- Page 1 PNT2001OBDHD SERIES QUICK INSTALL GUIDE PNT2001OBDHD24 1.855.287.4477 8AM - 5PM Monday to Friday MT CERTIFIED TRACKING SOLUTIONS 12-24V Thank-you for your purchase! You’ve made a smart decision. Please follow 5 QUICK STEPS shown in this guide.
- Page 2 PNT2001OBDHD Determine Installation Options Connect OBD/JBUS(Optional) Depending upon the requirements, the device can be installed with Refer to the PNT2001OBDHD/JBUS Connections on the following page following options. Confirm LED Status Type1: Device Only Type2: PNT2001OBDHD with Starter Kill/input/output Orange : Flashing Connected/Online Type3: PNT2001OBDHD with DRIVER ID Green...
- Page 3 PNT2001OBDHD Type 3 : PNT2001OBDHD with Driver ID DRIVER iD PANEL MOUNT SCANNER White - Key Ignition Source (+) Green - Starter Disable Out (-) Black - GND Grey - iButton Input Red (12-24V+) - Constant PNT2001OBDHD Fuse DRIVER iD 1.
- Page 4 PNT2001OBDHD OBD II Installation JBUS Installation Plug the 24-Pin Connector into the device. Plug the 24-Pin Connector into the device. Connect the male end of the direct connect cable to the Connect the male end of the direct connect cable to vehicle OBDII port.
