Page 2 TRANSELF TRJ 75W-80 API GL5 Automatic gearbox DEXRON III RENAULTMATIC D3 Syn RENAULT recommends approved ELF lubricants. When topping up or changing the oil, we recommend you use the original lubricants. Consult your RENAULT Dealer or visit the site www.lubricants.elf.com...
Page 3 Welcome to your new RENAULT This driver’s handbook contains the information necessary: • to enable you to get to know your RENAULT, to use it to the best advantage and to benefit from all the latest technical developments which are incorporated into it.
Page 4 Brief overview • Tyre pressures ......................0.04 • RENAULT key/card ................... 1.02 1.10 • Adjusting the seats and the driver's position ........1.18 1.25 • Child restraints ..................1.34 1.49 • Warning lights (instrument panel) ............1.54 1.82 • Starting/stopping the engine ..............2.04 - 2.09 •...
Page 5 Sections Getting to know your vehicle ............Driving ....................... Your comfort ....................Maintenance ....................Practical advice ................... Technical specifications ................ Alphabetical index ..................0.03...
Page 6 TYRE PRESSURES (in bar or kg per cm when cold) Tyre sizes 165/65 R15 81 T 195/50 R16 88 V 185/60 R15 88 H 185/60 R15 84 H Wheel sizes 5.5 J 15 6.5 J 16 6 J 15 6 J 15 Non-motorway use •...
Page 7 TYRE PRESSURES (in psi when cold) Tyre sizes 165/65 R15 81 T 195/50 R16 88 V 185/60 R15 88 H 185/60 R15 84 H Wheel sizes 5.5 J 15 6.5 J 16 6 J 15 6 J 15 Non-motorway use •...
Page 8 0.06...
Page 9 Section 1: Getting to know your vehicle Key/Radio frequency remote control unit: general information, use, deadlocking ....... 1.02 1.04 RENAULT Cards: general information, use, deadlocking ..............1.05 1.10 Doors ..............................1.11 1.15 RAID (RENAULT Anti-Intruder Device) ......................1.16 Engine immobiliser ............................1.17 Headrests - Seats ..........................
Page 10 • It will be necessary to take the interference and affect the operation vehicle to your RENAULT Dealer of the system. if you need to replace a key Radio frequency remote control because both the vehicle and all...
Page 11 KEY / RADIO FREQUENCY REMOTE CONTROL: use Unlocking / Locking the tailgate only (for certain countries) Press button 4 to unlock or lock the luggage compartment. The hazard warning lights and side indicators flash once to indicate unlocking if the vehicle doors are locked.
Page 12 KEY / RADIO FREQUENCY REMOTE CONTROL: deadlocking Deadlocking the doors and tailgate (for some countries) This allows you to lock the doors and luggage compartment and to prevent the doors from being opened with the interior handles (by breaking the window and then trying to open the doors from the inside).
Page 13 RENAULT CARDS: general information The RENAULT Card is used for: - locking/unlocking the doors and luggage compartment (doors, luggage compartment) and the Advice fuel filler flap (refer to the Do not keep your RENAULT Card following pages); in a place where it could be...
Page 14 RENAULT CARDS: general information (continued) Replacement, need additional RENAULT Card If you lose your RENAULT Card or require another, you can obtain one from your Dealer. If a RENAULT Card is replaced, it will be necessary to take the vehicle and all RENAULT Cards to your RENAULT Dealer to initialise the system.
Page 15 - if door luggage locked. compartment is open or not properly shut, or if a RENAULT The hazard warning lights and side Card is still in the reader, the doors indicators flash twice to indicate and luggage compartment quickly that the tailgate is locked if the lock then unlock and the hazard vehicle doors are locked.
Page 16 RENAULT CARD: use in hands-free mode RENAULT CARD: Unlocking doors hands-free mode luggage compartment In addition to the remote control Walk up to your vehicle carrying functions, and without handling your RENAULT Card. (hands-free mode), this allows: As soon as you place your hand on...
Page 17 RENAULT CARD: use in hands-free mode (continued) If you wish to check that the doors are locked after locking with the RENAULT Card or the buttons on handles, have approximately three seconds to try the door handles without unlocking them.
Page 18 RENAULT CARD: deadlocking To activate deadlocking Vehicles equipped with electric windows on the rear doors: - press button 2 twice in quick succession. - or press the exterior door handle buttons luggage compartment badge twice in quick succession. The hazard warning lights flash five times to indicate locking.
Page 19 Pull handle 2. using either the remote control, the A beep will let you know if you key or the RENAULT Card, pull have left the card in the reader when handle 1. you open the driver's door, and the “Remove card”...
Page 20 OPENING AND CLOSING THE DOORS (continued) Rear door locking must be reactivated following disconnection of the battery by pressing switch 3. Safety of rear occupants The driver can inhibit operation rear electric windows and doors by pressing switch 3 on the side Child safety with the icon.
Page 21 LOCKING AND UNLOCKING THE DOORS Locking/unlocking from outside This is done using the RENAULT remote control: refer “Key/radiofrequency remote control: general information” and “RENAULT CARD: general information”. some cases, radiofrequency remote control and the RENAULT Card may not work: • vehicle located in a zone of high electromagnetic radiation, •...
Page 22 LOCKING/UNLOCKING THE DOORS (continued) Using the integrated key 4 on Operating faults the RENAULT Card Each door can be locked manually if there is an electrical fault. Remove cover A at notch 5 (using Insert key 4 into the lock of the front the end of the emergency key).
Page 23 The indicator light integrated in and the RENAULT Card may not switch 7 shows whether or not the work: doors and tailgate are locked: - vehicle located in a zone of high - the light is on when the doors are electromagnetic radiation, locked;...
Page 24 If they are closed correctly, consult your RENAULT To deactivate Dealer. With the ignition on, press central door locking button 1 for about five seconds, until you hear two beeps.
Page 25 (computer, wiring, etc.) RENAULT Dealer only may be dangerous. It must be RENAULT Dealer is qualified to carried out by trained RENAULT repair engine immobiliser Network personnel. system. If there is interference and/or the hands-free RENAULT Card is not recognised, insert it in card reader.
Page 26 FRONT HEADRESTS To raise the headrest To remove the headrest To refit the headrest Pull the headrest upwards to the Lift the headrest to its highest If the rod setting has been altered, desired height. position. Press button 2 and raise withdraw the rods 3 as far as the headrest to remove it.
Page 27 REAR HEADREST Positions for use Storage position While pressing button A of lock 1, Press button A and lower the lift the headrest as far as possible to headrest completely. use it in the high position. Lower it until it locks to use it in the low The completely lowered headrest position.
Page 28 FRONT SEATS To move a seat forwards or To adjust the driver's seat height: backwards Move lever 2 as many times as Lift lever 1 underneath the seat to necessary: release. Once desired - upwards to raise it, position, release the lever and check - downwards to lower it.
Page 29 FRONT SEATS (continued) Access to the rear seats To tilt the seatback Turn tumblewheel 5 and tilt the (three-door versions) seatback to the desired position. Lift handle 6, tilt the seatback and slide the seat forward. To adjust the driver's seat comfort in the lumbar area: use handle 4.
Page 30 SEAT BELTS Always wear your seat belt when Adjusting your driving position travelling in your vehicle. You must • Sit well back in your seat (having also comply with the legislation of removed your coat or jacket). This the particular country you are in. is essential to ensure that your back is positioned correctly.
Page 31 - then allow the belt to rewind automatically, - unwind it again, - if the fault is still present, contact your RENAULT Dealer. Unlocking Press button 5 on buckle 6 and the seat belt will be rewound by the Adjusting the height of the seat Locking inertia reel.
Page 32 SEAT BELTS (continued) Rear side seat belts 1 Rear centre belt The belts are locked, unlocked and Unwind belt 3 slowly from its Fasten sliding tongue 4 into the adjusted in the same way as the housing, then fasten tongue 2 into corresponding red buckle.
Page 33 • No adjustments may be made to the original component parts of the restraint system (belts, seats and their mountings). For special cases (e.g. fitting child seats) contact your RENAULT Dealer. • Do not use devices which give any slack in the belts (e.g. clothes pegs, clips, etc.): a seat belt which is worn too loosely may cause injury in the event of an accident.
Page 34 • To avoid premature triggering of operate independently or together the system which may cause in the event of a front, side, or rear injury, only qualified RENAULT impact. Network personnel may work on Depending on the severity of the...
Page 35 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (continued) Chest and lap belt force limiters Driver and passenger airbags Above a certain severity of impact, Fitted to the driver and passenger this mechanism is used to limit the side.
