AERIAL PHOTOGRAPHY DRONE 720P CAMERA CAMERA GIMBAL
USER MANUAL
1
MAIN FEATURES
●Special 4-axis structure - fast and agile. Suitable for flying in
spacious indoor and outdoor areas.
●Built-in 6-axis gyroscope, barometer and optical flow sensor ensures
accurate position hold.
●Capable of doing 360 degrees stunts.
●Headless mode for easy flying.
●Auto take-off and landing - easy and safe flying.
●HD camera - enjoy aerial photography with real-time WiFi video
transmission.
●Trajectory Flying - new smart phone application feature.
Notice: The company will not be held responsibly for any printing
inconsistencies and may or not inform end users regarding any new
potential updates.For further information, please vistit the syma
website.
GYRO REMOTE CONTROL SERIES
25W
HEIGHT HOLD OPTICAL FLOW SENSOR
12+
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SYMA X25W
Summary of Contents for SYMA X25W
- Page 1 ●Trajectory Flying - new smart phone application feature. Notice: The company will not be held responsibly for any printing inconsistencies and may or not inform end users regarding any new potential updates.For further information, please vistit the syma website.
-
Page 2: Safety Guide
Safety Guide 1. Please, keep the small drone accessories out of reach of children. 2. This drone is very powerful. When flying for the first time, avoid sudden movements of the throttle. When ascending push the throttle stick slowly up to avoid unintended damages or injuries. -
Page 3: Installing The Camera
Box Contents Items included: ●Blade Protective Guard X4 ●Drone ●Mobile Phone Mount ●Transmitter ●User Manual ●Blades X4 ●USB Charger Installing the Blades and the Blade Protective Guards Installing the blades To remove the blades, press down on the blade nut and rotate the blades marked “A”... -
Page 4: Uninstalling The Camera
Uninstalling the Camera 2.Gently lift the camera and after 1.Rotate the camera clockwise. unplug the camera’s wires from the drone. Installing the Mobile Phone Mount 1. To remove the mobile 2. To install the mobile 3. To adjust to phone phone mount, pull it phone mount, insert it holder to the required... -
Page 5: Transmitter Functions
3. Insert the battery into the charging cradle. Plug the USB into a power outlet. When charging, the charging light will glow red and the cradle’s light will be green. Unplug the charger when the lights go off. Charging time: about 150 minutes. Warning: only standard 5V chargers are safe to use (input of 2A). -
Page 6: Installing Transmitter Batteries
Camera's Up angle control (pitch control) Video 3D Stunt Picture Auto take-off and landing Camera's Down angle control (pitch control) Installing transmitter batteries: Battery cover 4 x AA Batteries Transmitter battery installation: open the battery cover at the back fo thhe transmitter. - Page 7 Step 3: Turn on the drone Step 4: Move the left stick (throttle) fully up and after fully down. The drone indicator lights will turn solid (glow) indicating the drone is ready to fly. 2.Arming Motors Method 1: Move the left stick (throttle) fully up, after let it come back to the middle and the motors will start spinning.
- Page 8 Method 2: Push both sticks at the same time (left stick to the bottom-right corner and the right stick to the bottom-left corner) and hold for 1 second and the motors will stop spinning. Method 3: After the drone is in stable hovering position, press the B button and the drone will slowly land.
-
Page 9: Product Features
Trimming Forward/Backward Trim Control If the drone drifts quickly forward or backward while hovering, please adjust forward/backward trim. Press the left stick and hold it, then move the right stick forward/backward until the drone starts hovering as normal. Left/Right Trim Contro If the drone drifts quickly to the left/right Front while hovering, please adjust left/right... -
Page 10: Pictures & Videos
4. Low/High Speed Mode: Low speed mode is the default mode. To change the speed mode gently press the right stick once, the transmitter will emit two beeps indicating high speed mode. Gently press the right stick again and the transmitter will emit one beep indicating low speed mode. - Page 11 8.Optical Flow and Height Hold: ①Optical Flow The optical flow sensor is automatically activated after the drone is turned ON. Hover the drone at the desired place and the optical flow sensor will hold the drone’s position. Note： 1. The position precision hold is approximately 0.5 meters, though deviation may occur.
-
Page 12: Smart Phone Application
Android: Please download and install the software SYMA FLY from www.symatoys.net or scan the QR code. IOS: Please download and install the software SYMA FLY from App Store, or scan the QR code. Tips: QR codes can be found on the packaging box or at the last page of the user manual. - Page 13 This device must not be collocated or operating in conjunction with any other antenna or transmitter.” Decoration of Conformity lnserts: “Hereby, GuangDong Syma model aircraft lndustrial co.,ltd, declares that this drone is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU.”...
- Page 14 Accessories /Parts (Optional) Please, look through the parts below. For your convenience, we have specified every part and accessory. The parts and accessories can be purchased through local distributors. Please specify desired colours at the time of purchase. Blade Body(black) Body(white) Landing Gear(white) Battery Storehouse...
- Page 15 Product Main Parts and Components Component/ Component/ Component/ Serial Serial Serial Quantity Quantity Quantity number Part Name number Part Name number Part Name Top Main Body Battery Storehouse Landing Gear LED Light Protective Bottom Main Body On/Off Button Cover Clockwise LED Ligh Inner Shell Blades...
-
Page 16: Main Specifications
Main Specifications 110mm 375mm 375mm Drone length: 375mm Drone width : 375mm Drone height: 110mm Motor Size : 10x20 Ø Battery : 7.4V 1000mAh lithium battery TroubleShooting Problem Reason Solution 1. The drone has activated low-voltage The drone does battery protection. 1. - Page 17 Problem Reason Solution Re-set forward direction. Please When in headless Numerous crashes. relate to page number 10. mode the forward direction deviates. 1.Perform balance calibration. Please relate to page number 8. 1. Balance calibration is needed. 2. Avoid flying the drone in severe The drone does 2.
- Page 18 Android APP iOS APP Manufacturer: Guangdong Syma Model Aircraft Industrial Co., Ltd. Address: No 2 West Xingye Road, intersection of North Xingye Road, Laimei Industrial Park, Chenghai District, Shantou City, Guangdong Province, China. Postal Code: 515800 Sales department：+86 0754 86980668 After-sales service: +86 0754 86395095 Fax: +86 0754 86395098 Website: www.symatoys.net...
