and Strap) Motor compartment hood IMG0023 Inspection lid Inspection lid Central lubrication cover Equalizing valve cover Equalizing valve cover... - Page 20 4 OVERVIEW OF THE CRAFT Control handle Control handle Throttle control cord IMG0024 Side FCS fi n Main FCS fi n Main fi n base Jet pump IMG0025 Main fi n base Main fi n FCS plug Main FCS fi n Side FCS fi n IMG0003 IMG0068...
-
Page 21: 4�2� Standard Equipment
Jetsurf ELECTRIC battery A001350 pg. 27 FCS II Performer Black Medium - Side fi n R06Z083 pg. 43 Jetsurf ELECTRIC user's manual Jetsurf ELECTRIC Charger POA1752 pg. 34 Tool kit ELECTRIC POA0185 Novoleen super 32 L1060 - Throttle control cord... - Page 22 4 OVERVIEW OF THE CRAFT TOOL KIT ELECTRIC: ITEM CODE AMOUNT Tool bag Engine shut-off key A000351 pg. 23 Allen key SW 4,0 P006291 O-ring 5 x 2 NBR POP0267 O-ring 10,78 x 2,62 NBR P015097 O-ring 58 x 2,5 NBR P013963 Board cleaning attachment P014339...
-
Page 23: Operating Instructions
5 OPERATING INSTRUCTIONS 5.1. CONTROL HANDLE Jetsurf ELECTRIC comes with a control handle that controls the motor speed. Along with the handle, a magnetic shut-off key with a paracord bracelet is also supplied, which is used to activate and start the Jetsurf. -
Page 24: 5�2� Indicator
5 OPERATING INSTRUCTIONS 5.2. INDICATOR Jetsurf ELECTRIC is equipped with an indicator that signals all states of the motosurf, the signaling of which is necessary for the safe operation of this device. The indicator (A) has the following functions: Signalization: •... -
Page 25: 5�5� Performance Adjustment
5 OPERATING INSTRUCTIONS 5.5. PERFORMANCE ADJUSTMENT Two shut-off keys are required to adjust the motor power. The motor power is set after activating the board’s electronics - the shut-off key is inserted into the control handle and the indicator lights up blue. If the second shut-off key is attached to the indicator in this state, the control unit will start to change the motor power, shown by the color of the indicator: •... -
Page 26: 5�6� Control Unit Error Signalization
5 OPERATING INSTRUCTIONS 5.6. CONTROL UNIT ERROR SIGNALIZATION INDICATOR COLOR SIGNALED ERROR 1x long red, 1x short red Battery Management System Error - BMS. 1x long red, 2x short red Motor regulator error. Fast flashing red Control handle error. 5.7. ERROR EVALUATION OF THE CONTROL UNIT 1x long red, 1x short red - Battery management system error - BMS: The battery is depleted below the usable level and only the 12 V power supply for the board’s electronics is active - the battery management system is switched off. -
Page 27: Battery And Charging
Work that is not described and explained may only be carried out by trained experts from authorized Jetsurf service centers. Your authorized Jetsurf dealer will be happy to help you. Do not open the electric motor or the battery. -
Page 28: 6�2� Inserting The Battery
• Make sure all 4 (four) locks (A) on the battery are unlocked. IMG0035 • Place the battery in the Jetsurf ELECTRIC so that the battery plug (B) and the battery socket (C) are opposite each other (as shown in the fi gure). -
Page 29: 6�3� Removing The Battery
• Unlock all 4 (four) locks (A) on the battery. IMG0035 • Remove the battery. IMG0037 Note The Jetsurf ELECTRIC battery is very heavy. Another person can help you with handling the battery. Warning (Material Damage) Do not touch the battery plug and socket. -
Page 30: 6�4� Protection Of The Socket And Plug Against Damage
• Place the battery socket cover. Then secure it with the battery connector lock. IMG0061 6.5. SECURING THE BATTERY BEFORE TRANSPORT • Each Jetsurf ELECTRIC battery is supplied with a battery bag. This case is intended for safe storage or charging of the battery. IMG0049 •... -
Page 31: 6�6� Battery Cooling System
(2). When riding a Jetsurf ELECTRIC, visually check the correct operation of the cooling system. Water should fl ow continuously out of the cooling system water outlet (2). If you do not see the water, stop riding immediately and inspect the craft. - Page 32 • After a while, the water will start to fl ow out of the inlet (B), which is located at the jet pump. IMG0038A Warning (Material Damage) Don’t forget to put the connector cover on the Jetsurf ELECTRIC before washing the battery compartment.
