GRAND EFFECTS 100 Operation And Maintenance Manual

Hide thumbs Also See for 100:
Table of Contents

Advertisement

Quick Links

Premium Line Automated Operation
WARNING
FOR YOUR SAFETY: This product must be installed and serviced by a contractor who is licensed and qualified in pool equipment
by the jurisdiction in which the product will be installed where such state or local requirements exists. In the event no such state or
local requirement exists, the installer or maintainer must be a professional with sufficient experience in pool equipment installation
and maintenance so that all of the instructions in this manual can be followed exactly. Before installing this product, read and follow all
warning notices and instructions that accompany this product. Failure to follow warning notices and instructions may result in property
damage, personal injury, or death. Improper installation and/or operation can create carbon monoxide gas and flue gases which can
cause serious injury, property damage, or death. For installations in the vicinity of occupied/living spaces, as an additional measure
of safety, Zodiac Pool Systems LLC strongly recommends installation of suitable carbon monoxide detectors in the vicinity of this
appliance and in any adjacent occupied spaces. Improper installation and/or operation may void the warranty.
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Immediately switch off main gas supply.
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
MAINTENANCE MANUAL
Grand Effects
IF THESE INSTRUCTIONS ARE NOT FOLLOWED
EXACTLY, A FIRE OR EXPLOSION MAY RESULT,
CAUSING PROPERTY DAMAGE, PERSONAL
INJURY, OR DEATH.
OPERATION AND
Fire Pits
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 100 and is the answer not in the manual?

Questions and answers

Related Manuals for GRAND EFFECTS 100

Summary of Contents for GRAND EFFECTS 100

  • Page 1 OPERATION AND MAINTENANCE MANUAL Grand Effects ® Fire Pits Premium Line Automated Operation IF THESE INSTRUCTIONS ARE NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT, WARNING CAUSING PROPERTY DAMAGE, PERSONAL INJURY, OR DEATH. FOR YOUR SAFETY: This product must be installed and serviced by a contractor who is licensed and qualified in pool equipment by the jurisdiction in which the product will be installed where such state or local requirements exists.

  • Page 2: Table Of Contents

    Section 1. Important Safety Instructions ..3 Section 2. General Description ...... 4 Product Overview ............4 Product Contents............4 Section 3. Installing the Grand Effects ® Fire Pits .......... 5 Preparing the Fire Pit for Installation ......5 Gas and Electric Requirements........7 Installing the Fire Pit ............7...

  • Page 3: Section 1. Important Safety Instructions

    Visit www.zodiacpoolsystems.com for additional free copies of these instructions or call Zodiac Technical Support at 800.822.7933 (U.S.) or Grand Effects at 949.697.5270 ATTENTION INSTALLER This manual contains important information about the installation, operation and safe use of this product.

  • Page 4: Section 2. General Description

    ® CAUTION The Grand Effects Fire Pits are not serviceable and therefore contain no serviceable parts. In order to prevent risk of property damage and/ or injury, no service should be attempted to the fire pit in the event of a malfunction.

  • Page 5: Section 3. Installing The Grand Effects

    Fire Pits Premium Line Automated Operation Page 5 Section 3. Installing the Grand Effects ® Fire Pits WARNING Risk of Electrical Shock or Electrocution. This fire pit must be installed by a licensed or certified electrician or a qualified pool...

  • Page 6: Gas And Electric Requirements

    Loosen the setscrew. Insert the bond wire into the hole. Tighten the setscrew until the bond wire is secured into place. Gas and Electric Requirements 120 VAC / 60 Hz to Grand Effects ® Input Voltage Control Panel Output Voltage...

  • Page 7: Installing The Fire Pit

    Fire Pits Premium Line Automated Operation Page 7 Installing the Fire Pit WARNING Do not install near any combustibles such as wood structures, fuels, clothing, fabrics, or dry vegetation. Keep surrounding area clear of all debris such as paper, leaves, pine-needles and other combustible materials.
  • Page 8 GAS INLET (PROPANE) 12 VAC 120 VAC 60HZ INPUT OUTLET TO CONTROL PANEL PROPANE ADDER SUPPLIED BY GRAND EFFECTS ® 12 VAC OUTPUT & CONDUIT (UNDERGROUND) 3/4” - 1” GAS PIPING (UNDERGROUND) Figure 2. Propane Gas CONTROL PANEL (TYPICALLY MOUNTED WITH...
  • Page 9 Typically, the pool controller is the device that turns the unit on and off. If a pool controller is not available, Grand Effects can provide a hand held remote system or an electrician can wire a decorative switch for on/off control up stream of the Grand Effects control panel.

