AVS A4
Certification:
Test Report XF2244/R1
•
This product complies with AS/NZS 4601:1999 including amendment 1, 2003
•
AVS A5
Certification:
Test Report XF2106/R2
•
This product complies with AS/NZS 3749.1 2003 Class A. Volumetric Sensing (glass break/shock) must be enabled
•
to comply with a Class A installation (refer Programmable Features).
Class A VSAS (Vehicle security alarm system) includes control equipment including setting and unsetting facilities,
•
all sensors, warning devices and provisions for immobilization of the vehicle and the volumetric sensing device
(glass break/shock)
AVS A-Series – AVS A4/A5
Installation manual
Generation 2 Version 6
A4 Serials: 4406037 – Current
A5 Serials: 5403781 – Current
Make sure you are using the correct manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AVS A Series
Summary of Contents for AVS A Series
- Page 1 AVS A-Series – AVS A4/A5 Installation manual Generation 2 Version 6 A4 Serials: 4406037 – Current A5 Serials: 5403781 – Current Make sure you are using the correct manual AVS A4 Certification: Test Report XF2244/R1 • This product complies with AS/NZS 4601:1999 including amendment 1, 2003 •...
- Page 2 Manta help line 09 476 8052 AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
-
Page 3: Table Of Contents
Negative on alarm / pager out • Inhibit / enable mode selection for factory remote interface inputs • Installer mode • Past alarm trigger memory • Factory remote interface (MAP function) on/off AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... - Page 4 Vacuum CDL system • Single wire CDL system • Flow thru CDL system • Remote boot release diagram Optional siren diagrams 3 extra control channels from AVS remote (requires RXPRO/RCX-4) Trouble shooting guide AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
-
Page 5: Introduction
The polyfuse may take several minutes to reset. Auto-immobilisation: The AVS system will automatically immobilise 38 seconds after the ignition is switched OFF. The LED will light solid to indicate it is in auto immobilise mode. Arm by remote: Press the button on the remote. - Page 6 The panic feature will not work when the ignition is switched on. The panic button can also be programmed to operate instantly when the button is pushed (refer Register 1, Feature 18). AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
-
Page 7: Boot Release Output (150Ma Max)
60 seconds. This feature is off by default but it is recommended that it be programmed on (refer Register 2, Feature 4). AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... -
Page 8: Additional Features
Intelligent glass break sensor (AVS A5): The AVS A5 includes an intelligent glass break sensor. It will only trigger the alarm when it registers the correct sound frequency parameters for breaking glass and the shock sensor also registers a corresponding vibration/impact to the vehicle (the shock sensor on the A5 is used only for the digital glass break sensor and does not detect shock by itself). -
Page 9: Remote Controls
Wait for the indicators and LED to flash once. (If the alarm is armed you will not be able to see the indicator flash so instead look for the LED flash). Now, repeat for the second PIN digit and wait for the indicators/LED to flash. Repeat until all five digits are entered. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... - Page 10 NOTE: Unless a remote control is learnt in you will need to repeat the procedure every time you wish to start the car. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
-
Page 11: Wiring Instructions
Plug connector (looking at alarm socket with wires facing): If a tag is accidentally cut, or accessories are being added to the AVS A-Series alarm at a later date, it is possible to trace the required wires by first un-clipping the case. Next, slide the circuit board out to expose the main connector plug. -
Page 12: Data Battery Back-Up Siren V2 Wiring
Data battery back-up siren wiring (DBBSMV2) The AVS data siren V2 has the following wires located on it: Red: connect to +12V wire from alarm module bundled with other alarm wires, marked with red and white sheathing. Ensure the 12v supply is fused. -
Page 13: Plug Pin # To Connection
(2 wires) to comply with AS/NZS installation standards. SIREN - Connect this wire to the white wire on the AVS data siren V2. Up to two data sirens can be connected. Note: You can only connect the specially coded AVS data battery back-up siren V2. This output is not compatible with any other AVS siren or any other brand of siren as coded data is transmitted to turn the siren on and off. - Page 14 IM3A wires. Now connect the other end to the IM3B two IM3B wires. To meet AS/NZS installation standards, make sure the cut is made wires) more than 300mm from the starter or ignition immobiliser cuts. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
- Page 15 AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
-
Page 16: Changing Programmable Features