-
Page 33: 6�7� Charging
Do not use the charger if the cable, connector, or any of its components are damaged or dirty. Warning (Risk of injury) The safety of the Jetsurf ELECTRIC battery is only guaranteed if the original charger is used. The battery may only be charged with the original charger. -
Page 34: 6�8� Standard Charger Equipment
6 BATTERY AND CHARGING Warning (Material Damage) Charging at temperatures above 30 °C (86 °F) may cause the battery to overheat and be damaged. Never charge the battery immediately after riding. Allow the battery to cool fi rst. The charger has sensitive electronics and must be handled with due care. The charger may be damaged or destroyed by falls, shocks or other mechanical overloads. -
Page 35: 6�9� Connecting The Charger And Starting The Charging
6 BATTERY AND CHARGING 6.9. CONNECTING THE CHARGER AND STARTING THE CHARGING • Before each charge, check that the connector pins are not mechanically damaged or corroded. IMG0028A Warning (Material Damage) Do not use the charger if the pins are damaged. Contact an authorized service center. -
Page 36: 6�10� Disconnecting The Charger
6 BATTERY AND CHARGING • Check that there is no obstacle near the cooling inlet of the charger (C). IMG0031 Warning (Material Damage) Insuffi cient heat dissipation during charging may cause the charger to overheat and be damaged. Charging starts automatically when the battery is checked. •... -
Page 37: 6�11� Information Displayed On The Charger Display
6 BATTERY AND CHARGING 6.11. INFORMATION DISPLAYED ON THE CHARGER DISPLAY • When the charger is connected to the mains, the display lights up and after a while shows that it is ready for charging. At this point, it is possible to enter the charging mode setting by long pressing the button (D). -
Page 38: 6�12� Acoustic Warning Signals
6 BATTERY AND CHARGING 6.12. ACOUSTIC WARNING SIGNALS The charger is equipped with an acoustic error indicator. The following errors can be signaled: • 1x long tone, 1x short tone - High battery humidity (> 80%) • 1x long tone, 2x short tone - High battery pressure (> 1400 hPa) •... - Page 39 6 BATTERY AND CHARGING 1x long tone, 5x short tone - High temperature battery management sys- tem - BMS: The battery management system is overheated, disconnect the charger from the battery. If the battery has been overheated during handling and storage in direct sunlight, store the battery in a cool place away from sunlight and wait for the battery to cool sufficiently.
-
Page 40: Routine Maintenance Table
7 ROUTINE MAINTENANCE TABLE... - Page 41 7 ROUTINE MAINTENANCE TABLE...
-
Page 42: Before Riding
Warning (Danger of accident) Before attempting the fi rst ride without the supervision of an authorized dealer or Jetsurf trainer, make sure that you have read and understood the manual that comes with the Jetsurf ELECTRIC. Familiarize yourself with the laws that apply to the waters where the motosurf will be operated. -
Page 43: 8�3� Side Fins
The stand opens. IMG0074 Warning (Material Damage) Before placing the Jetsurf on the stand, make sure that all the feet of the stand are touching the ground and are on a solid surface so that the stand does not tip over. -
Page 44: 8�4� Main Fin
• Screw the main fi n FCS plug to the main fi n base with four screws. IMG0069 Note Use the screwdriver that comes with the Jetsurf ELECTRIC • Unscrew the locking screw from the main FCS fi n plug. IMG0072 •... -
Page 45: 8�5� Bindings (Straps)
Screw the main fi n screws into the fi n base (without the main fi n fl ange and main fi n) during transport. 8.5. BINDINGS (STRAPS) • Jetsurf ELECTRIC has a fully adjustable binding that can be tightened or loosened. Make sure the binding fi ts comfortably and is not too loose or too tight. -
Page 46: 8�6� Binding Adjuster
8 BEFORE RIDING 8.6. BINDING ADJUSTER Note The binding adjuster is an above-standard equipment of Jetsurfs. The binding adjuster is used to rotate and move the binding according to the customer's needs. The binding adjuster is only compatible with two-tap binding. The binding adjuster contains: 1 - 2x Carbon binding adjuster - Top 2 - 2x Carbon binding adjuster - Bottom... -
Page 47: 8�7� Basic Motosurf Check Before Riding
To check the battery status, it is always necessary to activate the Jetsurf ELECTRIC in riding mode or connect the Jetsurf ELECTRIC battery to the charger, which indicates the battery status on the built-in display. - Page 48 8 BEFORE RIDING CHECKING THE PRESENCE OF WATER IN THE MOTOR COMPARTMENT Warning (Risk of injury) To prevent possible electric shock, always remove the battery from your Jetsurf ELECTRIC before inspecting the motor compartment. • Unscrew the motor compartment cover. 4 screws.
