Before Locating The Fixing Brackets - Infiniton VIT3F30D Instruction Manual / Installation Manual

L(mm) W(mm)
590 520
Under any circumstances, make sure the ceramic cooker hob is well ventilated
and the air inlet and outlet are not blocked. Ensure the ceramic cooker hob is in
good work state. As shown below
Note: The safety distance between the hotplate and the cupboard above
the hotplate should be at least 760mm.
A(mm) B(mm)
760 50 mini

Before locating the fixing brackets

The unit should be placed on a stable, smooth surface (use the packaging). Do not
H(mm) D(mm)
52 48
C(mm) D
40 mini Air intake
A(mm)
560
E
Air exit 10 mm
21
B(mm) X(mm)
490 50 mini