Changing programmable features The AVS A-Series programming mode is very quick and easy to use. Follow the steps below to change any of the programmable features: Find the Register (1 or 2) in which the feature is located. Set the vehicle up as described to access the required Register. e.g. to access Register 1 close all doors, bonnet and boot, arm and disarm alarm then turn ignition on, off and back on. - Page 17 When this feature is ON, the –ARM wire changes to become ‘negative on alarm’ Description: instead. Can be used to power pagers or internal sirens. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
-
Page 18: Inhibit / Enable Mode Selection For Factory Remote Interface Inputs
LED will flash and the siren chirp three times for shock sensor. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... - Page 19 The last memory heard is the most recent alarm sector triggered. Turn the ignition on and off to exit this mode. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
-
Page 20: Turbo Timer Run Time
When this feature is ON the button needs to be held for 3 seconds to Description: activate panic instead of being instant. Pressing the button again once will disarm panic mode. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... - Page 21 AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
-
Page 22: Map Feature, 2-Second Entry Delay / Factory Remote Interface
If the alarm is activated the system will shut the engine down and trigger as normal. Description: When in courier mode the glass sensor (AVS A5) will be disabled while the engine is running but will arm normally when the ignition is off. Note AUX input... - Page 23 60 seconds. If turned on dome light extension will be turned off automatically. Installers must wire up the door circuit for this feature to function. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
-
Page 24: Indicator Flash On Alarm Trigger
Factory setting: When this feature is turned ON, the unlock output becomes a 15-second negative Description: pulse instead of 0.5 seconds. This feature is for use with vehicles with vacuum central locking. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... -
Page 25: Turbo Timer Instructions
On-board turbo timer On most vehicles the AVS A-Series can be set up to run the on-board turbo timer by simply connecting the ignition immobiliser wires that would normally be connected to the key side of the cut (IM2A) to +12V main power feed as shown in the diagram below. - Page 26 6. Once the desired time duration is selected simply turn the ignition on then off. The siren should chirp the new run time setting indicating the turbo timer time duration is now set. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
- Page 27 With the onboard turbo timer turned to on (Register 1, Feature 17), the BOOT OUT wire puts out a constant negative when the onboard turbo timer is running so this wire can be used to run an external relay to provide +12V power to the secondary ignition wire. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
-
Page 28: Interface With External Turbo Timers
If the alarm detects an intrusion the alarm will sound and the system will immobilise the engine. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... -
Page 29: Factory Remote Interface (Map Function)
The AVS A-Series can be directly controlled using the vehicle’s existing factory remote control. By hooking up the POS1, POS2, NEG1, NEG2, M1 and M2 wires as per most data sheets (either supplied by AVS or not) or by testing to find the trigger wires, the alarm can be controlled without further programming. The only programming required is to turn on the interface in Register 1, Feature 14 and if you require enable mode, change Register 1, Feature 10 depending on the vehicle, interface uses inhibit mode as default. -
Page 30: Courier Mode
20 times. 5. Turn ignition OFF. Siren will chirp once to confirm feature is now ON. The siren will chirp twice if the feature is turned OFF. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... -
Page 31: Central Door Lock Diagrams
Unlock NC Connect to Lock NC Unlock COM Unlock NO +12V (Fused 10A) Lock NC Connect to Unlock COM Lock COM Connect to motor end of Vacuum control wire Lock NO Earth AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... -
Page 32: Single Wire Cdl System
Unlock COM Unlock NO Earth or +12V (Fused 10A) Lock NC Lock COM Lock NO Earth or +12V (Fused 10A) Vehicle’s Vehicle’s Existing Existing Door Switch Motor Remote Boot Release diagram AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... -
Page 33: Optional Siren Diagrams
1. Learn both alarm remotes into the RXPRO/RCX-4 receiver, (at step 7 of the RXPRO remote learning instructions push the button on the AVS waterproof remotes). Operation: Alarm remote 1 second button push 3/5 second button push button RXPRO Ch 4 Arm/disarm alarm and lock/unlock the doors AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... - Page 34 RXPRO Ch 2 Boot pop or T/T shut off RXPRO Ch 3 Alarm panic AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
-
Page 35: Trouble Shooting Guide
Turn on Register 1, Feature 14. modes In enable mode, nothing happens when I pulse the Make sure POS2 is getting a positive enable signal motor wires when the motor wires pulse or constant. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