- Page 49 8 BEFORE RIDING Warning (Material Damage) If the balancing valve is clogged, replace it. CHECKING THE BATTERY PLUG RUBBER • Before inserting the battery into the board, visually make sure that the rubber band around the battery plug (A) is intact and in place.
- Page 50 8 BEFORE RIDING JET PUMP CHECK • Before riding, check the cleanliness and condition of the Jet pump (C). Its condition can result in decreased performance of the motor board. IMG0045 Warning (Risk of injury) Under no circumstances insert your fi ngers or other objects into the Jet pump unless you are absolutely sure that the motor board is not switched off and without the possibility of starting!
-
Page 51: During The Ride
60 °C (140 °F). An increase in temperature can damage the Jetsurf. Keep in mind that the Jetsurf is not intended or designed as a fl otation device. Do not leave the motorized surfboard unattended or in the water without the motor running for a long time, there is a risk of it sinking. -
Page 52: 9�2� Jetsurf Start-Up Process
For a sharp start in the water, it is essential to fi nd a suitable place to start riding. The water from which the Jetsurf will take off must be of suffi cient depth, otherwise there is a risk of damage to the fi ns. The minimum depth is 50 cm. Keep in mind that after accelerating the motor and jumping on the boat, the back of the board can sink by 10-20 cm. -
Page 53: 9�3� Start From The Shore (In Shallow Water)
• As soon as the indicator starts to indicate the battery status, it is possible to press the throttle trigger of the control handle to which the motor will respond at this time. • The rider jumps on the Jetsurf the moment the board starts to accelerate. IMG00AE... -
Page 54: 9�4� Start From Deep Water Or After A Fall
If, after a fall, the rider manages to insert the shut-off key into the control handle socket within 5 minutes, the Jetsurf will go into the active phase and the motor will start responding to the throttle trigger depressed by the control handle. -
Page 55: 9�5� Learning How To Operate Control Handle On Jetsurf
During the very fi rst ride, the rider should master control of the control handle and acceleration. For Jetsurf, this is a key skill. The rider can remain supine or kneeling. Only when he is sure of the throttle control and how to control it can the rider go and try to stand. -
Page 56: 9�8� Stops / Falls On Jetsurf
9.8. STOPS / FALLS ON JETSURF If the rider wants to stop, he must fi rst reduce the speed of the Jetsurf before the stopping point. As soon as the driver is close enough to the stopping point, he pulls the shut-off key out of the control handle socket. -
Page 57: After The Ride
10 AFTER THE RIDE 10.1. BRIEF CHECKLIST AFTER RIDING 1 - Tilt the Jetsurf ELECTRIC with the cooling water outlet down and pour out the water. 2 - Remove the battery and put on the connector cover. 3 - Check that there is no water at the bottom of the motor compartment. - Page 58 5 - Cooling system - If the motosurf was operated in salt water, rinse the cooling system with fresh water. IMG0007A After removing the battery and attaching the battery connector cover to the Jetsurf ELECTRIC, also do not forget to rinse the area where the battery is stored.
