Commax CDL-1AR User Manual page 8

04
Convenient Function (Option)
Sound pause function
This function is for One time mute to prevent beeping.
How to use
① Outside touch plate , press [ # ] button. (without sound)
② How to use password :
After touch password , press [ ] button and then the door
is open (Blinking the lamp)
Smart key use :
③
When you touch [Smart Key], the door opens
Because it is a one-time function,
an operation sound is generated at the next use.
NOTE
Volume control
This function is to control volume level. (In case door closes)
How to use
※There are 7 levels to control.
1 2
After touching
Enter [password]
outside number
plate
On outside number plate, touch [3] button several time, volume
up. touch [6] button several time, volume down. When entering
NOTE
Stop volume function, keypad Blink.
14
Digital Door Lock COMMAX
3 4
Press [3] or [6]
press [ # ]button
on outside
number plate.
Automatic • Manual lock setting
This is an optional feature that locks doors automatically or manually.
Automatic•Manual lock
With the door half open
1 2
Press the [Open /
Touch the
Lock] button on the
indoor side to release outdoor plate.
the Mortis square lock
If you purchased the product for the first time, it is set to Auto-Lock.
When the manual lock is set, the door is not locked even when the door
is closed. Press the [Open / Lock] button or touch [Plate] of the outdoor
NOTE
body to lock the door.
Smart card automatic • Manual detection settings
This function sets the smart card to be detected automatically or manually.
1 2
Touch the outdoor
Enter password.
license plate.
If you touch the smart key contacts during automatic detection
①
setup, you can open the door.
② When manual detection is set, you can open the door by touching
NOTE
the license plate and touching the smart key contact.
3 4
After inputting
[4] : Auto lock
the password,
[7] : anual Lock
press the [ # ]
Feature settings
button twice.
3 4
[1] buttton:
Auto detection
press [ # ]button
[3] button:
manual detection
15
