414192
Night Stand
Embassy Point Collection
PLEASE CONTACT US
BEFORE RETURNING
YOUR UNIT TO THE STORE
1-800-523-3987
www.sauder.com
NOTE: THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
English .................... Page 1-15
Français ...............Pages 16-18
Made in the USA
Espanol .............Páginas 19-21
Archbold, OH
Lot #: 354253
Date Purchased: ____________________
07 / 31 / 13
Advertisement
Related Manuals for Sauder Embassy Point 414192
Summary of Contents for Sauder Embassy Point 414192
- Page 1 PLEASE READ AND KEEP FOR FUTURE REFERENCE. BEFORE RETURNING English ....Page 1-15 YOUR UNIT TO THE STORE Français ....Pages 16-18 Made in the USA 1-800-523-3987 Espanol .....Páginas 19-21 Archbold, OH www.sauder.com Lot #: 354253 07 / 31 / 13 Date Purchased: ____________________...
- Page 2 Use this PART IDENTIFICATION to help identify similar parts. RIGHT END LEFT END BACK BRACE FRONT SKIRT DRAWER FRONT DRAWER MOLDING BOTTOM MOLDING RIGHT DRAWER SIDE LEFT DRAWER SIDE D158 DRAWER BACK D964 DRAWER BOTTOM Page 2 www.sauder.com/services 414192...
- Page 3 PART IDENTIFICATION D158 D964 D158 D964 414192 www.sauder.com/services Page 3...
- Page 4 GOLD 5/16" FLAT HEAD SCREW - 16 BLACK 1-1/4" FLAT HEAD SCREW - 8 BLACK 1-9/16" FLAT HEAD SCREW - 8 BLACK 7/8" MACHINE SCREW - 2 Screws are shown actual size. You may receive extra hardware with your unit. Page 4 www.sauder.com/services 414192...
- Page 5 Look for this icon. It means a video assembly tip is available at: www.sauder.com/services/tips Do not tighten the HIDDEN CAMS in this step. Arrow (10 used) Do not insert HIDDEN CAMS and CAM DOWELS into this edge. Arrow Arrow Arrow Insert the metal end of the CAM DOWEL into the HIDDEN CAM.
- Page 6 Roller end Finished edge Fasten the CABINET RIGHTS (35GA) to the RIGHT END (A) and the CABINET LEFTS (35GB) to the LEFT END (B). Use eight GOLD 5/16" FLAT HEAD SCREWS (3S) through holes #1 and #3. Page 6 www.sauder.com/services 414192...
- Page 7 Tighten Arrow Risk of damage or injury. Hidden Cams must be completely Arrow Maximum tightened. Hidden 210 degrees Cams that are not completely tightened Minimum may loosen, and parts 190 degrees may separate. To completely tighten: 414192 www.sauder.com/services Page 7...
- Page 8 Unfi nished surface Maximum Arrow 210 degrees Minimum 190 degrees Fasten the TOP (C) to the ENDS (A and B). Tighten four HIDDEN CAMS. Fasten the BOTTOM MOLDING (I) to the upper BRACE (E). Tighten two HIDDEN CAMS. Page 8 www.sauder.com/services 414192...
- Page 9 Fasten four ANGLE BRACKETS (5G) to the ENDS (A and B) and upper BRACE (E). Use four BLACK 9/16" LARGE HEAD SCREWS (1S). Fasten the FRONT SKIRT (F) to the ENDS (A and B) and upper BRACE (E). Use four BLACK 9/16" LARGE HEAD SCREWS (1S) through the ANGLE BRACKETS and into the FRONT SKIRT. 414192 www.sauder.com/services Page 9...
- Page 10 Carefully turn your unit over onto its front edges. Unfold the BACK (D) and lay it over your unit. Make equal margins along all four edges of the BACK (D). Push on opposite corners of your unit if needed to make it “square”. Fasten the BACK (D) to your unit using the NAILS (1N). Page 10 www.sauder.com/services 414192...