-
Page 59: 10�4� Motor Compartment Cover Maintenance
ELECTRIC before inspecting the motor compartment. Warning (Material Damage) If there is water inside the motor compartment, do not use the Jetsurf and contact an authorized service center. Try to get the water out of the board, for example by turning the board upside down. -
Page 60: 10�5� Turning Off
Warning (Risk of injury) Never leave the shut-off key in the control handle socket after riding. Warning (Material Damage) Never remove the battery from the board unless the Jetsurf is completely switched off . This could damage the electric motor. -
Page 61: Storage
11 STORAGE 11.1. SHORT-TERM STORAGE For short-term storage, for example between riding days, it is suffi cient to follow the steps described in chapter 10, “After the ride”. After performing these steps, store the motosurf in a dry place. Notice (Material damage) Be sure to remove the battery from the board and charge it to at least 30% (Travel Charging Mode). -
Page 62: User Maintenance
From this point, tighten the valve by 180° by hand. • The expansion valve can be ordered from your authorized Jetsurf dealer. IMG0052 12.2. DRAINING WATER FROM THE BOARD Water can enter the space of the outer airbox (the space between the outer and inner wall of the board) by air condensation, or in the case of damage to the waterproofi ng of the board. -
Page 63: 12�3� Refilling Of Central Lubrication Vaseline
Warning (Material Damage) Observe the amount of water fl owing out. If there is a large amount of drained water, contact your Jetsurf dealer and do not ride your Jetsurf. The cause may be damage to the board. Warning (Material Damage) Never start riding without the drain plugs screwed in. -
Page 64: 12�4� Battery Plug Rubber Replacement
We recommend using a mixture of vaseline (Isofl ex LDS 18 Special A) and oil (Motorex Ocean FS 2T Bio) in a ratio of 7:4 (100 g of vaseline per 57 ml of oil). A mixture of Vaseline and oil can be purchased from an authorized Jetsurf service center. 12.4. BATTERY PLUG RUBBER REPLACEMENT •... -
Page 65: Transport
Notice The battery cannot be transported in your hand luggage. Note Your Authorized Jetsurf Dealer will be happy to help you transport your battery or board. 13.2. TRANSPORT TO THE SERVICE CENTER Before transport, contact an authorized service center about the fact that you are going to send your surfboard. -
Page 66: Technical Information
14 TECHNICAL INFORMATION DESCRIPTION Length (mm) 1800 Width (mm) Height (mm) Weight without bindings (kg) 33,9 Number of passangers One rider Maximum load (kg) Category* Ride duration 25 - 45 min Max speed 55 km/h (34 mph) MOTOSURF CONSTRUCTION Hull 100% Carbon composite BATTERY Battery type... - Page 67 The prescribed service work was performed in full according to the most up-to-date service checklist and was documented in the Jetsurf system. Only original Jetsurf spare parts or spare parts and accessories approved by Jetsurf were used in the service work.
- Page 68 The prescribed service work was performed in full according to the most up-to-date service checklist and was documented in the Jetsurf system. Only original Jetsurf spare parts or spare parts and accessories approved by Jetsurf were used in the service work.
- Page 69 The prescribed service work was performed in full according to the most up-to-date service checklist and was documented in the Jetsurf system. Only original Jetsurf spare parts or spare parts and accessories approved by Jetsurf were used in the service work.
-
Page 70: Warranty
2 - The manufacturer will assess the alleged defect (complaint) within 90 days from the date of delivery of the Jetsurf to his hands and will notify you of the result of the complaint, either himself or through the authorized dealer from whom you purchased the Jetsurf from. -
Page 71: Section 3. Exclusions And Limitations Of Warranty
Damage or necessary modifications caused by items that are added, altered, or altered after Jetsurf is no longer owned by the manufacturer, as well as any modifications, alterations, unauthorized repairs or replacements of components, motor or Jetsurf after ownership by the retailer e. -
Page 72: Section 4. Local Warranty Specifications
Section 5. DISPUTES 1 - All disputes arising out of the rights from the Jetsurf Warranty should be settled out of court as a matter of priority. Contact us and let us know what you are not satisfied with in regard to the warranty solution. - Page 73 8. Enter the water WITHOUT reading the user manual. If I did not understand something as a user, I contacted an authorized Jetsurf dealer. 9. Enter the water WITHOUT checking that the Jetsurf is working as expected and as described in the user manual.
- Page 74 The language version that has been handed over to the owner together with Jetsurf, usually in the language of the country to which it is delivered to the Jetsurf owner, is always decisive for the validity and correctness of the operating instructions, unless otherwise agreed between the manufacturer / importer / seller and the owner.
- Page 75 8. Enter the water WITHOUT reading the user manual. If I did not understand something as a user, I contacted an authorized Jetsurf dealer. 9. Enter the water WITHOUT checking that the Jetsurf is working as expected and as described in the user manual.
- Page 76 The language version that has been handed over to the owner together with Jetsurf, usually in the language of the country to which it is delivered to the Jetsurf owner, is always decisive for the validity and correctness of the operating instructions, unless otherwise agreed between the manufacturer / importer / seller and the owner.
-
Page 77: Notes
16 NOTES... - Page 78 16 NOTES...
