- Page 1 Installation, use and maintenance manual MINI JOHANNA model stove 48.41.30.130.EN 07-09 Read the instructions carefully before installation and startup...
- Page 2 5.1 The stove does not work 5.2 Difficult lighting 5.3 Smoke leaks 5.4 The glass gets dirty quickly 5.5 Condensate in the combustion chamber 5.6 The oven does not heat 6– ENCLOSURES 6.1 Warranty certificate 6.2 CE marking information Mini Johanna...
-
Page 3: General Information
- The oven/food-warmer must only be used for its intended purpose, i.e. for heating and/or cooking food; any other use is deemed improper and hazardous. The Manufacturer declines any liability for problems, breakage or accidents due to non-compliance with or failure to apply the instructions given above and in the manual. Mini Johanna... - Page 4 1.3 Technical description The MINI JOHANNA solid fuel burning stove is suitable for cooking food on the cast iron hotplate and in the oven, and for heating the home. The stove has been tested with wood logs and meets the requirements of German Standard DIN 18880.
- Page 5 Anello fumi Ø 120mm Diametro max 270mm Fig 1 Mini Johanna dimensions 1.3.1 Fire door (A) The fire door is opened by pulling the handle outwards; use the protective glove supplied with the stove when the handle is hot. There are air inlet slots around the top and bottom edges of the fire door to keep the glass clean.
-
Page 6: Permissible And Non-Permissible Fuels
UNI 10683/98: Standard prescribing the installation requirements for heat generators or appliances also intended for cooking food, such as stoves and heating cookers with natural draught on fume side and forced draught with thermochemical power of <35kW burning natural wood. Mini Johanna... -
Page 7: Transport And Installation
For the end-user: Contact the service centre and/or your dealer to order replacement parts For the dealer: To request any replacement parts contact the Cola s.r.l. service centre and/or send a fax clearly specifying the following: stove model; serial number;... -
Page 8: Connection To The Flue
2.3 Connection to the flue The MINI JOHANNA stove must be connected to the flue by means of the collar on the hotplate, using flue pipes that are readily available on the market. Connection to the flue must be made using strong and stable pipes (recommended min. -
Page 9: Stove Use
Never leave children unsupervised in the vicinity of the stove; there is a very high risk of burns from the hot surfaces. Also: -never use the stove with the fire door open; -do not store firelighters or other easily flammable materials near the stove. -do not move or lift the stove using the handles. Mini Johanna... - Page 10 To reach adequate cooking temperatures, make sure the damper lever is in position “Z” and if necessary increase the primary and secondary air. Clean the oven every time it is used, following the instructions given in the section on cleaning. Mini Johanna...
-
Page 11: Routine Stove Cleaning And Maintenance
Every day, before lighting the fire, remove any unburnt residuals on the grate and the ashes in the ash pan zone. 4.1 Removing the ash The MINI JOHANNA stove has a removable grate which should be cleared of ash, using the poker supplied, every time before loading fuel. -
Page 12: Troubleshooting
The oven does not heat Make sure the oven door is properly closed. Make sure the damper is closed (pos. “Z”) Make sure the fuel burns normally. Make sure there is sufficient flue draught. Make sure the combustion gas ducts are clean. Mini Johanna... -
Page 13: Warranty Certificate
The company reserves the right to make technical or aesthetic modifications to the products at any time without notice. The drawings, measurements, diagrams and any other configurations are given only by way of example. Mini Johanna... -
Page 14: Ce Marking Information
Rear – right/left side - floor Emission of CO to 13% O2 in combustion products 0,380 % Maximum operating pressure Flue gas temperature 225 °C Nominal heat output 6 kW Energy efficiency 76 % Legna in tronchetti Fuel types Wood logs Mini Johanna...
