3 SPECIFICATION

3.1 GENERAL

System Capacity
Cabinet Size(mm)
Cabinet Material
Cabinet Finish
Cabinet Colour
Mounting
Shipping Weight
Mains Input
Internal Power Supply
Standby Battery
Battery Charger
PSU Supervision
Temperature
Humidity

3.2 INPUTS

Detector Circuits
Maximum detector
quiescent current
Door Switch
Other

3.3 OUTPUTS

Bell
Brigade(2)
Ancillary(2)

3.4 INDICATORS and DISPLAY

Zone Status
LED Status Indicators
Audible Buzzer
Document No: 4020-M010
Minimum 8 Alarm Zone Circuits
Maximum 48 Alarm Zone Circuits
Up to 24 Zones
24 - 48 Zones
1.5mm Mild grade steel
Powder coated
Magnolia Ripple
Wall mount
14Kg (without batteries)
240V AC, +6%,-10%,50Hz
24V DC @ 1.5A, or 24V DC @ 4.5A
24V sealed lead acid 7Ah or 12Ah
27.6V DC (nominal) @ 0.6A,
Charger high/low,Battery low/fail
-5°C to 45°C
10% to 90% rh non-condensing.
Standard 20V detectors
2.4mA
Bell Isolate, ACF Isolate
Supervised door mounted Manual Call Point
Supervised 24V DC @ 1.5A
Voltage free relay contacts (2A @ 30V dc) N.O. or N.C.
Power Fail(Fault), Master Alarm
Voltage free relay contacts (2A @ 30V dc) N.O. or N.C.
2 line by 40 character backlight Liquid Crystal Display with
adjustable contrast control
Common Alarm, Fault and Isolate
Bell Isolated, ACF Isolated, Mains Power ON
Alarm And Fault Indications
Keypress feedback
1st February, 1997
: 440H x 500W x 140D
: 400H x 535W x 180D
Issue 2.0
