Configuring IP Address
3. At the "POC2502 Series#" prompt, enter "configure".
4. At the "POC2502 Series (config)#" prompt, enter the
following command and press <Enter> as shown in Figure
4.
POC2502 Series(config)# ip address 192.168.1.100
mask 255.255.255.0
POC2502 Series(config)# ip default-gateway
192.168.1.254
The previous command would apply the following settings for
the Switch.
IP Address: 192.168.1.100
Subnet Mask: 255.255.255.0
Gateway: 192.168.1.254
Figure 4: IP Address Screen
5. Repeat Step 1 to check if the IP address is changed.
If the IP is successfully configured, the POC2502 Managed
Switch will apply the new IP address setting immediately. You
can access the Web interface of the POC2502 Managed
Switch through the new IP address.
If you are not familiar with the console command or
the related parameter, enter "?" anytime in console
to get the help description.

Saving the Configuration via the Console

In the switch, the running configuration file stores in the RAM.
In the current version, the running configuration sequence
running-config can be saved from the RAM to FLASH by
writing the command or copying the running-config startup-
config command, so that the running configuration sequence
becomes the startup configuration file, which is called
configuration save.
1.
At the "POC2502 Series#" prompt, enter "copy running-
config startup-config" as shown in Figure 5.
IFS POC2502 Series Quick Start Guide
Figure 5: The Configuration Screen

Starting Web Management

The following shows how to start up the Web Management of
the POC2502 Managed Switch. Note, the POC2502 Managed
Switch is configured through an Ethernet connection. Please
make sure the manager PC must be set on the same IP
subnet address.
For example, the default IP address of the POC2502 Managed
Switch is 192.168.0.100, then the manager PC should be set
at 192.168.0.x (where x is a number between 1 and 254,
except 100), and the default subnet mask is 255.255.255.0.
Figure 6: IP Management Diagram
Logging in to the Managed Switch
1.
Use Internet Explorer 8.0 or above Web browser and
enter IP address http://192.168.0.100 to access the Web
interface.
2.
When the following dialog box appears, please enter the
default user name and password "admin". The login
screen in Figure 7 appears.
Default Username: admin
Default Password: admin
Figure 7: Login Screen
3