Page 36 (in the event of more severe Consult your RENAULT Dealer as leaving the vehicle. impacts). soon as possible. Your protection will be reduced until this fault is rectified.
Page 37 • Do not attach any objects (badge, clock, telephone holder, etc.) to the steering wheel boss. • The steering wheel must not be removed (except by qualified personnel from the RENAULT Network). • When driving, do not sit too close to the steering wheel. Sit with your arms slightly bent (see the information on “Adjusting your driving position”...
Page 38 • To avoid premature triggering of - protection is provided by the belt the system which may cause only; injury, only qualified RENAULT Network personnel may work on - the pretensioner is triggered to pretensioner airbag rectify seat belt play.
Page 39 Contact your RENAULT screen draw your attention to the Dealer to find out if these covers may be purchased from RENAULT presence of additional means of outlets. The use of any covers other than those designed for your vehicle...
Page 40 • As a safety precaution, have the airbag system checked if your vehicle has been involved in an accident, stolen or broken into. • When selling or lending the vehicle, inform the user of these points and hand over this handbook with the vehicle. • When scrapping your vehicle, contact your RENAULT Dealer for disposal of the gas generator(s). 1.32...
Page 41 Refer to the Child safety equipment recommended on the following It is particularly dangerous to put booklet available from the RENAULT page. the belt round your child when he Network to choose the seat suited to or she is sitting on your lap. Never...
Page 42 CHILD SAFETY (continued) Type of child seat Seat Passenger seats size Front passenger Rear side Rear centre seats seats seat (1) (3) (4) Crosswise carrycot for 0 to 6 months F - G U - IUF (5) Approved for group 0 < 10 kg (22 lbs) Rear-facing shell seat for 0 to 9 months U - IUF - IL U - IUF - IL...
Page 43 Integrated: Seat fitted with an R44-03 approved child restraint system for this age range (refer to the section on Using the child restraint function) Refer to the Child safety equipment booklet available from the RENAULT Network to choose the seat suited to your child and recommended for your vehicle.
Page 44 To avoid any risk to your safety, we recommend that you use absorbing pad. RENAULT approved accessories because they are suitable for your vehicle and are the only accessories for which RENAULT will provide a warranty. 1.36...
Page 45 CHILD SAFETY (continued) booster seat with height-adjustable seatback and a belt guide are recommended as this will allow the belt to be worn as close to the base of the neck as possible but not on it. Place the headrest in the top position to allow you to press the seatback of the child seat firmly against the vehicle seatback.
Page 46 (only on rear seats); • Make sure that there is • a special RENAULT child seat nothing obstructing the fitted with two locks that hook seat mounting mechanism...
Page 47 CHILD SAFETY (continued) Fitting the child seat seat base - For information on fitting and using seat, read instructions provided carefully. - Attach mounting guide (supplied with the child seat or as an accessory), to rings 1 fitted to the seat. Fitting the child seat seatback - Slide the seat latches 3 into the guides 2 and push the seat hard...
Page 48 CHILD SAFETY (continued) Rear-facing seat mounting ring for Front-facing seat mounting ring rear seats (rear seats only) - attach belt hook to ring 5 or, - place the headrest in the high depending on the vehicle, the ring position or remove it; located under the rear bench seat - pass strap 4 (supplied with the and marked by a label;...
Page 49 CHILD SAFETY (continued) Adaptation of the rear centre seat is The headrest provided in the child approved for restraining children of pack has 3 settings: 22 kg (48 lbs) to 36 kg (79 lbs); this - child 6-10 years; conforms to European regulation - adult;...
Page 50 CHILD SAFETY (continued) Installing the pack for children Fitting the adaptor 1 This headrest setting recommended for children of 6-10 of 6 to 10 years The seat belt adaptor is attached years but it is not mandatory. If the under the guides 4 of the rear centre Replace the original headrest with child prefers to use the headrest on seat headrest.
Page 51 CHILD SAFETY (continued) Headrest on 6-10 years setting Insert the headrest rods into the shafts, press button A on the control Lift latch 7, disengage belt 8, and Adjust the height of the headrest to 3 and lower the headrest to the then lower latch 7 again.
Page 52 CHILD SAFETY (continued) If the lateral supports are in contact with the child's shoulders when in the high position, the child is too big for this setting; reposition the headrest on the adult setting. Headrest on adult setting Positioning the child of 6 to 10 years and fastening the seat belt Lift the headrest to set it in the adult position.
Page 53 CHILD SAFETY (continued) The shoulder belt should pass over the child's left shoulder as close as possible to he base of the neck. The lap belt should pass as low as possible over the thighs. It must never pass over the child's stomach. Fasten the child's seat belt by clipping the sliding bolt 12 into the holder 13 as far forward as...
Page 54 CHILD SAFETY (continued) To set the headrest in the storage position: Press button A on the control 3 at the base of the headrest rod and lower the headrest completely until it is in contact with the seatback. This setting gives driver maximum rear visibility.
Page 55 CHILD SAFETY (continued) CHILD SAFETY • No modifications may be made to the original component parts of the restraint system (belts and seats and their mountings). • Carefully follow the instructions for fitting provided by the manufacturer of the restraint system. •...
Page 56 CHILD SAFETY (continued) DANGER Since front passenger Deactivating the front passenger airbag triggering and the airbags position of a rear-facing To deactivate the airbags: push and child seat are incompatible, it is To fit a rear-facing child seat on the turn the lock 14 to the OFF position.
Page 57 Consult your RENAULT Dealer as soon as possible. Activating the front passenger airbags You should reactivate the airbag as soon as you remove the child seat...
Page 58 DRIVER’S POSITION, LEFT-HAND DRIVE 26 25 24 23 22 16 15 14 1.50...
Page 59 • cruise control and speed 15 Central door locking switch limiter, • ASR traction control, 7 Central air vents. • instrument panel lighting 16 RENAULT Card reader. 8 Warning lights for: dimmer. • driver's seat belt not fastened • front passenger airbag deactivated.
Page 60 DRIVER’S POSITION, RIGHT-HAND DRIVE 9 10 12 13 25 24 23 18 17 1.52...
Page 61 (continued) The equipment fitted, described below, depends on the version, option and country. 1 Side vent. 9 Instrument panel. 18 RENAULT Card reader. 10 Driver's airbag location, horn, 2 Location of passenger airbag. cruise control / speed limiter 19 Gear lever.
Page 62 If the warning light comes on, you should visit a RENAULT Dealer immediately. If no information appears on the instrument panel, it is essential to stop as soon as traffic conditions allow.
Page 63 Consult your vehicle is travelling in excess of running, there is a fault in the RENAULT Dealer as soon as 75 mph (120 km/h). system. possible. Consult your RENAULT Dealer as soon as possible.
Page 64 If the warning light comes on, you should visit a RENAULT Dealer immediately. If no information appears on the instrument panel, it is essential to stop as soon as traffic conditions allow.
Page 65 • If it flashes, reduce the engine after a few seconds. If it comes speed until the light stops Contact a RENAULT Dealer. on when the vehicle is being flashing. driven, accompanied by the...
Page 66 If the warning light comes on, you should visit a RENAULT Dealer immediately. If no information appears on the instrument panel, it is essential to stop as soon as traffic conditions allow.
Page 67 Stop immediately, indicates that the electrical switch off the ignition and circuit overcharged contact a RENAULT Dealer. Urgent stop warning undercharged. light Stop and have the circuit It goes out as soon as the checked.
Page 68 If the warning light comes on, you should visit a RENAULT Dealer immediately. If no information appears on the instrument panel, it is essential to stop as soon as traffic conditions allow.
Page 69 If it comes on when the vehicle displayed; the dashes and is being driven, it is advisable to “adjust oil level” are displayed visit your RENAULT Dealer as together with soon as possible. warning light. Top up the oil level as soon as possible.
Page 70 If the warning light comes on, you should visit a RENAULT Dealer immediately. If no information appears on the instrument panel, it is essential to stop as soon as traffic conditions allow.
Page 71 75 mph (120 km/h). Dealer as soon as possible. system. • If it flashes, reduce the engine Consult your RENAULT Dealer speed until the light stops as soon as possible. flashing. Left-hand turn signal...
Page 72 If the warning light comes on, you should visit a RENAULT Dealer immediately. If no information appears on the instrument panel, it is essential to stop as soon as traffic conditions allow.
Page 73 Check the oil level. If the level is normal, the warning light is being lit by something else. Contact a RENAULT Dealer. 1.65...
Page 74 If the warning light comes on, you should visit a RENAULT Dealer immediately. If no information appears on the instrument panel, it is essential to stop as soon as traffic conditions allow.
