COMMAX CO.,Ltd.
Thank you for purchasing COMMAX products.
•
Please carefully read this User' s Guide (in particular, precautions for safety) before using a product
•
and follow instructions to use a product exactly.
The company is not responsible for any safety accidents caused by abnormal operation of the product.
•
Digital Door Lock CDL-30LR / 30LRC
U s e r M a n u a l

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDL-30LRC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Commax CDL-30LRC

Summary of Contents for Commax CDL-30LRC

  • Page 1 Digital Door Lock CDL-30LR / 30LRC U s e r M a n u a l COMMAX CO.,Ltd. Thank you for purchasing COMMAX products. • Please carefully read this User’ s Guide (in particular, precautions for safety) before using a product •...

  • Page 2: Product Feature

    Product Feature Durable door lock without A/S We produce this door lock under strict quality assurance systembased on KS certification Durable body using metallic material We design the durable body using metallic material for suitable for fire or impact Automatic lock / Re-lock / Double lock functions We think the customers security and convenient so it is easy to use and very safety.
  • Page 3 Warning Don’t install, repair or This devise is for the Use the device after fire door products, disassemble the reading the user so it may not operate device randomly. manual. for other environment normally. To Change the Don’t impact on Don’t push or insert pin-number regularly the device.
  • Page 4 Product Feature Specification & features Part names How to use Setting the Pin-number Setting the electronic-key Deleting the electronic-key Opening the door at outside Locking the door at outside Opening the door at inside Locking the door at inside Locking the door by force Setting &...

  • Page 5: Specification & Features

    Under 10mW For safe system Features Remote controller User manual Outer body Inner body (CDL-30LRC only) Mortise Sticker Screws Emergency key 2 pcs Battery 8 pcs Warning sticker Drawing for screw hole Electronic key 4 pcs Outdoor shaft (Key type only)

  • Page 6: Part Names

    Part names Outer body Emergency 9v battery (not supplied) Name Feature To use to register or change the pin number. Key buttons You can open the door with registered pin number. Electronic keyhole You can open/register the electronic key. Battery warning light Light will be on with low power with warning sound.
  • Page 7 Inner body Name Feature Battery cover Cover for battery and buttons for registration of pin number & electronic key. Registration button Using registration or change the pin number or electronic key You can lock the door and it can’t be opened at the outside such Button for double as night time.

  • Page 8: How To Use

    How to use Setting the Pin-number Warning! Please set the pin number while you open the door. Open the battery cover, Push the registration button once then you can hear “Beep” sound Go to outside Lift up the cover of keypad and check the lights on in the keypad.
  • Page 9 Setting the electronic-key. Warni n g! If you register or re-register new electronic-keys, you need to register all electronic-keys at once. Open the battery cover, Push the registration button once then you can hear “Beep” sound. “Beep” “Beep” Go to outside Lift up the cover of keypad Outside Contact the electronic-key to the...
  • Page 10 How to use Deleting the electronic-key Open the battery cover, Push the registration button once then you can hear “Beep” sound. “Beep” “Beep” Go to outside Check the light of key numbers. Outside 5 sec. Push the buttons for 5 seconds, all the electronic-keys will be deleted with the sound.
  • Page 11 Opening the door at outside No.2 Using electronic key Contact the registered electronic key to the receiver. You can hear the sound and open the door Locking the door at outside No.1 In the case of setting the automatic lock The door is locked automatically after 2 seconds when you close the door.
  • Page 12 How to use Opening the door at inside Warni n g! If you do not open the door within 7 seconds after you pull the inner body’s SEC. handle down, the door will be locked automatically. No.1 Pull the handle down The door is locked, you can open the door with pulling the inner body’s handle down, you can open the door.
  • Page 13 Locking the door by force Inner double lock Disable to use pin number or electronic key outside of room Setting SEC. When the door is locked, Push the [Double lock] button for 3 seconds in inner body, the setting is completed with sound. Cancel It will be cancelled if you open the door to pull the inner body’s handle down.
  • Page 14 Convenient functions(Optional) Setting automatic door lock This is the optional function to lock the door automatically. Setting While you open the door Enter the pin-number After putting out Enter the [4] button, Touch the key of the inner body’s the automatic door button outer body mortise...

  • Page 15: Setting The Sound Volume

    Setting the sound temporary pause You can set the sound temporary pause at once whatever you set the sound volume. Setting Touch the outer body’s key and push the ] button.(You can’t hear any sounds) Enter the [Pin-number] (Only the lamps will be blinking) Note This is for only once, you can hear the operating sound in next time.
  • Page 16 Convenient functions(Optional) RFID automatic / manual detecting Electronic key can be detected by automatically or manually. Setting for automatic detecting Push [1] button, the automatic Touch the outer Enter the Push [ detecting function body’s key pin-number button twice will be activated with sound.

  • Page 17: Remote Controller

    Remote controller You can open the door with remote controller.(Remote controller model only) Setting Open Register “Beep” Push the [*] button, Open the inner body’s Push the [Register] or battery cover, push the the registration will be [Open] button on the [Register] button completed with sound.

  • Page 18: Emergency Alarm

    Emergency alarm Detecting high-temperature If the digital door lock detect the high-temperature (62℃±5℃) just like firing, it unlock the door automatically with warning sounds for safety. Alarming the break-in If the digital door lock detect the opening the door abnormally, under the door is locked, there is the warning alarm more than 80db.(For example, the door open by force) Disable the warning of high-temperature &...
  • Page 19 Alarming the jam of square catches There will be “Bee, Bee, Bee, Bee” warning sounds for 3 times when the square catches(Dead volts) can’t operate in-and-out normally or jammed. Dead volts (Square catches) If the warning sounds keep ringing or operate abnormally, Warni n g! you may need to move the location of the digital door lock.
  • Page 20 Emergency alarm Emergency power Note If you can’t open the door when the batteries run out completely, Buy 9 V While contacting Push [ After Push the the battery to ] button, alkaline button entering the terminal of the door will be battery pin-number emergency...
  • Page 21 Cause of disorders & Solution Please check the details as below when the product is operating abnormally. Problem Check Page Please check the batteries are disables or insert right directions. Please check if the batteries run out completely There is no Power. or insert right directions.
  • Page 22 COMMAX CO.,Ltd. 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. Tel. : +82-31-7393-540~550 Fax. : +82-31-745-2133 Web site : www.commax.com Printed In Korea/ 2014.04.106...
