4020 OPERATORS MANUAL
BRIGADE
0 No test facility
1 Alarm relay ACF2 (Ct2) operates for 10 seconds
2 Alarm relay ACF2 (Ct2) operates for 15 seconds
3 Alarm relay ACF2 (Ct2) operates for 20 seconds
4 Alarm relay ACF2 (Ct2) operates for 25 seconds
5 Alarm relay ACF2 (Ct2) operates for 30 seconds
6 Alarm 1 relay ACF2 (Ct2) operates for 20 seconds Delay
for 20 seconds . Alarm 2 relay ACF3 (Ct3) operates for
20 seconds
7 Alarm 1 relay ACF2 (Ct2) operates for 20 seconds Delay
for 20 seconds. Alarm 2 relay ACF3 (Ct3) operates for 20
seconds Delay for 20 seconds
Alarm 3 relay ACF4 (Ct4) operates for 20 seconds
Table 1.2 - Available Brigade Test Options
Document No: 4020-M010
DESCRIPTION
1st February, 1997
Page 35
Issue 2.0
