Instruction Revision: D
S
Parts List:
(1) Bar Top
(1) Left Side Assembly
READ ENTIRE INSTRUCTIONS BEFORE BEGINNING! Carefully remove contents
from box. Make sure that all parts and hardware are included. Will Require Two People for
Handing of Bar
Stand side up with front leg down. Insert front panel into pock-
ets of front leg of side assembly (Front Leg has bolt). Tap in to
make sure front panel sits tightly against the leg (Left Picture).
Secure using (3) 1-1/4" Phillips Head Screw through pre-drilled
pockets in front panel (Right Picture). Repeat process for other
side.
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114
C
EASIDE
ASUAL
ENVIRO
(009) Portsmouth Party Bar rev. B
(1) Top Shelf
(1) Right Side Assembly
Assembly Instructions
Step One: Set Up
Step Two: Base Assembly
F
URNITURE
WOOD
Hardware:
(57) 3/4" Pan Head Screws
(6) 1-1/4" Phillips Head Screws
(2) 3/4" Phillips Pan Head Screws
Tools Required:
Phillip's Head Screwdriver
7 /16 Socket or Wrench
(2) Lower Shelves
(1) Front Panel
