MANUAL INSTALL CDL-88P ENG
[Outdoor Side]
Outdoor Body
D
E
F
[Door]
Mortise
* If the door is thick, it can be
installed using (B) M5 X 40, (F).
[Indoor Side]
(Up to 80mm can be installed)
* To fasten the door lock and door
tightly, use screws (D) and (E).
D
D
D
Indoor Pad
Indoor Plate
E
Indoor Body
