- Page 1 Installation, use and maintenance manual TERMO REGINA 4 heating stove 48.41.15.021.EN -04/2007 Read the instructions carefully before installation and startup Termo Regina 4...
- Page 2 5.1 The stove does not work 5.2 Difficult lighting 5.3 Smoke leaks 5.4 The glass gets dirty quickly 5.5 Condensate in the firebox 5.6 Radiators or heating system inefficient 6– ENCLOSURES 6.1 Warranty certificate 6.2 "CE" marking information Termo Regina 4...
-
Page 3: General Information
In case of operation anomalies, relight the stove only after eliminating the cause of the problem. The Manufacturer declines any liability for problems, breakage or accidents due to non- compliance with or failure to apply the instructions given above and in the manual. Termo Regina 4... - Page 4 1.3 Technical description The Termo REGINA 4 is a heating stove with water chamber for heating the home through the water circuit and also by natural convection. The heating stove uses wood and meets the requirements of Standard EN 13240.
- Page 5 0, the air inlet is closed; when the arrow is in position 3, the air inlet is fully open. The secondary air flow control must be set to zero (closed) when combustion is controlled with the thermostat (F). Warning: Wider adjustments can cause overheating and damage to the stove. Termo Regina 4...
- Page 6 UNI 10683/98: Standard prescribing the installation requirements for heat generators or appliances also intended for cooking food, such as stoves and heating cookers with natural draught on fume side and forced draught with thermochemical power of <35kW burning natural wood. Termo Regina 4...
-
Page 7: Transport And Installation
For the end-user: Contact the service centre and/or your dealer to order replacement parts. For the dealer: To request any replacement parts contact the Cola s.r.l. service centre and/or send a fax clearly specifying the following: stove model; serial number;... -
Page 8: Connection To The Flue
(36) Bathtub with taps 6) Return manifold 1” 14) Non-return valve (25) Heating equipment (37) Shower with mixer 7) System-door box 15) Flow switch 8) Open expansion tank (SA) Room temperature probe (ST1) delivery temperature probe (ST2) return temperature probe Termo Regina 4... -
Page 9: Room Ventilation
Distance A Distance B 15° 0.50 m 15° 1.00 m 30° 0.50 m 30° 1.30 m Less than 1.85 m More than 1.85 m 45° 2.00 m 45° 0.50 m 60° 0.50 m 60° 2.60 m Termo Regina 4... -
Page 10: Stove Use
Never leave children unsupervised in the vicinity of the stove; the risk of burns caused by the hot parts is very high. Make sure to carefully observe the following rules: - never use the stove with the door open; - do not store firelighters or easily flammable materials near the stove Termo Regina 4... -
Page 11: Routine Stove Cleaning And Maintenance
Make sure to periodically empty the ash pan, since the accumulation of ash under the grate hinders the flow of combustion air. Otherwise the grate will overheat and may become damaged. Termo Regina 4... -
Page 12: Troubleshooting
4.2 Cladding maintenance Clean the cladding only when the stove is cold COLA ceramics are handicraft production and therefore may have minor surface imperfections such as tiny spots or slight colour differences. It is advisable to use a soft dry cloth to clean the ceramic surfaces; the use of detergents could highlight any imperfections 4.3 Cleaning the glass... - Page 13 The product warranty is cancelled in case of any problem, breakage or accident due to non-compliance with the instructions given in this manual. The company reserves the right to make technical or aesthetic modifications to the products at any time without notice. Termo Regina 4...
-
Page 14: "Ce" Marking Information
325 ° C Flue gas temperature Nominal heat output total 20.5 kW water heating 16.5 kW Nominal heat output room heating 4.0 kW Efficiency : 70 % Efficiency Type of fuel Wood logs Type of fuel Wood logs Termo Regina 4...