Page 75 It indicates that it is essential to seconds after the engine is conditions allow and contact a stop immediately (as soon as started. RENAULT Dealer. traffic conditions allow). If it lights up or remains lit, fill up with fuel as soon as possible. Not used...
Page 76 If the warning light comes on, you should visit a RENAULT Dealer immediately. If no information appears on the instrument panel, it is essential to stop as soon as traffic conditions allow.
Page 77 If it comes on when the vehicle is being driven, it is advisable to Dipped beam headlight visit your RENAULT Dealer as Multifunction display indicator light soon as possible. This indicates that an opening element (door or tailgate) is...
Page 78 TRIP COMPUTER AND WARNING SYSTEM Trip computer This displays following information on instrument panel display A or B (location varies depending on the vehicle): - information messages (journey parameters etc.); - the operating fault messages (generally linked to the warning light), - warning messages (linked to the warning light).
Page 79 TRIP COMPUTER AND WARNING SYSTEM (continued) c) mileage before service, d) programmed speed (speed limiter/cruise control), e) on-board log: record information messages operating fault messages stored by the computer. Display selection keys 1 and 2 Scroll through following information in this order or reverse order by briefly pressing the key repeatedly.
Page 80 TRIP COMPUTER AND WARNING SYSTEM (continued) Interpreting some of the values • that the average fuel consumption increases when the vehicle is displayed after resetting stationary with the engine idling. The values showing average fuel This is normal since the computer consumption, range and average takes account of fuel used during speed will become more stable and...
Page 81 TRIP COMPUTER AND WARNING SYSTEM (continued) Examples of display selection by Interpreting the display selected pressing key 2 Display A Display B a) Total mileage recorder (shown on line 1 of display B) Trip mileage recorder (shown on line 2 of display B) b) Trip parameters Fuel consumed since the last reset.
Page 82 TRIP COMPUTER AND WARNING SYSTEM (continued) Examples of display selection by Interpreting the display selected pressing key 2 Display A Display B Current fuel consumption This value is displayed after a speed of approximately 20 mph (30 km/h) is reached. Estimated range with remaining fuel This range takes into account the average fuel consumption since the last time the reset button was pressed.
Page 83 TRIP COMPUTER AND WARNING SYSTEM (continued) Examples of display selection by Interpreting the display selected pressing key 2 Display A Display B c) Mileage before service/maintenance Distance left before the next service. There are several scenarios: • remaining mileage less than 1,000 miles (1,500 km) or next service scheduled within two months.
Page 84 TRIP COMPUTER AND WARNING SYSTEM (continued) Examples of display selection by Interpreting the display selected pressing key 2 Display A Display B d) Cruise Control/Speed Limiter programmed speed (depending on vehicle) Refer to the information on “cruise control” and “speed limiter” in Section 2. e) Computer log Successive display: - of information messages (automatic headlights, etc.
Page 85 Examples of warning messages are given on the following Fault messages pages. You should immediately go to your RENAULT Dealer for work to be N.B.: the messages appear on the carried out on your vehicle. display either individually...
Page 86 TRIP COMPUTER AND WARNING SYSTEM (continued) Examples of information messages Messages Interpretation of messages "Tailgate open" Indicates that the tailgate has been left open. "Oil level OK" Indicates that the oil level is correct when the ignition is switched on. "Automatic lights OFF"...
Page 87 TRIP COMPUTER AND WARNING SYSTEM (continued) Examples of fault messages They appear in conjunction with the warning light and indicate that you should visit your RENAULT Dealer Messages Interpretation of messages "Check ESP" Indicates a traction control system fault (refer to the information on the traction control system in Section 2).
Page 88 RENAULT Dealer Messages Interpretation of messages "Gearbox fault" Indicates that a fault has occurred inside the gearbox, contact your RENAULT Dealer as soon as possible. "Auto lights fault" Indicates an automatic lights operating fault, contact your RENAULT Dealer.
Page 89 TRIP COMPUTER AND WARNING SYSTEM (continued) Examples of warning messages They appear in conjunction with the warning light and require you to stop the vehicle immediately (depending on traffic conditions). Messages Interpretation of messages "Injection fault" Indicates that the vehicle has a serious engine fault. "Engine overheating"...
Page 90 TRIP COMPUTER AND WARNING SYSTEM (continued) Examples of warning messages They appear in conjunction with the warning light and require you to stop the vehicle immediately (depending on traffic conditions). Messages Interpretation of messages "Steering fault" Indicates a fault in the vehicle's power assisted steering. "Gearbox overheating"...
Page 91 INFORMATION DISPLAYS Depending on the vehicle, displays Special note: 1 or 2 may show: When the outside temperature is - the radio (zone A); –3°C to +3°C, the °C characters flash (signalling a risk of ice on the road). - the clock (zone B); - the external temperature (zone C);...
Page 92 CLOCK Display A The time is displayed when the Then press and hold down button 3 ignition is switched on. to confirm the hour setting. To access display 1 which adjusts When the minutes are flashing, the clock, press button 2 or 3. press button 2 repeatedly or hold down to adjust them.
Page 93 CLOCK AND EXTERNAL TEMPERATURE (continued) Exterior temperature indicator Vehicles fitted with navigation assistance systems, telephones, etc. Special note: Refer to the separate instructions for the function to understand the When the outside temperature is special features of this equipment. –3°C to +3°C, the °C characters flash (signalling a risk of ice on the road).
Page 94 STEERING WHEEL Adjusting the height and depth of the steering wheel (depending on the vehicle) Pull the lever 1 and place the steering wheel in the required position; push the lever to lock the steering wheel in place. Never leave the steering wheel at full lock when the vehicle is stationary.
Page 95 REAR-VIEW MIRRORS Door mirrors with manual adjustment To adjust the mirror, move lever 1. The driver's door mirror have clearly defined zones. Zone B is what can normally be seen in a conventional door mirror. For your safety, zone A increases the area you can see at the rear and to the side of your car.
Page 96 REAR VIEW MIRRORS (continued) Electric door mirrors Folding door mirrors Interior rear-view mirror With the ignition on, turn knob 2 to: Move button 2 to position F and the Its position can be adjusted. For door mirrors fold in. To put them night driving, avoid being...
Page 97 THE HORN AND HAZARD LIGHTS Hazard warning lights Press switch 2. This switch lights all four direction indicators and the side-mounted indicators simultaneously. Only use this function to warn other road users if you are: • are obliged to stop for any reason beyond your control...
Page 98 EXTERIOR LIGHTING AND SIGNALS Switching on the side Adjusting the brightness of the lights instrument panel lighting Turn the end of switch 1 until the Turn control 3 downwards to symbol is opposite mark 2. reduce the brightness and upwards Before driving at night, to increase it.
Page 99 EXTERIOR LIGHTING AND SIGNALS (continued) Automatic operation (depending See-me-home lighting function on vehicle) This function (useful, for example, With the engine running, the for opening a gate, a garage, etc.) dipped beam headlights enables you briefly to light up the switched on or off automatically dipped headlights.
Page 100 Switching on the main If this happens, contact your beam headlights RENAULT Dealer soon With the dipped beam headlights possible. on, pull stalk 1 towards you. Warning: this is not a normal...
Page 101 EXTERIOR LIGHTING AND SIGNALS (continued) Automatic operation (depending Lights on warning buzzer on vehicle) If the lights are switched on after the The lights go out when the engine is engine is switched off, a warning stopped, when the driver's door is beep sounds when the driver's door opened or when the vehicle is is opened to warn you that the lights...
Page 102 EXTERIOR LIGHTING AND SIGNALS (continued) Rear fog light Switching off the lights Turn ring 5 again until mark 6 is Turn centre ring 5 on stalk 1 opposite the symbol for the fog light until the symbol faces mark 6, then you wish to switch off.
Page 103 ELECTRICAL ADJUSTMENT OF THE HEADLIGHT BEAM HEIGHTS vehicles fitted with this function, control A allows you to adjust the height of the beams according to the load. Turn control A down to lower the headlights and up to raise them. 1.95...
Page 104 WINDSCREEN WASH/WIPE Vehicles with automatic wiper function With the engine running, move stalk 1. • A off. • B automatic wiper function When this position is selected, the system detects the presence of water on the windscreen and triggers wiping at a suitable wiping speed.
Page 105 WINDSCREEN WASH/WIPE (continued) • Headlights on The headlight washers will be activated at the same time. Windscreen washers, headlight washers (depending on vehicle) In frosty weather, make sure the With the ignition on, pull stalk 1 wiper blades are not stuck by ice towards you.
