VIESMANN
Installation and service
instructions
for contractors
Vitocal 350-G
Type BW/BWS 351.A18
Brine/water heat pumps with electric drive, 1 and 2-stage
For applicability, see the last page
VITOCAL 350-G
Please keep safe.
5546 267 GB
6/2014
