SEASIDE CASUAL FURNITURE Portsmouth Bar Table Assembly Instructions

Instruction Revision: B
S
(51) 42In X 42In Portsmouth Bar Table

Parts List:

(1) Table Top
(2) Leg Assemblies
(2) Upper Leg Stretchers
(2) Lower Leg Stretchers
(2) Long Aprons
(2) Short Aprons
(1) Mid Umbrella Stretcher
READ ENTIRE INSTRUCTIONS BEFORE BEGINNING! Carefully remove contents
from box. Make sure that all parts and hardware are included.
Place Lower Leg Stretcher between Leg Assemblies aligning pre-
drilled holes. Attach using (4) 3" Hex 1/4" Lags. Repeat process for
other Lower Leg Stretcher. (Right Picture)

Step Four: Mid Umbrella Stretcher Assembly

Place Mid Umbrella Stretcher between Upper Leg Stretchers aligning
pre-drilled holes. Attach using (4) 3" Hex 1/4" Lags. (Right Picture)
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114
C
EASIDE ASUAL
ENVIRO
Assembly Instructions

Step One: Set Up

Step Two: Lower Leg Stretcher Assembly

Step Three: Upper Leg Stretcher Assembly

Place Upper Leg Stretcher between Leg Assemblies aligning pre-
drilled holes. Attach using (4) 3" Hex 1/4" Lags. Repeat process for
other Upper Leg Stretcher. (Left Picture)
F
URNITURE
WOOD
Hardware:
(28) 3" Hex 1/4" Lags
(10) 3/4" Pan Head Screws
(2) Thumb Screws

Tools Required:

Phillip's Head Screwdriver
4MM Allen Wrench (Included)
1