Page 106 REAR SCREEN WASHER/WIPER Rear screen wash/wipe Special note With the ignition on, move windscreen wipers the end of stalk 1 to align the mark 2 operating or are in automatic mode, with the symbol. rear screen wiper wipes intermittently when reverse gear is When the stalk is released, it returns engaged.
Page 107 The shut-off system new cap is of the same type. and its surrounding area must be Refer to the information on “Filling Contact your RENAULT Dealer. dust-free. up with fuel” for more details. Never handle the cap near a source There is a cap holder 2 on the fuel of heat or a flame.
Page 108 (at the • not work on, or restart, the vehicle pump). before it has been inspected by qualified staff from the RENAULT - Insert the nozzle so that the valve Network. is pushed back and then fully insert it before beginning to fill the tank (risk of splash-back).
Page 109: Table Of Contents
Running in ................................ 2.02 Ignition switch ..............................2.03 Operating - Stopping the engine using the key/remote control ..............2.04 Starting - Stopping the engine using the RENAULT Card ............... 2.05 2.08 Special features of petrol versions ........................2.09 Special features of diesel versions ........................2.10 Gear lever / Power assisted steering .......................
Page 110: Running In
RUNNING IN Petrol version Diesel version For the first 625 miles (1,000 km) do For the first 900 miles (1,500 km), do not exceed 80 mph (130 km/h) in the exceed 2,500 rpm. After highest gear, or 3,000 to 3,500 rpm. completing this mileage you may drive faster, although you may only expect completion...
Page 111 IGNITION SWITCH: vehicle with key / radiofrequency remote control “Ignition on” position M Special note on vehicles with an automatic gearbox The ignition is switched on: Before starting, shift the lever to position N or P. “Start” position D If the engine fails to start at the first Special note on vehicles with a attempt, the key must be turned Quickshift gearbox...
Page 112 STARTING / STOPPING THE ENGINE: vehicle with key / radiofrequency remote control Starting the engine Stopping the engine Petrol injection With the engine idling, turn the key Diesel injection back to the “Stop” position. Engine warm or cold Cold or warm engine - Turn the key to the start position - Turn the key to the “Start”...
Page 113 STARTING THE ENGINE: vehicle with RENAULT Card RENAULT Card Starting conditions. The card must be in the detection Follow the starting instructions on area 1 (passenger compartment and the instrument panel 2 describing tailgate except for certain high-level the following conditions:...
Page 114 STARTING THE ENGINE: vehicle with RENAULT Card (continued) Special note for vehicles with an - in some cases it will be necessary automatic gearbox to move the steering wheel while pressing the start button 3 to assist Depress the brake pedal with the in unlocking the steering column;...
Page 115 STARTING THE ENGINE: vehicle with RENAULT Card (continued) Operating faults In certain cases, the RENAULT Card may not work: - vehicle located in a zone of high electromagnetic radiation, - use of appliances operating on the same frequency as the card (mobile phone, video game, etc.);...
Page 116 STOPPING THE ENGINE: vehicle with RENAULT Card Never leave your vehicle with the RENAULT Card inside and never leave a child (or a pet) unsupervised. There is a risk that they could start the engine or operate electrical Conditions for stopping the...
Page 117: Special Features Of Petrol Versions
These faults may be avoided by • using leaded petrol, regularly taking your vehicle to your RENAULT Dealer at the • using oil or fuel additives which intervals specified in your Warranty are not approved by RENAULT.
Page 118: Special Features Of Diesel Versions
However, if after a few seconds and several attempts the engine fails to start, contact a RENAULT Dealer. Do not park the vehicle or run the engine in locations where combustible...
Page 119: Gear Lever / Power Assisted Steering
GEAR LEVER POWER STEERING Never drive with inadequately-charged battery. Variable power assisted steering variable assistance power steering electronic management system that adapts the level of assistance to the vehicle speed. Steering is made easier during parking manoeuvres (for added comfort) whilst the force needed to steer rises progressively as speed increases (for enhanced safety at high speeds).
Page 120: Handbrake
HAND BRAKE To apply: Pull upwards, make sure that the vehicle cannot move To release: Pull lever 1 gently upwards, push in button 2 and lower the lever to the floor. The red warning light on the instrument panel will light up if Depending on the slope you are driving with an incorrectly and/or vehicle load, it...
Page 121 • idling speed: this does not require adjustment. Your RENAULT Dealer has all the equipment necessary for ensuring • Air filter, diesel filter: A clogged that your vehicle is maintained to element hinders performance and its original standard.
Page 122 D. - If it comes on continuously, • Do not try to maintain the same contact your RENAULT Dealer as speed up a hill, accelerate no soon as possible. more than you would on the level.
Page 123 ADVICE ON FUEL ECONOMY AND DRIVING (continued) • On vehicles with conditioning, it is normal to observe an increase in fuel consumption (especially in city conditions) when it is used. For vehicles fitted with manual air conditioning, switch system when it is not required. Some advice reducing...
Page 124: Environment
• At the end of the vehicle's service life, it should be sent to approved Recycling: centres to ensure that it is RENAULT has used all its expertise recycled. to reduce environmental impact as • In all cases, comply with local far as possible at the end of the legislation.
Page 125 ENVIRONMENT (continued) Recycled plastic parts Renewable material parts 2.17...
Page 126: Tyre Pressure Monitor
Check tyre pressures, which may be purchased from including the spare wheel, once RENAULT outlets: the use of other a month. accessories could affect the correct operation of the system. 2.18...
Page 127 Tyre repair aerosols Because the valves are specially designed, only aerosols approved by RENAULT's Technical Department. Refer to the equipment instructions for the special features of these vehicles. Display Display 1 on the instrument panel...
Page 128 The tyre pressure is not suitable for Replace the wheel affected B or the speed of travel. Slow down or contact a RENAULT Dealer. inflate all four tyres to motorway This message appears along with pressure (refer to the tyre pressure table).
Page 129 ELECTRONIC STABILITY PROGRAM: ESP WITH UNDERSTEERING CONTROL This system helps to keep the Operating principle Understeer control vehicle under control in “critical” A sensor in the steering wheel This system optimises the action of driving situations (avoiding an detects the direction selected by the the ESP in the case of pronounced obstacle, loss of road holding in a driver.
Page 130 A. the engine is started, slowly turn the Contact your RENAULT Dealer. steering wheel from lock to lock to reinitialise the system. Deactivating function results in the ESP function being deactivated.
Page 131: Traction Control: Asr
TRACTION CONTROL: ASR This system helps to limit skidding on drive wheels and to control the vehicle when pulling away or accelerating. This function additional aid in case of critical driving conditions to enable the vehicle behaviour to be adapted to suit the driving conditions.
Page 132 A. automatically when the ignition is deactivate the function by pressing switched on or when a speed of Contact your RENAULT Dealer. switch 1. approximately 30 mph (50 km/h) is If the warning light comes on The “traction control deselected”...
Page 133: Anti-Lock Braking System: Abs
ANTI-LOCK BRAKING SYSTEM: ABS Under heavy braking, the system This system also allows you to You will feel pulsing through the has two principal aims, to reduce optimise stopping distances when brake pedal when the system has the stopping distance and keep your the grip of one or more wheels may been activated.
Page 134 1 - Orange warning lights light up on the instrument panel. Braking is still performed, but without system. Contact a RENAULT Dealer as soon as possible. 2 - The orange warning light and the red brake fault warning light along with and the message are lit up on the instrument panel.
Page 135 BRAKE ASSIST This system is complementary to ABS and helps reduce vehicle stopping distances. Operating principle The system is for detecting an emergency braking situation. In this case, braking assistance immediately develops maximum power trigger This function regulation. additional aid in case of ABS braking is maintained as long critical driving conditions as the brake pedal is not released.
Page 136 CRUISE CONTROL - SPEED LIMITER: limiter function Controls The speed limiter function helps you to not exceed the driving speed 1 Main ON/Off button. that you choose. 2 Limit speed memorisation and This may be useful, for example, in increase switch. town driving or in areas with speed 3 Recall of stored limit speed.
Page 137: Speed Limiter
CRUISE CONTROL - SPEED LIMITER: limiter function (continued) Warning light 6 This indicator light instrument panel lights up to indicate that the limiter function is in operation. When the function is active, the “Speed limiter” message appears on the instrument panel accompanied by dashes.
Page 138 CRUISE CONTROL - SPEED LIMITER: limiter function (continued) Driving When a limit speed is stored, the vehicle may be driven normally until the limit speed is reached. From this point, no effort on the accelerator pedal will allow you to exceed the programmed speed except emergency...
