- Page 1 A l l e g r o P i t I n s t a l l a t i o n G u i d e Category: Residential and Commercial Metering Model number: ALLPU Type: Installation Manual Issue: Operation...
-
Page 2: General Information
Professionally trained personnel should install the equipment. The Allegro Pit Unit is equipped with an internal antenna/transmitter and 1) must be installed at a minimum separation distance of at least 20 cm from all persons, and 2) must not be co-located or operating in CAUTION conjunction with any other antenna or transmitter. - Page 3 The device meets the exemption from the routine evaluation limits in section 2.5 of RSS-102 and compliance with RSS-102 RF exposure, users can obtain Canadian information on RF exposure and compliance. Master Meter, Inc. 101 Regency Pkwy, Mansfield, TX 76063 T: 817-842-8000 F: 817-842-8100 MasterMeter.com...
-
Page 4: Product Specifications
Normal mode Device is associated to a parent, got configuration from 5 seconds fast blinks Command center. (0.5Sec on / 05sec off) Master Meter, Inc. 101 Regency Pkwy, Mansfield, TX 76063 T: 817-842-8000 F: 817-842-8100 MasterMeter.com... - Page 5 Remove threaded locking mechanism Step 3) Pass the cable through the Lid hole and install the Allegro Pit Unit into the Pit lid. If mounting brackets are available beneath the meter pit lid, the unit may alternatively be installed in this manner.
- Page 6 Step 4) Fasten the unit to the meter pit lid using the threaded locking mechanism Step 5) Attach the Allegro Pit Unit to the encoded water meter using the appropriate Nicor or Bare Wire connections Step 6) Activate the Allegro Pit Unit using a magnet or Allegro Activator tool Step 7) Verify Status using the LED Indicators located at the bottom of the unit’s neck...
- Page 7 _____________________________________________________________________________________ Master Meter, Inc. 101 Regency Pkwy, Mansfield, TX 76063 T: 817-842-8000 F: 817-842-8100 MasterMeter.com...
