Summary of Contents for Cola Marlene 3
- Page 1 Installation, use and maintenance manual Wood-burning stove model MARLENE 3 48.41.30.160.GB -07/09 Read the instructions carefully before installation and startup Marlene 3...
-
Page 2: Table Of Contents
5.20 The glass gets dirty quickly ......................13 5.21 Condensate in the heating chamber .....................13 5.22 The oven does not heat........................13 5.23 The electric fan oven does not work .....................13 5.24 The gas hob does not work ......................13 ENCLOSURES………………………………………………………………………………………………….13 6.1 Warranty certificate…………………………………………………………………………………………13 Marlene 3... -
Page 3: General Information
- The oven/food-warmer must only be used for its intended purpose, i.e. for heating and/or cooking food; any other use is deemed improper and hazardous The Manufacturer declines any liability for problems, breakage or accidents caused by failure to follow or apply the instructions contained in this manual Marlene 3... -
Page 4: Technical Description
Wood-fired oven HxWxD 267X341X476 Electrical power supply 230V 50Hz Volume 45Litres Fan oven Max. absorption 2500W 230VAC, 50Hz, 600W ILVE hob H x W x D = 1204 x710 x 710 mm (fig. 1) Dimensions (mm) 305 kg Weight Marlene 3... - Page 5 By turning the lever to position A, the combustion gases flow over the oven and under the cast iron hotplate directly towards the outlet collar. Position “A” is advisable when lighting the stove and during summer. Position “Z" must be used for oven cooking. Marlene 3...
-
Page 6: Permissible And Non-Permissible Fuels
Make sure all electrical connections are disconnected and that the stove is cold before carrying out any operation. • Only use original replacement parts. 1.10 Stove decommissioning For disposal, the stove must be sealed inside strong packing; contact your local authority for information on how to proceed in accordance with the current local regulations. Marlene 3... -
Page 7: Transport And Installation
The hob must not be connected to the gas by means of a rubber hose fixed to the hose connector, as it is not inspectionable. • After connecting the gas supply, check for leaks. Use soapy water or a similar liquid. • Do not use a flame to look for gas leaks. Marlene 3... -
Page 8: Advice On Flues And Connections
If there are other stoves in the same house, each must have its own flue. It is inadvisable to make holes in the flue for connecting other appliances, as this could impair the draught. Marlene 3... -
Page 9: Stove Use
When the stove is hot, adjust the primary air and secondary air as described in the following paragraph and close the bypass damper by moving the lever to position Z. • Never use petrol, alcohol or other flammable liquids to light the fire. Marlene 3... -
Page 10: Adjusting The Combustion Air
Clean the oven every time it is used, following the instructions given in the section on cleaning. 3.9 Multifunction oven operation To access the multifunction oven controls remove the door H (fig.1) 1-Multifunction knob /On switch ► 2-Power On indicator (green) ► 3-Heating elements On indicator (orange) ► 4-Temperature adjustment knob ► Multifunction knob Marlene 3... -
Page 11: Temperature Knob
If the stove is not going to be used for a long period, after the above operations and disconnecting from the flue it is advisable cover it with a protective cloth and store in a safe and protected place. Marlene 3... -
Page 12: Routine Stove Cleaning And Maintenance
4 screws fixing the oven door frame, after removing the door and frame, undo the blind nut located in the middle of the oven at the back, then remove the oven and carry out cleaning, removing the residuals of soot. Marlene 3... -
Page 13: Troubleshooting
Check correct operation of the controls, consulting the specific enclosed ILVE manual. If the oven still does not work correctly, switch it off, disconnect the gas supply by closing the main cock and contact the ILVE service centre. Marlene 3... -
Page 14: Enclosures
The company reserves the right to make technical or aesthetic modifications to the products at any time without notice. The drawings, measurements, diagrams and any other configurations are given only by way of example. Marlene 3...