Page 139 CRUISE CONTROL - SPEED LIMITER: limiter function (continued) Exceeding the limit speed Recalling the limit speed In the event of an emergency A stored speed can be recalled by pressing button 3 until the “Speed It is possible to exceed the limit limiter”...
Page 140 CRUISE CONTROL - SPEED LIMITER: cruise control function This function additional driving aid. However, the function does not take the place of the driver. Thus, can, under circumstances, replace the driver's Controls The speed control function helps responsibility to respect speed you to maintain your driving speed 1 Main On/Off switch limits and to be vigilant (the driver...
Page 141 CRUISE CONTROL - SPEED LIMITER: cruising function (continued) Warning light 6 This indicator light instrument panel lights up to indicate that the cruise control function is in operation. When the function is active, the “Cruise control” message appears instrument panel accompanied by dashes.
Page 142 CRUISE CONTROL - SPEED LIMITER: cruising function (continued) Driving Once a cruising speed is stored and the cruise control function is active, you may lift your foot off the accelerator pedal. Switching on Varying the cruising speed Press switch 1 side.
Page 143 CRUISE CONTROL - SPEED LIMITER: cruising function (continued) Exceeding the cruising speed - press button 1, in which case the cruising speed is no longer stored. In the event of an emergency The instrument panel indicator cruising speed light going out confirms that the exceeded at any time by pressing function is stopped.
Page 144: Automatic Gearbox
AUTOMATIC GEARBOX Gear selector lever 1 Driving The gear control paddles 4 allow you to change gear while the gear P : park With the lever in position P or N, lever is in “manual mode” position R : reverse switch on the ignition.
Page 145 AUTOMATIC GEARBOX (continued) How to drive as economically as possible Leave the selector in position D on open road, depress accelerator pedal slightly to ensure automatic gear changes comparatively low engine speeds. Driving in automatic mode Place the lever 1 in the D position. You may at any time modify the gear selected automatically by using the In most traffic conditions, you will...
Page 146 AUTOMATIC GEARBOX (continued) Accelerating and overtaking Depress the accelerator pedal fully that goes beyond kickdown point). This will enable you to change down to the optimal gear within the engine range. Driving in manual mode With the gear lever 1 in position D, pull the lever to the left (changing gear using the lever).
Page 147 AUTOMATIC GEARBOX (continued) - In cold weather, start the engine and wait a few seconds before moving the selector lever from position P or N and engaging it in D or R to prevent the engine stalling. - Vehicles not fitted with traction control: on a slippery surface or surface with a low level of adhesion, change to manual mode...
Page 148 (continued) Operating faults - when driving, if the “check gearbox” message appears on the instrument panel, it indicates a fault. Consult your RENAULT Dealer as soon as possible. - when driving, if the “gearbox overheating” message appears on instrument panel,...
Page 149: Quickshift Gearbox
QUICKSHIFT GEARBOX Gear lever 1 Display Paddles 6 - This allows you to shift directly 2 automatic mode Like the lever, they allow you to from first gear to reverse gear, to change gear: 3 gear display select reverse gear and neutral and - while driving, 4 brake pedal depressed indicator to change gear in manual mode.
Page 150 RENAULT Card. Neutral N will then be selected The level of oil in the automatic transmission system tank varies according automatically and the engine will to use. Adding oil is strictly forbidden (except by qualified RENAULT start. Network personnel). 2.42...
Page 151 QUICKSHIFT GEARBOX (continued) Operation in automatic mode Automatic mode is selected by Note: default every time the ignition is Automatic mode takes account of: switched on. - the position speed It can be activated or deactivated at depression accelerator any time when the engine is pedal to assess driving style and running by pushing the lever to the select the optimum gear,...
Page 152 QUICKSHIFT GEARBOX (continued) Changing mode system does accept The mode (automatic/semi-automatic) downshifts which would generate a may be changed at any time by high engine speed or upshifts which pushing the lever to the left. The would cause low engine speed. mode is changed without changing gear.
Page 153 QUICKSHIFT GEARBOX (continued) The system will not tolerate a series The vehicle will move off again: of up or down changes that cause - either slowly, if you release the the engine to underrev or overrev. brake without accelerating (e.g. when in a traffic jam), Pulling right-hand...
Page 154 QUICKSHIFT GEARBOX (continued) Snow mode is deselected every time Parking the engine is switched off. It will be It is possible to park in gear (for necessary to select it again. example, on a slope). To do this: - with the ignition on, select a gear with the brake pedal depressed, Accelerating and overtaking - check that a gear other than N is...
Page 155 - switch on the ignition; not function perfectly. However, • It is possible to engage first gear - select neutral; you should consult a RENAULT from neutral or while stationary - push or tow the vehicle or roll it Dealer as soon as possible.
Page 156: Parking Proximity Sensor
5 second continuous The driver should always pay beep as a warning when reverse gear attention to sudden incidents is selected. Contact your RENAULT during driving: always ensure that Dealer. there are no moving obstacles (such as a child, animal, pram or bicycle, etc.) or small, narrow...
Page 157 PARKING PROXIMITY SENSOR (continued) Temporary deactivation of the Prolonged deactivation of the system system Press switch 1 to deactivate the You can deactivate the system system. permanently by pressing the switch for longer than approximately three The indicator light built into the seconds.
Page 158 2.50...
Page 159 Section 3: Your comfort Air vents ..............................3.02 - 3.03 Heating and air conditioning ......................3.04 3.17 Electric windows ..........................3.18 3.20 Electrically controlled sunroof ......................3.21 - 3.22 Sun visor ................................3.23 Interior lighting ..............................3.24 Storage compartments / passenger compartment fittings ..............3.25 3.28 Ashtrays / Cigarette lighter ..........................
Page 160 AIR VENTS (air outlets) 1 - left-hand front window demister 5 - control panel 6 - Right-hand side air vent 2 - left-hand side air vent 7 - Right-hand side window demister 3 - windscreen demister outlets vent 4 - Centre air vents 8 - Footwell heater outlet 3.02...
Page 161: Air Vents
AIR VENTS (continued) Air flow Direction Turn wheel 1 or 3 (beyond the point Right / left: move slides 2 or 4. of resistance). Up / down: lower or raise slides 2 or 4. A: closing. B: maximum opening. 3.03...
Page 162: Heating And Air Conditioning
HEATING AND AIR CONDITIONING The controls A - Adjusting passenger E - Heated rear screen and heated compartment air distribution. door mirror control indicator light (depending on B - Air temperature adjustment. vehicle). C - Ventilation speed adjustment. F - Air conditioning control and warning light (depending on D - Air recirculation control.
Page 163 HEATING / VENTILATION (continued) Position The air flow is directed mainly towards the passenger footwell. Position The air flow is directed to all the air vents and the front and rear passenger footwells. This is the recommended position for the best temperature in hot weather.
Page 164 HEATING / VENTILATION (continued) Adjusting the air temperature Turn control B to obtain the desired temperature. The further the slide is in the red, the more the temperature will be increased. When the air conditioning system is used for long periods, it may begin to feel cold.
Page 165 HEATING / VENTILATION (continued) recirculation operation (isolating passenger compartment) Turn control towards Air recirculation is for: - isolating the vehicle from the recirculation symbol Prolonged use of this position can external atmosphere (driving in lead to condensation forming on In these conditions air is taken from polluted areas, etc.), the side windows and windscreen the passenger compartment and is...
Page 166 AUTOMATIC AIR CONDITIONING 12 - Heated rear screen and heated door mirrors (depending on vehicle). 13 - Heated rear screen indicator light. 14 - Air recirculation control. Information operating instructions: refer to the end of the paragraph “heating/air conditioning”. 13 12 11 10 The controls 1 - “clear view”...
Page 167 AUTOMATIC AIR CONDITIONING (continued) - press button 7 to increase the temperature, - press button 4 to decrease the temperature. Note: The maximum and minimum settings of 15 °C and 27 °C allow the system to produce a minimum or maximum temperature, whatever the ambient conditions.
Page 168 AUTOMATIC AIR CONDITIONING (continued) Ambient temperature: (automatic mode) (continued) Operation To reach and keep the chosen comfort level and to maintain good visibility, the system controls: - ventilation speed, - the air distribution, - the air recirculation management, - starting stopping conditioning, The displayed temperature values...
Page 169 AUTOMATIC AIR CONDITIONING (continued) Adjusting automatic mode The automatic mode is the normal operating mode of the system (indicator light 6 on), but you may alter the selections made by the system (air distribution, etc.). These options are explained on the following pages.
Page 170 AUTOMATIC AIR CONDITIONING (continued) Position The air flow is directed to all the windscreen demisting vents and the passenger footwell. Position The air flow is only directed to the passenger footwells. 13 12 1110 Distribution passenger compartment Position There are 5 air distribution settings All the air flow is directed to the available, which are obtained by demisting vents for the windscreen...
