ABSCO SHEDS CYCSKRSK Manual

Skillion shed n3/c1 frame kit for space saver and reverse skillion models
Hide thumbs

Advertisement

Quick Links

Download this manual
AU: 1800 029 701
NZ: 0800 466 444
This kit is applicable to the following sheds:
30152SK
30151SK
23151SK
23151RSK
The addition of this frame kit will increase the
wind rating of the specified sheds to
Wind rating: N3/C1 as per AS4055-2012.
Suitable for specific cyclonic regions
DOWNLOAD
OUR APP FOR
ASSEMBLY
VIDEOS
Absco Industries
Assembly Instruction Manual
SKILLION SHED
N3/C1 FRAME KIT
FOR SPACE SAVER AND
REVERSE SKILLION MODELS
admin@absco.com.au
www.abscosheds.com.au
View of frame kit applied to
Where information conflicts with the original
non-cyclonic
instruction
document is to be referenced.
WARNING: This shed must be anchored to a
100mm thick concrete slab with the concrete
anchors supplied.
Failure to do so will result in the shed not
having the structural integrity required to
endure a severe storms or cyclonic event.
WARNING: Doors must remain closed with
all padbolts properly secured during severe
storms or cyclonic event.
LEAVE A REVIEW
Tell us about your experience and
receive a $20 Coles Gift Card.
Visit www.abscosheds.com.au/review
Model: CYCSKRSK
30152SK
manual,
this
02/03/21
1.1
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the CYCSKRSK and is the answer not in the manual?

Questions and answers

Related Manuals for ABSCO SHEDS CYCSKRSK

Summary of Contents for ABSCO SHEDS CYCSKRSK

  • Page 1 Suitable for specific cyclonic regions storms or cyclonic event. LEAVE A REVIEW DOWNLOAD OUR APP FOR Tell us about your experience and ASSEMBLY receive a $20 Coles Gift Card. VIDEOS Visit www.abscosheds.com.au/review Absco Industries Assembly Instruction Manual Model: CYCSKRSK 02/03/21...
  • Page 2 Sensible shoes are highly recommended. • Do not erect your shed in windy conditions. • It is highly recommended to erect the shed with two or more people. RECOMMENDED Absco Industries Assembly Instruction Manual Model: CYCSKRSK 02/03/21...
  • Page 3 20mm Tab notch + 45mm Lip notch 20mm Tab notch + 45mm Lip notch on both ends 45mm Lip One end: 20mm Tab notch + 45mm Lip notch notch SPECIAL NOTCHING, not noted above. Absco Industries Assembly Instruction Manual Model: CYCSKRSK 02/03/21...

