PacketMAX : Advanced Aggregator
TM
Quick Start Installation Guide
By Garland Technology
Model#: AA1G52ACV2, AA10G54AC, AA100G32AC and AA100G64AC

Installation Guide

● To Deploy the PacketMAX Advanced Aggregator System into the network, the following steps apply:
● Carefully un-pack the Unit and install it into a 19" equipment rack. Will require 1U of Rack space.
● You will need 2 AC connections to apply power to the two internal power supplies.
● Connect a power cable to each of the AA System's power supplies and plug them into an available power
source. Garland Technology recommends plugging the cables into different power sources in case one
should fail the other may not.
NOTE: The power supplies are redundant, and the system will operate with a single supply connection.

Initial Turn Up

The units are shipped with a default IP Management Address (10.10.10.200). Use the following procedure to change the IP
Management Interface address and launch the GUI.
1) Connect a Serial cable from a COM port on the laptop or PC to the Console Interface on the AA.
2) Launch Putty and configure the Serial connection options as follows.
Garland Technology | 716.242.8500 | garlandtechnology.com/support
Copyright © 2021 Garland Technology, LLC. All rights reserved.
QUICK START GUIDE
Advanced Aggregator | Firmware Rev Level: 3.2.1.x
