- Page 1 Whiz New Functions SW 1.14.28 Version Release Note THANK YOU FOR USING OUR AI CLEANING COBOT WHIZ. BRAIN OS (VER1. 1 4.28) INCLUDES UPDATES AS FOLLOWS: NEW FUNCTIONS • Route Sequencing • Delay Start • Home Position Check HOW TO UPDATE...
- Page 2 Route Sequencing Function (1/4) This function will allow the user to select multiple routes to be cleaned consecutively. 4 routes created by Whiz with the same HLC. When route A & B are selected When route A&D are selected TIPS •...
- Page 3 Route Sequencing Function (2/4) UI Flows for Route Sequencing Function: Select multiple routes to be cleaned Read Tap “CHOOSE MULTIPLE” Tap “NEXT” Tap “CANCEL” Home screen Ready to start...
- Page 4 Route Sequencing Function (3/4) The images below show what will be on the display screen during autonomous cleaning: When the 1st route is finished When the 2nd route is finished ROUTE ROUTE ROUTE AFTER THE CLEANING OF A ROUTE FINISHES, THE NEXT ROUTE MAP WILL BE DISPLAYED.
- Page 5 Route Sequencing Function (4/4) Cleaning Complete Screen of Route Sequencing After finishing all the routes, the last route information will be displayed Results of the other routes can be displayed by swiping the screen. ROUTE ROUTE ROUTE...
-
Page 6: Delay Start Function
Delay Start Function (1/3) This function will allow the user to be able to set a desired time delay for a machine to start autonomous cleaning. STEP 1.) STEP 2.) STEP 3.) After scanning the home location code, click Whiz will countdown until it reaches the time it was When the time comes, Whiz will automatically “delay”... - Page 7 Delay Start Function (2/3) UI Flows for Delay start Function: BACK DELAY CONFIRM NEXT CANCEL More CANCEL than 7hrs YES - CANCEL...
- Page 8 Delay Start Function (3/3) After setting the timer, a message will pop up to confirm that the battery is fully charged. This is not a battery check, it is just a warning screen.
- Page 9 Home Position Check Function (1/3) This function will request you to re-scan the Home Location Code (HLC), if the machine was moved after scanning HLC the first time. STEP 1.) STEP 2.) When Whiz is accidentally moved after it scans the HLC, a message will If you click “scan”...
- Page 10 Home Position Check Function (2/3) UI Flows for Home Position Check: “YES” to read HLC again BACK...
- Page 11 Home Position Check Function (3/3) UI Flows for Home Position Check using Delay Start: BACK Set the time to start Whiz is moved CANCEL autonomous cleaning while standing by Whiz not back to the original position by the time it is up. Error message would appear in case the user sets the start...
-
Page 12: How To Update
How to Update Press the main When the Machine Turn the power off, Check whether the power switch (I/O) is connected to the then reboot. software version to turn the Machine Robot Operations has been updated *Whiz may take up on (I).
