General Operation - Dual USER MANUAL Installation & Owner's Manual

XD6200

General Operation

Faceplate Removal
Power On/Off
Bass Boost
Programmable
Turn-On Volume
Confirmation Beep
Preset EQ Curves
Set the Clock
12/24-hour Clock
6
OPERATION
Press REL and pull away from the left side to remove.
To re-install, insert right side of faceplate first then push
left side to secure.
*For semi-permanent faceplate installation, remove trim ring and install
supplied Phillips head #1 screw through left side of mounting frame into
faceplate.
Press PWR or any other button (except eject) to turn the unit
on. Inserting a CD will turn the unit on automatically. Press
PWR to turn the unit off.
Mode
Press MODE to select between tuner, CD player and auxiliary
input. Modes of operation are indicated in the display.
Press BASS to activate and deactivate bass boost curve.
Activating this feature will enhance the bass frequencies
when listening to music at all volumes.
Volume
Adjust volume using rotary encoder (00-46).
Press and hold PWR for 3 seconds to program currently
selected volume level.
Press rotary encoder for 3 seconds to turn confirmation beep
on/off.
Mute
Press MUTE to silence the audio. Press MUTE again to cancel.
Press EQ to select between POP, JAZZ, CLASSIC, BEAT, ROCK
and OFF (default) equalization curves. Individual Bass/Treble
adjustment is not possible when an EQ curves is selected.
Display
Press DISP to select between clock and radio frequency
(tuner mode) or CD track/elapsed time (CD player mode).
With the unit on, press and hold DISP until clock begins to
flash, then release. Press TUNE
TUNE
to save the selected time.
The clock will display 12-hour AM/PM time in U.S. frequency
spacing mode (AM 6:00). In European frequency spacing
mode, the clock will display 24-hour time (6:00).
to adjust the minutes. Press DISP momentarily
to adjust the hours and