- Page 11 BLACK 1-1/4" FLAT HEAD SCREW (8 used in this step) Fasten the DRAWER MOLDINGS (H) to the DRAWER FRONTS (G). Use eight BLACK 1-1/4" FLAT HEAD SCREWS (7S). 414192 www.sauder.com/services Page 11...
- Page 12 Fasten the DRAWER BACK (D158) to the DRAWER SIDES (D12 and D13). Use four BLACK 1-9/16" FLAT HEAD SCREWS (30S). NOTE: Be sure the DRAWER BOTTOM (D964) inserts into the groove of the DRAWER BACK (D158). Repeat this step for the other drawer. Page 12 www.sauder.com/services 414192...
- Page 13 NOTE: The screw head in the CAM must be visible through the slotted hole in the SLIDE. Fasten a PULL (82K) to the DRAWER FRONT (G). Use a BLACK 7/8" MACHINE SCREW (37S). Repeat this step for the other drawer. 414192 www.sauder.com/services Page 13...
- Page 14 To insert the drawers into your unit, tip the front of the drawers down and drop the rollers on the drawers behind the rollers on the unit. Lift the front of the drawers up and slide them into the unit. Page 14 www.sauder.com/services 414192...
- Page 15 Tighten the SCREW when finished with adjustments. NOTE: Please read the back pages of the instruction booklet for important safety information. This completes assembly. To clean your unit, dampen a cloth with tap water and wipe. 414192 www.sauder.com/services Page 15...
- Page 16 30S VIS TÊTE PLATE 40 mm NOIRE ..8 et conserver le livret 37S VIS À MÉTAUX 22 mm NOIRE ..2 pour future référence. Pour contacter Sauder en ce qui concerne cet élément, faire référence au numéro de lot et numéro de modèle en appelant notre numéro...
- Page 17 Fixer le DESSUS (C) aux EXTRÉMITÉS (A et B). Serrer TIROIR (D964) s'encastre dans la rainure de l'ARRIÈRE quatre EXCENTRIQUES ESCAMOTABLES. DE TIROIR (D158). Fixer la MOULURE DE DESSOUS (I) à Répéter cette étape pour l'autre tiroir. l'ENTRETOISE supérieure (E). Serrer deux EXCENTRIQUES ESCAMOTABLES. 414192 www.sauder.com/services Page 17...
- Page 18 Pour insérer les tiroirs dans l'élément, abaisser le devant des tiroirs et faire passer les roulettes situées sur les tiroirs derrière les roulettes situées sur l'élément. Relever les devants du tiroir et les tiroirs dans l'élément. Page 18 www.sauder.com/services 414192...
- Page 19 CABEZA PERDIDA de 32 mm ..8 Si necesita ponerse 30S TORNILLO NEGRO DE en contacto con CABEZA PERDIDA de 40 mm ..8 Sauder en cuanto a 37S TORNILLO NEGRO PARA esta unidad, refi érase METAL de 22 mm ......2 al número de lote y al número de modelo...
- Page 20 DORSO DE CAJÓN (D158). Apriete cuatro EXCÉNTRICOS ESCONDIDOS. Repita este paso para el otro cajón. Fije la MOLDURA DE FONDO (I) a la RIOSTRA superior (E). Apriete dos EXCÉNTRICOS ESCONDIDOS. Page 20 www.sauder.com/services 414192...
- Page 21 Levante la parte delantera de los cajones y deslícelos dentro de la unidad. 414192 www.sauder.com/services Page 21...
- Page 22 Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y son propensos a inclinarse hacia adelante. Page 22 www.sauder.com/services 414192...
- Page 23 4. La présente garantie ne s’applique qu’aux défauts garantis qui se produisent des composantes de mobilier Sauder. Le mot « défaut », tel qu’il est utilisé sous pour la première fois et qui sont signalés à Sauder dans les limites de ouverture les termes de la présente garantie, comprend les imperfections des pièces qui...
- Page 24 Archbold, Ohio, where it all began. Certifi cate of Conformity The Sauder name on the box ensures that 1. This certifi cate applies to the Sauder Woodworking Product identifi ed by this Instruction Book. the item you have purchased is made with 2.
