Acnodes MKD9172D User Manual

1u rackmount17/19”monitorkeyboard drawer
Hide thumbs

Advertisement

Quick Links

Download this manual
User Manual
MKD9172D/9192D: 1U Rackmount 17/19" Monitor Keyboard
Drawer
14628 Central Ave,
Chino, CA 91710
tel:909.597.7588, fax:909.597.1939
MKD9172D/9192D
1U Rackmount LCD Keyboard Drawer
© Copyright 2013 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes' web site at www.acnodes.com.

Advertisement

loading
Need help?

Need help?

Do you have a question about the MKD9172D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Acnodes MKD9172D

Summary of Contents for Acnodes MKD9172D

  • Page 1 MKD9172D/9192D 1U Rackmount LCD Keyboard Drawer User Manual MKD9172D/9192D: 1U Rackmount 17/19” Monitor Keyboard Drawer © Copyright 2013 Acnodes, Inc. 14628 Central Ave, All rights reserved. Product description and product specifications Chino, CA 91710 are subject to change without notice. For latest product information, tel:909.597.7588, fax:909.597.1939...
  • Page 2 ■ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. © Copyright 2013 Acnodes, Inc. 14628 Central Ave, All rights reserved. Product description and product specifications Chino, CA 91710 are subject to change without notice. For latest product information, tel:909.597.7588, fax:909.597.1939 please visit Acnodes’ web site at www.acnodes.com.
  • Page 3 KVS801 KV1601 © Copyright 2013 Acnodes, Inc. 14628 Central Ave, All rights reserved. Product description and product specifications Chino, CA 91710 are subject to change without notice. For latest product information, tel:909.597.7588, fax:909.597.1939 please visit Acnodes’ web site at www.acnodes.com.
  • Page 4 Wait until your monitor is com pletely dry before plugging it in and powering it up. © Copyright 2013 Acnodes, Inc. 14628 Central Ave, All rights reserved. Product description and product specifications Chino, CA 91710 are subject to change without notice. For latest product information, tel:909.597.7588, fax:909.597.1939 please visit Acnodes’ web site at www.acnodes.com.
  • Page 5 < Part 1 > < 1.1 > Package Content MKD9172D/9192D unit X 1 - Wired mini USB optical mouse X 1 - 6f t Combo KVM cable X 1 - Pow er c ord X 1 - M6 screw, ca ge nu t & cup washer X 8 The above package content is only for the single console models.
  • Page 6 Weight Weight 442 x 650 x 44 mm 595 x 860 x 140 mm 15.5 kg 21 kg MKD9172D 17.4 x 25.6 x 1.73" 23.4 x 33.9 x 5.5” 34 lb 46 lb 442 x 700 x 44 mm 595 x 910 x 140 mm 16.5 kg...
  • Page 7 < 1.3 > Installation - How to install Installation Slides Step ¦ Insert the left and right rear mounting brackets into the LCD c onsole drawer. Step ¦ Measure the depth of the front and rear mounting rails. ¦ Align each rear mounting bracket to a suitable length. Step Complete the installation ¦...
  • Page 8 1W or less © Copyright 2013 Acnodes, Inc. All rights reserved. Product description and product specifications 14628 Central Ave, Chino, CA 91710 are subject to change without notice. For latest product information, tel:909.597.7588, fax:909.597.1939 please visit Acnodes’ web site at www.acnodes.com.
  • Page 9 640 x 350 x 70Hz © Copyright 2013 Acnodes, Inc. 14628 Central Ave, All rights reserved. Product description and product specifications Chino, CA 91710 are subject to change without notice. For latest product information, tel:909.597.7588, fax:909.597.1939 please visit Acnodes’ web site at www.acnodes.com.
  • Page 10 < 2.2 > Keyboard / Mouse Specifications G keyboard WOM-01 Wired mini USB optical mouse option: WOM -02 Wireless USB optical mouse Key force 55 ± 5g Travelling distance 3 ± 0.3mm Switch life > 10 million life cycle tim e Software support MS W indows 7 / 2008 / 2003 / 2000 / XP / ME / 98 / DOC Linux / Mac...
  • Page 11 Light up all membrane buttons, please press any button for 1 - 2 seconds ( except the Power © Copyright 2013 Acnodes, Inc. 14628 Central Ave, All rights reserved. Product description and product specifications Chino, CA 91710 are subject to change without notice. For latest product information, tel:909.597.7588, fax:909.597.1939 please visit Acnodes’ web site at www.acnodes.com.
  • Page 12 OSD position, graphic mode, ratio, reset and timer © Copyright 2013 Acnodes, Inc. 14628 Central Ave, All rights reserved. Product description and product specifications Chino, CA 91710 are subject to change without notice. For latest product information, tel:909.597.7588, fax:909.597.1939 please visit Acnodes’ web site at www.acnodes.com.
  • Page 13 ( 3.5mm audio jack s for au dio in & o ut, and 2W + 2W spea kers ) © Copyright 2013 Acnodes, Inc. 14628 Central Ave, All rights reserved. Product description and product specifications Chino, CA 91710 are subject to change without notice. For latest product information, tel:909.597.7588, fax:909.597.1939 please visit Acnodes’ web site at www.acnodes.com.
  • Page 14 Option excludes 1 x power cord and 1 x AC power adapter © Copyright 2013 Acnodes, Inc. 14628 Central Ave, All rights reserved. Product description and product specifications Chino, CA 91710 are subject to change without notice. For latest product information, tel:909.597.7588, fax:909.597.1939 please visit Acnodes’ web site at www.acnodes.com.
