Fire Bowls and Inserts Premium Line
WARNING
FOR YOUR SAFETY: This product must be installed and serviced by a contractor who is licensed and qualified in pool equipment
by the jurisdiction in which the product will be installed where such state or local requirements exists. In the event no such state or
local requirement exists, the installer or maintainer must be a professional with sufficient experience in pool equipment installation
and maintenance so that all of the instructions in this manual can be followed exactly. Before installing this product, read and follow all
warning notices and instructions that accompany this product. Failure to follow warning notices and instructions may result in property
damage, personal injury, or death. Improper installation and/or operation can create carbon monoxide gas and flue gases which can
cause serious injury, property damage, or death. For installations in the vicinity of occupied/living spaces, as an additional measure
of safety, Zodiac Pool Systems LLC strongly recommends installation of suitable carbon monoxide detectors in the vicinity of this
appliance and in any adjacent occupied spaces. Improper installation and/or operation may void the warranty.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Immediately switch off main gas supply.
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
MAINTENANCE MANUAL
Grand Effects
Automated Operation
IF THESE INSTRUCTIONS ARE NOT FOLLOWED
EXACTLY, A FIRE OR EXPLOSION MAY RESULT,
CAUSING PROPERTY DAMAGE, PERSONAL
INJURY, OR DEATH.
OPERATION AND
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FBBRPCON30 and is the answer not in the manual?

Questions and answers

Summary of Contents for GRAND EFFECTS FBBRPCON30

  • Page 1 OPERATION AND MAINTENANCE MANUAL Grand Effects ® Fire Bowls and Inserts Premium Line Automated Operation IF THESE INSTRUCTIONS ARE NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT, WARNING CAUSING PROPERTY DAMAGE, PERSONAL INJURY, OR DEATH. FOR YOUR SAFETY: This product must be installed and serviced by a contractor who is licensed and qualified in pool equipment by the jurisdiction in which the product will be installed where such state or local requirements exists.
  • Page 2: Table Of Contents

    Section 1. Important Safety Instructions ..3 Section 2. General Description ...... 4 Product Overview ............4 Product Contents............4 Section 3. Installing the Grand Effects ® Fire Bowls ........5 Preparing the Fire Bowl for Installation ......5 Gas and Electric Requirements........7 Installing the Fire Bowl ..........8...
  • Page 3: Section 1. Important Safety Instructions

    Visit www.zodiacpoolsystems.com for additional free copies of these instructions or call Zodiac Technical Support at 800.822.7933 (U.S.) or Grand Effects at 949.697.5270 ATTENTION INSTALLER This manual contains important information about the installation, operation and safe use of this product.
  • Page 4: Section 2. General Description

    Fire Bowls and Inserts. ® CAUTION The Grand Effects Fire Bowls are not serviceable and therefore contain no serviceable parts. In order to prevent risk of property damage and/ or injury, no service should be attempted to the bowl in the event of a malfunction.
  • Page 5: Section 3. Installing The Grand Effects ® Fire Bowls

    Fire Bowls and Inserts Premium Line Page 5 Automated Operation Section 3. Installing the Grand Effects ® Fire Bowls WARNING Risk of Electrical Shock or Electrocution. This fire bowl must be installed by a licensed or certified electrician or a qualified pool...
  • Page 6 Fire Bowls and Inserts Premium Line Page 6 Automated Operation Additionally, Zodiac Pool Systems LLC, requires that as required by Article 680 of the NEC, the appliance be properly connected to an equipotential bonding grid/loop that includes all electrical equipment in the system and on the equipment pad.
  • Page 7: Gas And Electric Requirements

    Tighten the setscrew until the bond wire is secured into place. Setscrew Bonding Lug / Bond Wire Insert Figure 2. Bonding Lug on Burner Assembly Gas and Electric Requirements 120 VAC / 60 Hz to Grand Effects Control ® Input Voltage Panel Output Voltage 12 VAC...
  • Page 8: Installing The Fire Bowl

