Download from tachograph
If during the data retrieval the device beeps 4 times and the progress bar moves back to the beginning, this
means that the reading of data will be continued by
"old" type of tachograph, where the data download can take up to one hour.
If during data retrieval red LED located in the center of the label lights up for about 4 seconds, and in this
time the device sounds three short beeps, then it goes off for about 2 seconds (repeatedly), this means an
error occurred - refer to the
5. End of data download will be signaled by the device by repeated beeps and flashing
the progress bar.
6. Disconnect TR Combo Plus from the tachograph and remove the company card.
. The data is saved to a file (Vehicle reg.no.
7
placed in the TACHO folder in the device memory.
Do not delete files from the LOG directory in the device memory.

7.1. Download special speed data

Some tachographs record special speed data (except the data specified in the Regulation 3821/85).
Requirements:
1. Continental VDO tachograph version 1.3 or higher
2. The device for downloading data from the tachograph: TachoReader Combo Plus , with serial
number that ends with the letter "A" , "B" i "AT" .
The serial number can be found on the label placed on the bottom of the device.
3. In the configuration window, for the selected button, select:
tachograph (S-file) option (Fig. bellow)
selected by default)
The special data include :
· Detailed data 4/sec, that is:
ast three records (high resolution - frequency: four values/second) of two-minute speed periods,
§ L
in which there was an unnatural speed change in a short period of time
ast three records (high resolution - frequency: four values/second) of two-minute speed periods,
§ L
in which there was a sudden, high change in speed
Speed history of the last 168 hours of driving recorded with a frequency of one second
·
TR Combo
"Error codes " topic.
20
Date and time of data download.DDD), which is
_
and decide which special data to download (all
at a lower speed. This can happen on the
Speed data from VDO
EDs on
L
14
