- Page 1 Solera Classic Awning OWNER'S MANUAL (AU) ®...
-
Page 2: Table Of Contents
Fabric Care Notes Introduction The Solera Classic Awning is designed for use on most recreational vehicle units and is available in a variety of sizes to fit even the largest unit. Additional information about this product can be obtained from www.lci1.com/support... -
Page 3: Operation
operation Extending the Awning Prior to raising the Pop top on a pop up trailer, the cam lock (Fig. 4B) MUSt be in the roll out position. Failure to do so can result in damage to the trailer. Release the travel locks, which will be either original (A) or current (B) style. A. - Page 4 Prior to raising the pop top on a pop up trailer, the cam lock (Fig. 2B) MUSt be in the roll out position. Failure to have the cam lock in the open position can result in damage to the trailer. Loosen the black locking knobs (Fig.
-
Page 5: Extending Optional Car Port
Fig. 6 Extending Optional Car Port After steps 1-8 in the Extending the Awning section have been completed, remove the outer arm (Fig. 6A) from the side of the unit by releasing the lever (Fig. 6B) on lower mounting bracket (Fig. 6C). Walk the awning out until the outer arm is straight up and down and let it set on the ground. - Page 6 Walk the awning in toward the unit. Hook the pull rod into the pull strap before the strap gets too high. Using the pull rod, walk the awning to the fully-closed position. Remove the hook from the pull strap and store in a secure location. Secure travel locks accordingly as they appear on the unit.
-
Page 7: Troubleshooting
troubleshooting What is happening? Why it's happening What should be done? Cam lock engaged. Check position of the cam lock (roll out). Make sure that the travel locks have been released Travel locks engaged. from the outer arm. Rafter arm(s) locking Make sure the locking knob for the rafters has been Awning will not extend. -
Page 8: Maintenance
Troubleshooting Continued What is happening? Why it's happening What should be done? Check the cam lock. Signs of a faulty cam lock include: Cam lock wear may be Awning will not stay in the • The absence of a clicking noise when the rolled out position. -
Page 9: Notes
Notes Page 9 Rev: 08.09.21 CCD-0001361-AU... - Page 10 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (“LCI”). LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty. ...