  • Page 10: Installing The Fire Pit Features

    MOUNTING BRACKET Figure 5. Mounting Note: All Models of Essex and Legacy require installation of the Grand Effects mounting bracket. See Figure 5. The mounting ® bracket must be installed for proper cooling of the burner assembly. Warranty may be voided if the mounting bracket is not installed.

  • Page 11: Section 4. Burner Setup And Adjustment

    To avoid the risk of property damage and serious injury, including death, when purging air from a propane system, be sure to disconnect wires going to the burner assemblies (terminals X1/X2) located in Grand Effects control panel. There should be no power at the burner ®...

  • Page 12: Burner Adjustment

    Page 12 Fire Pits Premium Line Automated Operation GAS INLET PILOT SOLENOID MAIN SOLENOID ENCLOSURE WITH IGNITOR IGNITION MODULE Figure 9. Bottom-side of Burner Assembly Burner Adjustment Note: Each burner should have a flame height of approximately 12″ – 15″ from the top of the bowl.
  • Page 13 Fire Pits Premium Line Automated Operation Page 13 WARNING Use only approved decorative media to cover the burner assembly. Lava and tumbled lava/ceramic stone and fire glass are all accepted media. To avoid the risk of property damage and serious injury, including death, use caution when in the immediate area, as pieces may pop or explode when exposed to heat or when wet and exposed to heat.

  • Page 14: Section 5. Maintenance

    Important: Gas must be securely shut off when not in use. Note: If any problems are present, consult a licensed heating specialist or call Grand Effects ®...

  • Page 15: Section 6. Operation

    • Before any inspection of the unit, always turn off power and gas supply at the control panel. • If you experience problems with this unit, call Grand Effects or a licensed heating professional. All work on this unit must be performed by a licensed heating professional.

  • Page 16: Section 7. Troubleshooting

    All work on this unit must be performed by a licensed heating professional. WARNING Model 100 Burner Assembly In order to avoid the risk of property damage, serious injury, including death, turn OFF power and gas at the control panel prior to initiating troubleshooting steps.
  • Page 17 Fire Pits Premium Line Automated Operation Page 17 WARNING Model 100 Burner Assembly In order to avoid the risk of property damage, serious injury, including death, turn OFF power and gas at the control panel prior to initiating troubleshooting steps. Turn power and gas ON once troubleshooting is complete.

  • Page 18: Section 8. Control Module Diagram

    Page 18 Fire Pits Premium Line Automated Operation Section 8. Control Module Diagram GRAND EFFECTS ® GE1020 CONTROL MODULE 1.45 5.25 THIS CONTROL IS TO BE Fire and Water Features www.grandeffects.com USED WITH OUTDOOR 12VAC 50/60Hz APPLIANCES ONLY 1 = .3A IV = 2.5A...

  • Page 19: Section 9. Wiring Diagram

    Section 9. Wiring Diagram CPWD-1 LEGEND L = 120 VAC LINE TERMINAL STRIP IN N = 120 VAC NEUTRAL GRAND EFFECTS ® GND = EARTH GROUND CONTROL PANEL X1 = 12 VAC HOT X2 = 12 VAC COMMON ELECTRICAL SERVICE...
  • Page 20 23121 Arroyo Vista, Suite B, Rancho Santa Margarita, CA 92688 1.949.697.5270 | www.GrandEffects.com Zodiac Pool Systems LLC 2882 Whiptail Loop #100, Carlsbad, CA 92010 1.800.822.7933 | www.ZodiacPoolSystems.com ©2020 Zodiac Pool Systems LLC. All rights reserved. ZODIAC® is a registered trademark of Zodiac International, S.A.S.U., used under license.
