4020 OPERATORS MANUAL
SPECIFICATION (CONTINUED)

3.5 KEYPAD CONTROLS

Fire Fighters Keypad
Service Technician
Keypad

3.6 PROGRAMMING FUNCTIONS

Input Zone Type
Zone Labels
Output Control

3.7 COMMUNICATIONS PORT (optional)

Type:

3.8 EXPANSION CARDS

8 Input Monitor Card
4 Point Control Card
Document No: 4020-M010
NEXT, ACKNOWLEDGE, RESET, ISOLATE, BRIGADE
TEST
20 keys including:- Alarm Test, Fault Test,
Isolate, Battery Test and Lamp test
Normal, Alarm Verification, AS1668 - 30sec or 60 sec
Latching/non-latching
Maximum 27 characters
Input list conditions, delay time, Door Isolate
Serial, 1 x 2120 DC Comms and 1x RS232 Printer port
OR
Serial , 1x Mimic and 1 x RS232 Printer port
8 alarm zone circuits
4 x N.O. Voltage free relay contacts (2A @ 30V dc)
supervised or unsupervised.