  • Page 4: Fittings And Accessories

    M10 NUT & BOLT PLATE BRACKET (8 PACK) 2 CO + 2 ZINC 3MM DRILL PHILLIPS HEAD FAST038 DRILL DRIVER BIT HEX HD TEK SCREW W/ NEO FAST033 FAST015 DYNABOLT WASHER 10-16x16mm Absco Industries Assembly Instruction Manual Model: CYCSKRSK 02/03/21...
  • Page 5 REVERSE SKILLION MODELS INSTALL EXTRA FASTENERS Absco sheds sheets have punched holes typically spaced at 592mm from centre to centre. To achieve a cyclonic wind rating additional screws will need to be installed to reduce these distances. The fastener intended at these positions is FAST001, a 10mm self tapping screw.
  • Page 6 148mm centres, (every pan) and then fix with a screw. Do this on the front and back walls only. Additional FAST001 for front wall of a double door model. Additional FAST001 for rear wall Absco Industries Assembly Instruction Manual Model: CYCSKRSK 02/03/21...
  • Page 7 - Do not screw any boxed sections until they have been correctly sized as the specific step instructs. - Roof section, door frames and upright door studs are singular pieces. - Use self drilling tek screws for all assembly and installation of these sections. Absco Industries Assembly Instruction Manual Model: CYCSKRSK 02/03/21...
  • Page 8 Start slowly, begin to drill the tek screw into the metal. Once the tek screw has stabilised while drilling increase the speed until the tek screw threads ‘bite’ into the metal. Absco Industries Assembly Instruction Manual Model: CYCSKRSK 02/03/21...
  • Page 9 For 2.3m wide structures the following parts will need to be cut to length. C2950 to 2210mm C2940 to 2000mm If shed is on a rebated slab S1785 will need to be cut-to-suit rebate height. Absco Industries Assembly Instruction Manual Model: CYCSKRSK 02/03/21...
  • Page 10 TIP 2: Take a single piece of wood at 890mm. This will act as a height template to mark the drilling positions when outside the shed to fix the internal bracing. Absco Industries Assembly Instruction Manual Model: CYCSKRSK 02/03/21...
  • Page 11 Now secure to the rear wall with tek screws from outside the shed at 148mm spacings. Corner detail of back wall brace. Bracing installed on the rear wall of a 3.0m shed. Absco Industries Assembly Instruction Manual Model: CYCSKRSK 02/03/21...
  • Page 12 5. Use corner brackets (BKT10) to secure the rear, side and front wall braces together. Position as shown and fix using four tek screws. Pre-drilling the bracket with a 3mm drill bit will make this easier. Absco Industries Assembly Instruction Manual Model: CYCSKRSK 02/03/21...
  • Page 13 S1785 will need to be trimmed to account for downward sloping roof. HEX HD TEK SCREW W/ NEO WASHER 10-16x16mm BKT17 fixed to roof sheet with 9 hex hd tek screws with neoprene washers from outside. Absco Industries Assembly Instruction Manual Model: CYCSKRSK 02/03/21...
  • Page 14 8 tek screws as shown to the right. The roof lip may need to be removed in order Two multipurpose to fit the four tek screws from the outside of the brackets, BKT17, are shed. used per roof brace. Absco Industries Assembly Instruction Manual Model: CYCSKRSK 02/03/21...
  • Page 15 3. Make sure the frame is square and fi x with and level surface and use one tek screw at a second tek screw at each join. each join. 4. Turn frame over and repeat last step. Absco Industries Assembly Instruction Manual Model: CYCSKRSK 02/03/21...
  • Page 16 10. Drill 10mm holes in the jamb above the door (ref image ‘B’) and the channel below the door (ref image ‘C’). These align with the vertical padbolt shafts of double doors. Absco Industries Assembly Instruction Manual Model: CYCSKRSK 02/03/21...

  • Page 17: Anchoring Methods

    Double door openings are required to be BKT17. Fixed by four tek screws. anchored using BKT12. It is fixed to the midpoint of the doorway channel with four tek screws as shown. Absco Industries Assembly Instruction Manual Model: CYCSKRSK 02/03/21...
  • Page 18 FOR SPACE SAVER AND REVERSE SKILLION MODELS ANCHORING LAYOUT Slab dimensions below illustrate the minimum required anchors per wall. Ensure that anchors are evenly spaced along wall. 3100mm for 3.0m wall 2360mm for 2.3m wall Absco Industries Assembly Instruction Manual Model: CYCSKRSK 02/03/21...
  • Page 19 Absco Sheds Storage Guidelines • Absco Sheds are designed to be weatherproof for normal weather conditions. In the event of extreme weather conditions such as heavy rain, combined with high wind gusts, the ridge capping, sheeting joins, screw fi xings etc., may exhibit minor deformations which may allow some water entry. These areas should be checked regularly to ensure that maximum strength and protection is maintained.
  • Page 20 Lifetime Warranty Statement This warranty against defects is given by: Absco Industries (ABN: 77 869 708 678) Address: PO Box 119 Acacia Ridge QLD 4110 Ph: 1800 029 701 Fax: 07 3344 1191 Email: admin@absco.com.au Date of issue: 19 December 2018 Details of Manufacturer’s Warranty This product comes with a Lifetime structural warranty from the date of purchase.
  • Page 21 IMPORTANT 1. Manufacturer’s Disclosure This warranty against defects shall not apply in the following situations: A) Where the product is not assembled in accordance with the instructions provided in the product kit; B) Where the product is used to store corrosive materials such as fertilizer, chlorine etc; C) The warranty does NOT cover damage caused by storms, wind, rain, snow or poor foundations;...