    Fire Bowls and Inserts Premium Line Page 8 Automated Operation Installing the Fire Bowl WARNING Do not install near any combustibles such as wood structures, fuels, clothing, fabrics, or dry vegetation. Keep surrounding area clear of all debris such as paper, leaves, pine-needles and other combustible materials.
  • Page 9 GAS INLET (PROPANE) 12 VAC 120 VAC 60HZ INPUT TO CONTROL PANEL OUTLET PROPANE ADDER SUPPLIED BY GRAND EFFECTS GAS OUTLET 12 VAC & CONDUIT (UNDERGROUND) BOWL #1 3/4” GAS PIPING (UNDERGROUND) 12 VAC & CONDUIT (UNDERGROUND) BOWL #2 3/4” GAS PIPING (UNDERGROUND) Figure 4.
  • Page 10 KEYED SWITCH 12 VAC 120 VAC 60HZ INPUT COMMERCIAL SAFETY PIPE TRAIN TO CONTROL PANEL OUTLET SUPPLIED BY GRAND EFFECTS 12 VAC 60 HZ INPUT DETAILS (INSTALL AS CLOSE AS POSSIBLE TO FIRE PIT) GAS OUTLET 12 VAC & CONDUIT (UNDERGROUND) BOWL #1 3/4”...
  • Page 11 Typically, the pool controller is the device that turns the unit on and off. If a pool controller is not available, Grand Effects can provide a hand held remote system or an electrician can wire a decorative switch for on/off control up stream of the Grand Effects control panel.
  • Page 12 Fire Bowls and Inserts Premium Line Page 12 Automated Operation 14. Install wire nuts on wires from the control panel and burner assembly. Be careful to hook up the “positive” to the “positive” and the “negative” to the “negative.” Wrap wire nuts with electrical tape or some means to prevent moisture from getting in.
  • Page 13 Fire Bowls and Inserts Premium Line Page 13 Automated Operation BRACKETS GRAND EFFECTS (FOLD OUT) BURNER ASSEMBLY SUPPORT PLATE BOWL CLAMP RING AND MOUNTING BRACKET HARDWARE ANCHOR BOLTS (3) MOUNTING BRACKET AND HARDWARE (NOT INCLUDED) WALL OR PILASTER 12 VAC ELECTRICAL (UNDERGROUND) 3/4”...
  • Page 14 Fire Bowls and Inserts Premium Line Page 14 Automated Operation 26” MINIMUM WHEN MOUNTED 1.5” IN BOWL TOP OF BURNER ASSEMBLY MINIMUM GRAND EFFECTS / IS FLUSH WITH TOP CSA APPROVED OF BOWL BURNER ASSEMBLY 9” MINIMUM CUSTOMER FURNISHED BOWL GRAND EFFECTS...
  • Page 15: Section 4. Burner Setup And Adjustment

    To avoid the risk of property damage and serious injury, including death, when purging air from a propane system, be sure to disconnect wires going to the burner assemblies (terminals X1/X2) located in Grand Effects control panel. There should be no power at the burner ®...
  • Page 16: Burner Adjustment

    Fire Bowls and Inserts Premium Line Page 16 Automated Operation GAS INLET PILOT SOLENOID MAIN SOLENOID ENCLOSURE WITH IGNITOR IGNITION MODULE Figure 10. Bottom-side of Burner Assembly Burner Adjustment Note: Each burner should have a flame height of approximately 12″ – 15″ from the top of the bowl.
  • Page 17 Do not cover the burner assembly and support plate. Fire glass requires a glass pilot hood, which is different than a standard pilot hood used with lava rock. Please consult the Grand Effects Glass Install Manual. If you use ®...
  • Page 18: Section 5. Maintenance

    WALL OR PILASTER Figure 12. Maintenance Important: The system needs to be turned on/off after a rain to remove any water in the pilot area. Note: If any problems are present, consult a licensed heating specialist or call Grand Effects ®...
  • Page 19: Section 6. Operation

    • Before any inspection of the unit, always turn off power and gas supply to the burners. • If you experience problems with this unit, call Grand Effects or a licensed heating professional. All work on this unit must be performed by a licensed heating professional.
  • Page 20: Section 7. Troubleshooting

    Troubleshooting WARNING To avoid the risk of property damage and serious injury, including death, call Grand Effects or a licensed heating professional if you experience ® problems with this unit. All work on this unit must be performed by a licensed heating professional.
  • Page 21 Fire Bowls and Inserts Premium Line Page 21 Automated Operation WARNING Model 100 Burner Assembly In order to avoid the risk of property damage, serious injury, including death, turn OFF power and gas at the control panel prior to initiating troubleshooting steps.
  • Page 22: Section 8. Control Module Diagram

    Fire Bowls and Inserts Premium Line Page 22 Automated Operation Section 8. Control Module Diagram GRAND EFFECTS ® GE1020 CONTROL MODULE 1.45 5.25 THIS CONTROL IS TO BE Fire and Water Features www.grandeffects.com USED WITH OUTDOOR 12VAC 50/60Hz APPLIANCES ONLY 1 = .3A...
  • Page 23: Section 9. Wiring Diagram

    Fire Bowls and Inserts Premium Line Page 23 Automated Operation Section 9. Wiring Diagram CONTROL PANEL BURNER 120V BLACK BLACK X1 BLACK 120V WHITE WHITE GREEN GREEN X2 ORANGE GROUND X2 ORANGE X1 BLACK...
  • Page 24 Grand Effects 23121 Arroyo Vista, Suite B, Rancho Santa Margarita, CA 92688 1.949.697.5270 | www.GrandEffects.com Zodiac Pool Systems LLC 2882 Whiptail Loop #100, Carlsbad, CA 92010 1.800.822.7933 | www.ZodiacPoolSystems.com ©2020 Zodiac Pool Systems LLC. All rights reserved. ZODIAC® is a registered trademark of Zodiac International, S.A.S.U., used under license.
