- Page 1 Installation, use and maintenance manual Continuous burning heating stove model TERMO JOHANNA – TERMO JOHANNA Sx 48.41.35.022.EN 07-09 Read the instructions carefully before installation and startup...
- Page 2 5.2 Difficult lighting 5.3 Smoke leaks 5.4 The glass gets dirty quickly 5.5 Condensate in the heating chamber 5.6 The oven does not heat 5.7 Radiators or heating system inefficient 6– ENCLOSURES 6.1 Warranty certificate 6.2 "CE" marking information Termo JOHANNA...
-
Page 3: General Information
- The oven/food-warmer must only be used for its intended purpose, i.e. for heating and/or cooking food; any other use is deemed improper and hazardous. The Manufacturer declines any liability for problems, breakage or accidents due to non-compliance with or failure to apply the instructions given above and in the manual. Termo JOHANNA... - Page 4 21.5 kW Wood consumption: 8.7 kg/h Efficiency: 73 % Exchanger capacity: 25 litres Max. operating pressure: 2 bar Weight : 250 kg Min. distance rear - sides: 200 mm External dimensions: H x W x D= 880x1070x680 mm (fig.1) Termo JOHANNA...
- Page 5 I- Flue bypass control lever L- Hotplate M- System delivery(1" female) N- Probe pocket connection (1/2" female) O- System return (1" female) P- Chamber drain connection (1/2" female) Q- Rear flue outlet Ø150mm Fig.1a - Termo Johanna stove dimensions Termo JOHANNA...
- Page 6 Fig.1b - Termo Johanna sx stove dimensions Termo JOHANNA...
- Page 7 The cast iron hotplate has concentric rings of max. diameter 320 mm in the fire zone and a rectangular plate for possible insertion of a tank containing water. The rings can be removed using the poker, to inspect the chamber or for inserting cauldrons. Termo JOHANNA...
- Page 8 UNI 10683/98: Standard prescribing the installation requirements for heat generators or appliances also intended for cooking food, such as stoves and heating cookers with natural draught on fume side and forced draught with thermochemical power of <35kW burning natural wood. 1.7 Dataplate Termo JOHANNA...
-
Page 9: Transport And Installation
For the end-user: Contact the service centre and/or your dealer to order replacement parts. For the dealer: To request any replacement parts contact the Cola s.r.l. service centre and/or send a fax clearly specifying the following data: stove model; serial number;... - Page 10 (recommended min. thickness 2-3 mm). 2.3 Connection to the flue The TERMO JOHANNA heating stove must be connected to the flue by means of the collar on the hotplate, using flue pipes that are readily available on the market. Connection to the chimney must be made using sturdy, stable pipes, with a recommended minimum wall thickness of 1.5-2 mm.
-
Page 11: Room Ventilation
(SA) Room temperature probe (ST2) zone temperature probe 2 (37) Shower with mixer 8) Open expansion tank (ST1) delivery temperature probe (STB) Boiler temperature probe (ST2) return temperature probe Fig 2 Example of plumbing system 2.5 Room ventilation Termo JOHANNA... - Page 12 Less than 5 m fig. 3a Chimney cap positioning and distances The chimney outlet must be at least 0.5 m higher than any obstacle within a radius of 10 m. fig. 3b Chimney cap positioning and distances UNI 10683/98 tables Termo JOHANNA...
- Page 13 It is also advisable to install an "antiwind" cap that guarantees fume exhaust even in the presence of strong horizontal winds. Fig 5 Horizontal winds 3– HEATING STOVE USE Termo JOHANNA...
- Page 14 Despite the large capacity of the combustion chamber, it is advisable to only load a max. of 2-3 logs at a time. Overloading does not increase efficiency, but will overheat the stove, damaging it. 3.6 Operation with slow combustion Termo JOHANNA...
-
Page 15: Routine Stove Cleaning And Maintenance
If the stove is not going to be used for a long period, after the above operations and disconnecting from the flue it is advisable cover it with a protective cloth and store in a safe and protected place. 4 – ROUTINE STOVE CLEANING AND MAINTENANCE Termo JOHANNA... - Page 16 4.5 Cleaning the cladding COLA ceramics are handicraft production and therefore may have minor surface imperfections such as tiny spots or slight colour differences. It is advisable to use a soft dry cloth to clean the ceramic surfaces; the use of detergents could highlight any imperfections.
-
Page 17: Troubleshooting
- Make sure the flue is insulated and complies with the applicable standards. - Check the flue draught. - Check the pump startup thermostat or the pump activation temperature setting. 5.6 The oven does not heat Make sure the oven door is properly closed. Termo JOHANNA... - Page 18 The company reserves the right to make technical or aesthetic modifications to the products at any time without notice. The drawings, measurements, diagrams and any other configurations are given only by way of example. Termo JOHANNA...
-
Page 19: "Ce" Marking Information
(rear – right/left side – floor) 0.674% CO emission in fumes Max. permissible water pressure 2 bar : 283°C Flue gas temperature Nominal heat output : 27kW 21.5 hot water production 5.5 output in heating Efficiency 73 % Type of fuel Wood logs Termo JOHANNA...
