AVS A4
Certification:
Test Report XF2244/R1
•
This product complies with AS/NZS 4601:1999 including amendment 1, 2003
•
AVS A5
Certification:
Test Report XF2106/R2
•
This product complies with AS/NZS 3749.1 2003 Class A. Volumetric Sensing (glass break/shock) must be enabled
•
to comply with a Class A installation (refer Programmable Features).
Class A VSAS (Vehicle security alarm system) includes control equipment including setting and unsetting facilities,
•
all sensors, warning devices and provisions for immobilization of the vehicle and the volumetric sensing device
(glass break/shock)
AVS is a registered trademark of the
AVS A-Series – AVS A4/A5
Installation manual
Generation 2 Version 5
A4 Serials: 4401765 – Current
A5 Serials: 5400757 – Current
Make sure you are using the correct manual
Manta help line 09 476 8052
group of companies
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AVS A Series
Summary of Contents for AVS A Series
- Page 1 Class A VSAS (Vehicle security alarm system) includes control equipment including setting and unsetting facilities, • all sensors, warning devices and provisions for immobilization of the vehicle and the volumetric sensing device (glass break/shock) Manta help line 09 476 8052 AVS is a registered trademark of the group of companies...
-
Page 2: Table Of Contents
Instant boot release / On board turbo timer shut down • Negative on alarm / pager out • Inhibit / enable mode selection for factory remote interface inputs • Installer mode AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... - Page 3 Vacuum CDL system • Single wire CDL system • Flow thru CDL system • Remote boot release diagram Optional siren diagrams 3 extra control channels from AVS remote (requires RXPRO/RCX-4) Trouble shooting guide AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
-
Page 4: Introduction
The polyfuse may take several minutes to reset. Auto-immobilisation: The AVS system will automatically immobilise 38 seconds after the ignition is switched OFF. The LED will light solid to indicate it is in auto immobilise mode. Arm by remote: Press the button on the remote. - Page 5 The panic feature will not work when the ignition is switched on. The panic button can also be programmed to operate instantly when the button is pushed (refer Register 1, Feature 18). AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
-
Page 6: Boot Release Output (150Ma Max)
There are two anti hijack modes to stop thieves that have possesion of the car key and alarm remote from stealing the vehicle. A momentary switch (AVS DS01 is recomended) needs to be pressed within a minute of an anti hijack activation or the alarm will cut fuel to the vehicle and sound the alarm (if programmed). -
Page 7: Additional Features
Intelligent glass break sensor (AVS A5): The AVS A5 includes an intelligent glass break sensor. It will only trigger the alarm when it registers the correct sound frequency parameters for breaking glass and the shock sensor also registers a corresponding vibration/impact to the vehicle (the shock sensor on the A5 is used only for the digital glass break sensor and does not detect shock by itself). -
Page 8: Remote Controls
Wait for the indicators and LED to flash once. (If the alarm is armed you will not be able to see the indicator flash so instead look for the LED flash). Now, repeat for the second PIN digit and wait for the indicators/LED to flash. Repeat until all five digits are entered. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... - Page 9 NOTE: Unless a remote control is learnt in you will need to repeat the procedure every time you wish to start the car. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
-
Page 10: Wiring Instructions
Plug connector (looking at alarm socket with wires facing): If a tag is accidentally cut, or accessories are being added to the AVS A-Series alarm at a later date, it is possible to trace the required wires by first un-clipping the case. Next, slide the circuit board out to expose the main connector plug. -
Page 11: Data Battery Back-Up Siren V2 Wiring
IN wire from the alarm module bundled with the other siren wires in the red and white sheathing. Connect the black wire coming from the siren labeled BONNET to the bonnet pin. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... -
Page 12: Plug Pin # To Connection
AVS data battery back-up siren V2. This output is not compatible with any other AVS siren or any other brand of siren as coded data is transmitted to turn the siren on and off. Do not connect any other siren as it will damage the unit and void the warranty. - Page 13 UNLOCK-NC - Refer to Central Door Lock diagrams for CDL connection. UNLOCK-COM - Refer to Central Door Lock diagrams for CDL connection. Continued overleaf… AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
- Page 14 To meet AS/NZS installation standards, make sure the cut is made more than 300mm from the starter or ignition immobiliser cuts. Must be connected wires) to fuel pump for anti-hijack to function. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
- Page 15 AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
-
Page 16: Changing Programmable Features
Changing programmable features The AVS A-Series programming mode is very quick and easy to use. Follow the steps below to change any of the programmable features: Find the Register (1 or 2) in which the feature is located. Set the vehicle up as described to access the required Register. e.g. to access Register 1 close all doors, bonnet and boot, arm and disarm alarm then turn ignition on, off and back on. - Page 17 When this feature is ON, the –ARM wire changes to become ‘negative on alarm’ Description: instead. Can be used to power pagers or internal sirens. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
