ES100 ELECTRONIC OVEN CONTROL
The ES100 electronic oven control is almost identical to the current control with a few exceptions.
Bake
Timer
Clock
Clear
Broil
On/Off
Set
Off
Note:
The ES100's are not field repairable.
Note:
Depending on model, the size and shape of touch pads may vary (for example round instead of elliptical).

NORMAL BAKE

During a normal bake mode, the control preheats the oven by alternate bake & broil elements. When the desired
temperature is reached, the control adds top heat by cycling the broil element on for 6 to 9 seconds per minute .
The bake element is on for the remaining time of the minute. Both elements use full power when they are on but
they are never on at the same time.
FIRST RISE
It is normal to see a temperature overshoot in the
first rise of all modes when you monitor the temperature.

OVEN CALIBRATION

Set the electronic oven control for normal baking at 350°F/176°C. Obtain an average oven temperature after a minimum
of 5 cycles. Press Cancel to end bake mode.
T
°
t (sec)
2
First rise overshoot
set point
