- Page 1 T16IZ Ver.2 GYA553 Setting manual 1M23Z07703...
- Page 2 By installing the latest software (Ver. 2 ~) on the T16IZ, you can setting the airplane gyro GYA553 on the T16IZ. Connection T16IZ and GYA553 Connection T16IZ and GYA553 T16IZ S.I/F CGY 接続コード（ジャイロに付属） Reciver Connection Cable (included with gyro) GYA553 CAUTION Be sure to connect and disconnect the GYA553 and T16IZ connection cable with the power off.
- Page 3 SETTING 1. Select “Gyro setting” on the last page of Airplane Model Menu * At this time, if Gyro is not connected to T16IZ by wire, this screen appears. When "GY Settings Transfer" is selected, the gyro setting data saved in T16IZ is written to the gyro. 2. Select "Start" Tap "Yes" to display the GYA533 data saved in T16IZ. Select "Start" This will download the gyro data to the T16IZ. To Basic menu 3. Home screen is displayed ◆ When copying data from Gyro A to Gyro B Connect the gyro A to the T16IZ and press [Start]. (Enter the data of A into T16IZ) If you press Start here, the B data will be download to the T16IZ and the A data will be lost. Connect Gyro B to T16IZ and press [GY Settings Transfer]. (Put data on A into gyro B)
-
Page 4: Home Screen
Home screen Home screen On the home screen, basic information such as gyro operation mode, sensitivity, battery voltage are displayed. Battery voltage Displays the voltage of the receiver battery connected to GYA. Gyro operation mode / Gyro gain Displays "AVCS" or "Normal" opera- tion mode and gyro gain of aileron (roll), elevator (pitch) and rudder (yaw) axis. - Page 5 Config Config Config 1/6 Gyro set mounting direction Set the mounting direction of GYA. Set mounting Config 1/6 WING/TAIL Set with the wing type/tail type of GYA553. The wing type/tail type of the transmitter is not used and is normal. Select wing type Select tail type...
- Page 6 Config Config Config 1/6 Servo type Select the servo type according to the servo to be used. Digital servo → DG : 285 Hz Analog servo → AN : 70 Hz action. Digital servo Analog servo Config 1/6 SB/R2 OUT Rudder 2 S.BUS S.BUS devices can be connected to this When using two rudder servos port. Program box S.BUS 2 MODE LED DATA LED MODE SW DATA SW Aileron 1 S.BUS/Rudder 2 Aileron 2 Rudder Elevator 2 Elevator Head direction mark...
- Page 7 Config Config Config 2/6 Gyro direction For dual aileron, dual elevator, and dual rudder aircraft, check the operating direction of each second aile ron/elevator/rudder. Tilt the airplane to the left on the ground and check that the ailerons operate to the right. Turn the airplane to the right on the ground and check that the rudder operates to the left. Raise the airplane with its nose upward and check that the elevator operates downward. Config 3/6 Neutral offset Neutral position setting for each servo. This will move the neutral to the desired position.
- Page 8 Config Config Config 4/6 5/6 Servo limit This is the limit setting for each servo. The position Aileron example Maximum angle Stick to full right Adjust the value (%) to reach the maximum operating position Maximum angle Stick to full left Adjust the value (%) to reach the maximum operating position Config 6/6 Reset...
- Page 9 SBUS Basic menu SBUS Basic menu The channel of each function can be changed. Reset each S.BUS function. It returns to the initial value. ON-OFF channel for auto recovery. ! 10 CH ON WARNING Always verify that the S.BUS function assignments match your transmitter’s function (in the FUNCTION menu) assignments. If any changes are made within the transmitter function assignments, then it will also be necessary to make the changes within the S.BUS function assignments.