-
Page 18: Inhibit / Enable Mode Selection For Factory Remote Interface Inputs
8 chirp, 8 flashes = bonnet / boot trigger If two previous alarms were recorded i.e. voltage drop and shock sensor the LED will flash and the siren will chirp once for voltage drop, then no noise for one AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... - Page 19 LED will flash and the siren chirp three times for shock sensor. The last memory heard is the most recent alarm sector triggered. Turn the ignition on and off to exit this mode. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
-
Page 20: Turbo Timer Run Time
Description: To set up the on-board turbo timer refer to Turbo Timer Instructions. Feature: Delayed panic Press the button this many times: Factory setting: AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... - Page 21 When this feature is ON the button needs to be held for 3 seconds to Description: activate panic instead of being instant. Pressing the button again once will disarm panic mode. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
-
Page 22: Map Feature, 2-Second Entry Delay / Factory Remote Interface
If the alarm is activated the system will shut the engine down and trigger as normal. Description: When in courier mode the glass sensor (AVS A5) will be disabled while the engine is running but will arm normally when the ignition is off. Note AUX input... - Page 23 ON it will re-arm and re-lock the doors if the system is disarmed and a door not Description: opened within 60 seconds. If turned on dome light extension will be turned off automatically. Installers must wire up the door circuit for this feature to function. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
-
Page 24: Indicator Flash On Alarm Trigger
The alarm will also activate for five minutes after the anti hijack trigger (can be turned off via Register 2, Feature 11). AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... -
Page 25: Anti Hijack - Mode 2
When this feature is turned ON, the LED will flash during the countdown to the Description: anti hijack trigger. This is used to inform the driver of the impending trigger and remind them to press the momentary switch. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... -
Page 26: Turbo Timer Instructions
On-board turbo timer On most vehicles the AVS A-Series can be set up to run the on-board turbo timer by simply connecting the ignition immobiliser wires that would normally be connected to the key side of the cut (IM2A) to +12V main power feed as shown in the diagram below. - Page 27 6. Once the desired time duration is selected simply turn the ignition on then off. The siren should chirp the new run time setting indicating the turbo timer time duration is now set. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
- Page 28 With the onboard turbo timer turned to on (Register 1, Feature 17), the BOOT OUT wire puts out a constant negative when the onboard turbo timer is running so this wire can be used to run an external relay to provide +12V power to the secondary ignition wire. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
-
Page 29: Interface With External Turbo Timers
If the alarm detects an intrusion the alarm will sound and the system will immobilise the engine. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... -
Page 30: Factory Remote Interface (Map Function)
The AVS A-Series can be directly controlled using the vehicle’s existing factory remote control. By hooking up the POS1, POS2, NEG1, NEG2, M1 and M2 wires as per most data sheets (either supplied by AVS or not) or by testing to find the trigger wires, the alarm can be controlled without further programming. The only programming required is to turn on the interface in Register 1, Feature 14 and if you require enable mode, change Register 1, Feature 10 depending on the vehicle, interface uses inhibit mode as default. -
Page 31: Anti Hijack Modes
Wiring of the hidden button/switch: The hidden button needs to be a momentary switch such as the AVS DS01 discrete switch that can be accessed by the driver but in a discrete location to increase the security of the anti hijack set up. The switch needs to be normally open with one side going to ground and the other to the AUX wire of the alarm. -
Page 32: Courier Mode
20 times. 5. Turn ignition OFF. Siren will chirp once to confirm feature is now ON. The siren will chirp twice if the feature is turned OFF. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... -
Page 33: Central Door Lock Diagrams
Unlock NC Connect to Lock NC Unlock COM Unlock NO +12V (Fused 10A) Lock NC Connect to Unlock COM Lock COM Connect to motor end of Vacuum control wire Lock NO Earth AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... -
Page 34: Single Wire Cdl System
Unlock COM Unlock NO Earth or +12V (Fused 10A) Lock NC Lock COM Lock NO Earth or +12V (Fused 10A) Vehicle’s Vehicle’s Existing Existing Door Switch Motor Remote Boot Release diagram AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... -
Page 35: Optional Siren Diagrams
1. Learn both alarm remotes into the RXPRO/RCX-4 receiver, (at step 7 of the RXPRO remote learning instructions push the button on the AVS waterproof remotes). Operation: Alarm remote 1 second button push 3/5 second button push button RXPRO Ch 4 AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5... - Page 36 Arm/disarm alarm and lock/unlock the doors RXPRO Ch 2 Boot pop or T/T shut off RXPRO Ch 3 Alarm panic AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
-
Page 37: Trouble Shooting Guide
Turn on Register 1, Feature 14. modes In enable mode, nothing happens when I pulse the Make sure POS2 is getting a positive enable signal motor wires when the motor wires pulse or constant. AVS A-SERIES INSTALLATION MANUAL - GEN 2 VER 5...