Page 171 CLIMATE CONTROL (continued) Varying the ventilation speed In automatic mode, the system uses the most suitable amount of air to reach and maintain the desired comfort level. Exit automatic mode by pressing buttons 9 and 11. These buttons allow you to increase or decrease ventilation speed.
Page 172 CLIMATE CONTROL (continued) 13 12 Heated rear screen Press button 12: operating warning To exit this function, press button light 13 lights up. 12 again. If this does not occur, demisting stops automatically. This function permits rapid demisting/de-icing rear screen and de-icing of the door mirrors (depending on version).
Page 173 CLIMATE CONTROL (continued) Note.: if you wish to reduce the air flow (which may produce a certain amount of noise in the passenger compartment), press button 11. To exit this function, press either: - button 1 again, - button 6 (the AUTO warning light on the display illuminates).
Page 174 CLIMATE CONTROL (continued) Air recirculation mode Pressing button 14 activates air Prolonged use of this function may recirculation (the symbol lights up lead odours caused on the display). non-renewal formation of condensation on the During recirculation, air is taken windows. from the passenger compartment and is recycled, with no air being We therefore advise you to return to...
Page 175 Operating faults conditioning, switch off the system Generally, in the event of an when it is not required. operation fault, consult your RENAULT Dealer. Some advice reducing - Reduction in de-icing, demisting consumption therefore or air conditioning performance. helping...
Page 176: Electric Windows
ELECTRIC WINDOWS From the front passenger seat With the ignition on: - press the button to open the Operate button 6. window to the desired height (note: the rear windows do not open fully), - lift the switch of the concerned Safety of rear occupants window to get it to the desired The driver can inhibit operation of the rear electric windows and...
Page 177 ELECTRIC WINDOWS / ONE-TOUCH ELECTRIC WINDOWS (continued) Safety of rear occupants The driver can inhibit operation rear electric windows and doors by pressing switch 4 on the side of the drawing. From the rear seats The “one-touch” mode is an added feature to the operation of the Driver's responsibility Operate switch 7.
Page 178 Manual window winders whilst closing (someone's fingers, one second to reset the system. Turn winder 1. an animal's paw or the branch of a necessary, consult your tree, for example), it stops and RENAULT Dealer. lowers by several centimetres. 3.20...
Page 179 ELECTRIC SUNROOF Driver's responsibility Tilting the sunroof The system operates: Never leave your vehicle - with the ignition on, - to open: turn button 2 to position A; with the key in the ignition - with the ignition off until the - closing: turn button 2 to position 0.
Page 180 Sunroof closing operating fault with the operation of the sunroof. In this case, check that there is no Consult your RENAULT Dealer for obstacle, then turn button 2 to details of possible adaptations; position 0, then press button 3, until the sunroof closes completely.
Page 181: Sun Visor
SUN VISOR Rear sun visor blind Front sun visor Courtesy mirrors, with lighting Pull the sun blind upwards using Lower sun visor 9. On equipped vehicles, lighting 11 is the tab until both hooks 8 lock into automatic. their housings (make sure the blind Non-lit courtesy mirror is properly locked in position).
Page 182: Interior Lighting
INTERIOR LIGHTING Map reading lights (depending on vehicle) Press switch 1 for the driver, 3 for the front passenger. Courtesy light Driver's and passenger floor bin lid lights 4 Press switch 2 for: (depending on vehicle) - permanent lighting, - intermittent lighting which comes on when a door is opened.
Page 183 REAR STORAGE COMPARTMENTS/ PASSENGER COMPARTMENT FITTINGS Front door storage pockets 1 Driver's and passenger footwell Sunglasses holder 3 storage compartments 2 They can hold a 1.5 litre bottle. This can be used for storing CDs, vehicle documentation (Driver's Handbook, Warranty and Servicing booklet, etc.), pocket torches, etc.
Page 184 STORAGE COMPARTMENTS, MODIFICATIONS / PASSENGER COMPARTMENT FITTINGS (continued) Stowage well 4 Centre console storage compartment 5 or 6 This can be used for storing motorway tickets, cards, etc. This can be used for storing a mobile ashtray, cup-holder, etc. 3.26...
Page 185: Storage Compartments / Passenger Compartment Fittings
STORAGE COMPARTMENTS / PASSENGER COMPARTMENT FITTINGS (continued) Rear door storage compartment 7 Rear door storage compartment 8 Passenger storage compartment 9 Pull handle 10 to open. 3.27...
Page 186 STORAGE COMPARTMENTS / PASSENGER COMPARTMENT FITTINGS (continued) Front seat storage pockets 12 For vehicles equipped with climate control, this storage compartment, like the passenger compartment, ventilation conditioning. Turn blanking piece 11 to open or close the air inlet. 3.28...
Page 187: Ashtrays / Cigarette Lighter
Pull it out to use. After use, replace it without pushing it all the way in. The cigarette lighter is provided connecting accessories approved RENAULT's Technical Department, with a maximum power of 120 watts (12 V). 3.29...
Page 188: Rear Bench Seat: Functions
REAR BENCH SEAT: functions The seat and the seatback may be Then lift the rear section 1 of the To fold down the seatback folded down in one or two parts to cushion and turn the seat base to Remove the rear headrests (if allow bulky objects to be carried.
Page 189 REAR BENCH SEAT: functions (continued) To replace the seat base, proceed in Then push the front 3 of the cushion the reverse order of removal. A in order to lock the seat base. Lift the bench seat cushion in order To replace the seat base, proceed in •...
Page 190 REAR PARCEL SHELF / TRANSPORTING OBJECTS IN THE LUGGAGE COMPARTMENT Rear parcel shelf Locations for anchorage points 3 To remove: These securing items transported luggage - unhook both return straps 1, compartment (see “transporting - unhook sun blind 2 (depending on objects luggage vehicle),...
Page 191 TRANSPORTING OBJECTS IN THE LUGGAGE COMPARTMENT (continued) Always position objects If you have to place objects on the transported so that the largest folded seatback, with the bench seat surface is against: in 3-seat position, lift the front headrests before folding seatback so that is can be folded as flat as possible against the seat base.
Page 192: Roof Bars
1 without plugging Only bolts supplied with documentation. the holes afterwards. RENAULT roof bars should be Authorised load on roof rack: refer used to fit the roof bars onto the to the information on “weights” in vehicle. Section 6. 3.34...
Page 193 When removing roof bars, make vehicle, we advise you to consult sure that you replace the cover. your RENAULT Dealer Refer manufacturer's instructions for information on how to fit and use the roof rack bar. Please keep these instructions with...
Page 194: Hands-Free Telephone Integral Control
Please keep these instructions that it can be fitted in the vehicle. with the rest of the vehicle Consult your RENAULT Dealer. documentation. 3.36...
Page 195 Section 4: Maintenance Bonnet ..............................4.02 - 4.03 Engine oil level / Oil change ......................4.04 4.07 Levels: Engine coolant ............................. 4.08 brake fluid ............................4.09 Windscreen/headlight washer reservoir .................... 4.10 Filters ................................. 4.10 Battery ................................4.11 Bodywork maintenance ......................... 4.12 - 4.13 Interior trim maintenance ..........................
Page 196: Bonnet
BONNET Bonnet safety catch To open, pull handle 1, located on the left-hand side of the dashboard. To open, push tab 2 to the left as you open the bonnet. Take care when working in the engine compartment as the engine cooling fan may start to operate at any moment without warning.
Page 197 3 in the bonnet. In the event of an impact, even slight, against the radiator grille or bonnet, have the bonnet catch checked by a RENAULT Dealer as soon as possible. Check that the bonnet is correctly locked. 4.03...
Page 198 Message 1 Level satisfactory However, contact your RENAULT Dealer if more than 0.5 litres is being consumed every 600 miles Message 2 (1,000 km) after the running in Level display function period.
Page 199 ENGINE OIL LEVEL (continued) Reading level instrument panel (continued) Consult your RENAULT Dealer at advance trip computer once if you notice an abnormal or reading, press the button again. repeated drop in any of the fluid - if the level is minimum: the“Oil”...
Page 200 ENGINE OIL LEVEL (continued) 1.2 16V 1.4 16V - 1.6 16V 1.5 dCi Topping up/filling The vehicle must be parked on level - Unscrew cap 1. ground and the engine should be - top up the level (for information, cold (for instance, before the engine capacity between is started up for the first time in the...
Page 201: Engine Oil Level / Oil Change
Take care when working in the engine compartment as Consult your RENAULT Dealer at the engine cooling fan may once if you notice an abnormal or start to operate at any repeated drop in any of the fluid moment without warning.
Page 202 (very severe damage is likely to be caused to the engine if it runs out of coolant). If topping up is required, only use products approved by RENAULT's Technical Department: - anti-freeze protection; - anti-corrosion protection of the cooling system.
Page 203: Brake Fluid
After operation hydraulic circuit, a specialist must replace the brake fluid. Only use fluids approved by RENAULT's Technical Department (and taken from a sealed container). Replacement interval Refer to the warranty and servicing booklet for your vehicle. Brake fluid level...
Page 204: Windscreen/Headlight Washer Reservoir
LEVELS FILTERS (continued) replacement filter components (air filter, cabin filter, diesel filter, etc.) is scheduled in the maintenance operations for your vehicle. Frequency replacing filter elements: refer to the warranty and servicing booklet for your vehicle. Windscreen/headlight washer Jets reservoir Use a needle-type tool to adjust the angle of the windscreen washer jets.
Page 205: Battery
If it does, wash the affected sure that it is replaced with a area with plenty of cold water. battery that enables this pipe to be connected. Contact your RENAULT Ensure naked flames, red-hot Dealer. objects and sparks do not come into contact with the battery as there is a risk of explosion.
Page 206: Bodywork Maintenance
- saline atmosphere (near the sea, • Use solvents not approved by adequate precautions are not particularly in hot weather), RENAULT's Technical Department taken, this could give rise to - seasonal and damp climatic to remove stains as this could corrosion or operational faults.
Page 207 RENAULT's Technical Department your RENAULT anti-corrosion discolour paintwork and may to protect them after they have warranty. Refer to the warranty even cause the paint to peel off been cleaned.
Page 208: Interior Trim Maintenance
RENAULT's Technical Department passenger compartment: unless • washing up liquid (with one part (RENAULT accessory outlets) or carefully used, such equipment washing up liquid to 200 parts warm soapy water and a sponge water). could interfere...
Page 209 Interior lights (replacing bulbs) ......................5.16 - 5.17 Fuses ............................... 5.18 - 5.19 Battery ..............................5.20 5.22 Radio frequency remote control: battery ......................5.23 RENAULT Card: battery ........................... 5.24 Fitting a radio/accessories ........................5.25 - 5.26 Wipers (replacing blades) ........................5.27 - 5.28 Towing ..............................5.29 5.31 Operating faults ............................
Page 210 EMERGENCY SPARE WHEEL The emergency spare wheel is - Unscrew nut 4 anticlockwise until - pull the wheel towards you, located underneath the vehicle. it comes off completely, then place - lay the wheel down flat and the palm of your hand on section - Open the tailgate;...
Page 211: Emergency Spare Wheel
EMERGENCY SPARE WHEEL (continued) To wind a wheel back up After changing a wheel, position the Position yourself behind the vehicle replaced wheel on support 9, with and pull handle 5 to raise the wheel To carry out this operation, the valve facing ground.
Page 212 EMERGENCY SPARE WHEEL (continued) Note: if the tool kit does not lock in If the spare wheel has been place, check the tightness of nut 4 stored for several years, and the correct positioning of have it checked by your handle 5.
Page 213 TOOL KIT Wheelbrace 3 This is used to tighten or release the wheel bolts. Towing ring 4 Refer information “towing” in Section 5. Hubcap spanner 5 or 6 This spanner is used to remove hubcaps. Jack 7 Storage compartments 1 The tool kit A is located in the Remove jack 7.
Page 214 HUBCAP - WHEEL Hubcap (example: hubcap 1) Central wheel hubcap (example: hubcap 4) Remove the wheel trim using hubcap spanner 3 (from the tool kit) Remove the hubcap using the by inserting the hook in the recess hubcap spanner 6 (located in the near the valve 2.
Page 215: Changing A Wheel
CHANGING A WHEEL Turn a few times to lift the wheel off the ground. Undo the bolts and take the wheel off. Fit the spare wheel on the central hub and turn it to locate the mounting holes in the wheel and the hub.
Page 216: Tyres (Tyre Safety, Wheels, Winter Use)
If such RENAULT Dealer. incidents occur, have condition of these parts checked by a RENAULT Dealer. 5.08...
Page 217 TYRES (continued) Tyre pressures Pressures should be checked when Fitting new tyres the tyres are cold; ignore higher Tyre pressures must be adhered to, pressures which may be reached in tyre pressures wheels hot weather or following a fast (including the spare wheel) must be For safety reasons, this journey.
Page 218 In all cases, we would recommend Only certain chains can be fitted that you contact your RENAULT to tyres. Contact your RENAULT Dealer who will be able to advise Dealer. you on the choice of equipment which is most suitable for your vehicle.
Page 219: Headlights (Replacing Bulbs)
55 W bulbs. your bulbs replaced your bulb concerned. RENAULT Dealer. (using any other type of bulb could Release spring. damage the headlight). Direction indicator lights Remove bulb 3 or bulb 5. The bulbs are under pressure and Turn the bulb holder C one can break when replaced.
Page 220 HALOGEN HEADLIGHTS: replacing bulbs (continued) Front side light Anti-U.V. type bulb (see box): Remove cover C then pull bulb As the headlights have holder 4 to access the bulb. plastic lenses, you must H1 or H7 Bulb type: W5W. use anti-UV 55 W bulbs. Do not touch the bulb glass.
Page 221 FRONT LIGHTS: front fog lights / additional long-range lights Additional lights If you wish to fit “anti-fog” or “long range” headlights to your vehicle, consult a RENAULT Dealer. Front fog lights 1 Replacing a bulb: Contact your RENAULT Dealer. Bulb type: H11.
Page 222: Rear Lights: Replacing Bulbs
REAR LIGHTS: replacing bulbs After opening the tailgate, remove Release the rear light assembly from 4 Side lights and stop lights bolts 1. outside the vehicle by pulling it P21/5 W bulb. towards the rear. 5 Direction indicator light Unclip the bulb holder 2 to access the bulbs.
Page 223 High-level brake light 8 Registration plate lights 9 Side-mounted indicator repeaters 10 Contact your RENAULT Dealer. Unclip light 9 by pressing the tab. Unclip the side repeater (using a flat Remove the light cover to gain blade screwdriver type tool).
Page 224 INTERIOR LIGHTING: replacing the bulbs Courtesy light Door lights 2 Unclip the transparent cover (using Unclip the light and remove the a flat blade screwdriver type tool). bulb using a pen or flat blade screwdriver. Remove the bulb concerned. Bulb type: C5W. Bulb type 1: W5W.
Page 225 INTERIOR LIGHTING: replacing the bulbs (continued) Luggage compartment light Using a flat blade screwdriver or Press tab 4 to release the bulb holder similar tool, unclip light 3 by and gain access to bulb 5. pressing the tabs on each side of the light.
Page 226: Fuses
(risk of fire) in the event of a consumer drawing an excessive accordance with local current. legislation or as a precautionary measure: Obtain a box of spare bulbs and fuses from your RENAULT Dealer. 5.18...
Page 227 Child safety However, because they can be difficult to access, you are advised Manual air conditioning to have your fuses replaced by a Electric windows RENAULT Dealer. Front cigarette lighter Passenger compartment ventilation ABS / E.P.S. General supply Driver's electric window...
Page 228 BATTERY: breakdown To avoid all risk of sparks: - Make sure “electrical consumers” switched before disconnecting reconnecting the battery. - When charging, stop the charger before connecting disconnecting the battery. - Do not place metal objects on the battery to avoid creating a short circuit between the terminals.
Page 229 Special procedures may for short journeys or for frequent be required to charge driving in town. some batteries. Contact your RENAULT Dealer. Avoid all risk of sparks which cause immediate explosion and charge the battery in a well-ventilated area. Risk of serious injury.
Page 230: Battery
A and B in the RENAULT Dealer or, if you already inverse order (4-3-2-1). have jump leads, ensure that they are in perfect condition. The two batteries must have an identical voltage: 12 volts. The...
Page 231 Do not throw away your used batteries, give them Batteries can be obtained from organisation your RENAULT Dealer. responsible for collecting These batteries should last about and recycling batteries. two years. 5.23...
Page 232: Renault Card: Battery
RENAULT CARD: BATTERY Replacing the battery The “Change card battery” message appears on the instrument panel. Pull firmly on emergency key 2. Replace battery 1, observing the polarity shown on the emergency key. After the operation, the “Change card battery” message no longer appears on the instrument panel.
Page 233 RENAULT Dealer. • In all cases, follow the manufacturer's fitting instructions carefully. • The specifications of the brackets and wires (available at RENAULT accessory outlets) vary depending on the equipment level of your vehicle and the type of radio. Contact your RENAULT Dealer to find out the correct reference number.
Page 234 RENAULT will provide a warranty. Electrical and electronic accessories • Only RENAULT technicians are Using telephones and CB permitted to carry out work on equipment. the vehicle's electrical circuit. Incorrect connection...
Page 235 WINDSCREEN WIPER BLADES To refit To refit the wiper blade, proceed in reverse order to removal. Make sure that the blade is correctly locked in position. Replacing windscreen wiper Lower tab 2. Clean your windscreen and your blades 1 rear screen regularly. Push blade forwards...
Page 236 WINDSCREEN WIPER BLADES (continued) To refit To refit the wiper blade, proceed in reverse order to removal. Make sure that the blade is correctly locked in position. Clean your windscreen and your rear screen regularly. Rear window wiper 5 - Lift the wiper arm 6; - Move the blade 5 until some resistance is met.
Page 237 When engine vehicle. Contact your RENAULT stopped, steering Dealer. braking assistance are not operational. 5.29...
Page 238 Neutral position, and for a - RENAULT specifies the distance not exceeding 30 miles use of a rigid towing bar. (50 km).
Page 239 TOWING (attachments) Permissible nose weight, maximum permissible towing weight, braked and unbraked: refer information “Weights” in Section 6. Refer manufacturer's instructions for information on how to fit and use the roof rack bar. Please keep these instructions with rest vehicle documentation.
Page 240 OPERATING FAULTS The following advice will enable you to carry out quick, albeit temporary repairs. For safety reasons you should always contact a RENAULT Dealer as soon as possible. Using the RENAULT CAUSES REMEDIAL ACTION • The RENAULT Card does unlock...
Page 241 OPERATING FAULTS (continued) The following advice will enable you to carry out quick, albeit temporary repairs. For safety reasons you should always contact a RENAULT Dealer as soon as possible. The starter is activated CAUSES REMEDIAL ACTION • There is no response, the indicator Discharged battery.
Page 242 Starting conditions are not fulfilled. Refer to the “starting the engine” RENAULT Card). information in Section 2. The RENAULT Card does not work. Insert the card in the card reader in order to start the engine. Refer to the “starting the engine”...
Page 243 • Abnormal white smoke from the Mechanical fault: damaged cylinder Stop the engine. exhaust. head gasket. Contact a RENAULT Dealer. • Vibrations. Tyres not inflated to correct pressures, Check tyre pressures. If this is not the incorrectly balanced or damaged.
Page 244 Section 4). - at idle speed, Low oil pressure. Contact the nearest RENAULT Dealer. - is slow to go out or remains lit on Low oil pressure. Stop: contact a RENAULT Dealer.
Page 245 Reminder: only products approved by RENAULT's Technical Department may be used for this purpose.
Page 246: Wipers (Replacing Blades)
Find the earth wire which is attached to a metal body part, scrape the end of the earth wire and reattach it carefully. On both sides: - Fuse blown. Replace the fuse. - faulty flasher sensor. To replace, contact a RENAULT Dealer. 5.38...
Page 247: Operating Faults
Check and replace if necessary. • The headlights do not switch off. Faulty electrical controls. Contact your RENAULT Dealer. • Traces of condensation in the lights. This is not a fault. The presence of traces of condensation in lights is a...
Page 248 5.40...
Page 249 Section 6: Technical specifications Vehicle identification plates ......................... 6.02 - 6.03 Dimensions ................................ 6.04 Engine specifications ............................6.05 Towing weights ............................6.06 - 6.12 Weights ..............................6.06 6.12 Replacement parts ............................6.13 6.01...
Page 250 VEHICLE IDENTIFICATION PLATES Quote the vehicle identification plate (right-hand side) and engine plate references when writing or ordering parts. Vehicle identification plate A 1 Vehicle type and chassis number 6 Technical specifications This information is repeated on vehicle marking B. 7 Vehicle paint code 2 Maximum permissible...
Page 251 VEHICLE IDENTIFICATION PLATES (continued) 1.2 16V 1.4 16V - 1.6 16V The information shown on the engine plate C should be quoted on all your letters or orders. C - Engine plate or engine label (Location varies depending on engine) 1 Engine type 2 Engine suffix.
Page 252 DIMENSIONS (in metres) 0,805 2,575 0,606 1,472 (1)/1,458 (2)/1,472 (3) 3,986 1,495* Depending on tyres fitted: (1) 165/65 R15 81 T (2) 185/60 R15 84 H 1,470 (1)/1,456 (2)/1,450 (3) (3) 195/50 R16 88V 1,719 * Empty 6.04...
Page 253 Only use the spark plugs specified for your vehicle’s engine. The type should be marked on a label stuck inside the engine compartment. If it is not then contact your – RENAULT Dealer. Fitting spark plugs which are not to specification may damage the engine. 6.05...
Page 254 WEIGHTS (in kg) - Basic vehicle with no options; may change during the year and depending on the country of marketing: consult your RENAULT Dealer. 5-door petrol versions 1.2 16V 1.4 16V 1.6 16V (versions marketed depend on country) Vehicle type...
Page 255 - It is important to comply with the towing weights, governed by local legislation in each country and, in particular laid down in the Road Traffic Regulations. Consult your RENAULT Dealer about any attachments. Under no circumstances may the gross train weight (= Maximum permissible all-up weight plus weight towed) be exceeded.
Page 256 WEIGHTS (in kg) - Basic vehicles with no options, susceptible to development over the course of the year and according to country of marketing: consult your RENAULT Dealer. 3-door petrol versions 1.2 16V 1.4 16V 1.6 16V (versions marketed depend on country)
Page 257 - It is important to comply with the towing weights, governed by local legislation in each country and, in particular laid down in the Road Traffic Regulations. Consult your RENAULT Dealer about any attachments. Under no circumstances may the gross train weight (= Maximum permissible all-up weight plus weight towed) be exceeded.
Page 258 WEIGHTS (in kg) - Basic vehicle with no options; may change during the year and depending on the country of marketing: consult your RENAULT Dealer. 5-door diesel versions 1.5 dCi (versions marketed depend on country) Vehicle type BR0G BR0F BR0H...
Page 259 - It is important to comply with the towing weights, governed by local legislation in each country and, in particular laid down in the Road Traffic Regulations. Consult your RENAULT Dealer about any attachments. Under no circumstances may the gross train weight (= Maximum permissible all-up weight plus weight towed) be exceeded.
Page 260 WEIGHTS (in kg) - Basic vehicle with no options; may change during the year and depending on the country of marketing: consult your RENAULT Dealer. 3-door diesel versions 1.5 dCi (versions marketed depend on country) Vehicle type CR0G CR0F CR0H...
Page 261 SPARE PARTS AND REPAIRS Original RENAULT parts are based on strict specifications and are regularly tested. Therefore, they are of at least the same level of quality as the originally fitted part. If you always fit genuine RENAULT parts to your vehicle, you will ensure that it performs well. Furthermore, repairs carried out within the RENAULT Network using original replacement parts are guaranteed according to the conditions set out on the reverse of the repair order.
Page 262 ALPHABETICAL INDEX A ABS ..............2.25 - 2.26 C Coolant ..............4.08 Accessories ..............5.25 Courtesy lights ..........3.24 - 5.16 Accessories socket (cigarette lighter) ...... 3.29 Courtesy mirrors ............3.23 Additional headlights ..........5.13 Cruise control ..........2.32 2.35 Adjusting your driving position ....
Page 263 ALPHABETICAL INDEX F Faults (operating faults) ......5.32 5.39 L Lashing rings (location) ........... 3.32 Filter: air filter ............4.10 Levels ............4.04 4.11 oil filter ............4.08 Lifting the vehicle (changing a wheel) ....5.07 Fog lights ............1.94 - 5.13 Lighting: exterior .........
Page 264 1.82 Rear seats (operation) ........3.30 - 3.31 Tyre Pressure Monitor ......... 2.18 2.20 RENAULT Card: use ....1.02 1.04 - 1.13 - 1.14 Tyre pressures ..........0.04 - 0.05 RENAULT Card: battery ........... 5.24 Tyre pressures ..........0.04 - 5.09 Replacement parts ............
Page 266 Driver's handbook – 82 00 492 669 – NU 747-1 – 11/2004 – Edition anglaise...

Renault CLIO 2004 Manual

Quick Links

Related Manuals for Renault CLIO 2004

Summary of Contents for Renault CLIO 2004

Table of Contents
