  • Page 1 GP-MELSEC-Q (RS232) Technical Support Manual © Copyright Reserved Autonics Co., Ltd.
  • Page 2 © Copyright Reserved Autonics Co., Ltd.
  • Page 3: Preface

    Preface Preface Thank you very much for selecting Autonics products. Please familiarize yourself with the information contained in the Safety Precautions section before using this product. This user manual contains information about the product and its proper use, and should be kept in a place where it will be easy to access.
  • Page 4: Technical Support Manual Guide

    (www.autonics.com) to download a copy.  The manual's content may vary depending on changes to the product's software and other unforeseen developments within Autonics, and is subject to change without prior notice. Upgrade notice is provided through our homepage. ...
  • Page 5: Technical Support Manual Symbols

    Failure to follow instructions can result in serious injury or death. Failure to follow instructions can lead to a minor injury or product damage. An example of the concerned feature's use. Annotation mark. ※1 © Copyright Reserved Autonics Co., Ltd.
  • Page 6: Safety Precautions

    This product uses lithium battery, do not disassemble or burn up. Failure to follow this instruction may result in explosion or fire.  Wire properly after checking power terminal polarity. Failure to follow this instruction may result in fire or product malfunction © Copyright Reserved Autonics Co., Ltd.
  • Page 7 © Copyright Reserved Autonics Co., Ltd.
  • Page 8 Safety Precautions  Note that this device is KCC certified for commercial use. Make proper applications for the product. © Copyright Reserved Autonics Co., Ltd.
  • Page 9: Table Of Contents

    Numeral input ..................... 26 3.4.3 Touch key (Up key) ..................27 3.4.4 Touch key (Down key)) ................28 3.4.5 Lamp ......................29 3.4.6 Touch key (Reset key) ................30 Appendix ....................31 Serial setting ...................... 31 © Copyright Reserved Autonics Co., Ltd.
  • Page 10 Table of Contents © Copyright Reserved Autonics Co., Ltd.
  • Page 11: System

    — GP-S070 Firmware V1.20 Release : 2016.01.26 Ms Windows Windows 7 — GX works2 V1.77F — Connections GP-S070-T9D6 CPU : Q02HCPU, Communication card : QJ71C24N Communication cable connection and dimensions (communication cable model: C3M5P05-D9F0-D9M0) © Copyright Reserved Autonics Co., Ltd.
  • Page 12 1 System © Copyright Reserved Autonics Co., Ltd.
  • Page 13: Gp-S070 Communication Setting

    2nd At GP/PLC Type dialog box, set GP/LP Type and CH1/2 Group/Type. Item Setting GP / LP Type GP-S070 T9D6 MITSUBISHI Q SERIES / CH1 Group / Type QhighP_EXT_MC CH2 Group / Type No Use © Copyright Reserved Autonics Co., Ltd.
  • Page 14 2 GP-S070 Communication Setting 3rd At Project Auxiliary Property dialog box, click ‘OK’ and it changes screen to draw. © Copyright Reserved Autonics Co., Ltd.
  • Page 15: Gp-S070 Setting

    2 GP-S070 Communication Setting GP-S070 Setting 1st Touch top-left of the GP. 2nd Touch ‘Environment’. 3rd Touch ‘Serial Communication’. © Copyright Reserved Autonics Co., Ltd.
  • Page 16 5th Touch right ‘SET’ and set as below. Item Setting Note Baud rate 115200 User setting Flow control XON/XOFF Don’t care Parity bit Fixed Data bit 8-bit User setting Stop bit 1-bit User setting © Copyright Reserved Autonics Co., Ltd.
  • Page 17: Gx Works2 Setting

    2 GP-S070 Communication Setting GX Works2 Setting 1st Run GX Works2 and select [Project] – [New] on menu. Select project type, PLC series, type, and language. 2nd Select ‘Intelligent Function Module’ and ‘New Module’. © Copyright Reserved Autonics Co., Ltd.
  • Page 18 3rd Set items as below. Item Setting Note Serial Communication / Module Type Modem Interface Module Module Name QJ71C24N Mounted Slot No. Installed slot number 4th Double-click ‘Switch Setting’ and set items as below. © Copyright Reserved Autonics Co., Ltd.
  • Page 19 Sum Check code None Fixed Online Change Enable Don’t care Setting modifications Enable Don’t care Communication rate setting 1152000 bps User setting MC protocol Communication protocol setting Fixed (Format1) Station number setting User setting © Copyright Reserved Autonics Co., Ltd.
  • Page 20 2 GP-S070 Communication Setting 5th Select ‘Connection Destination’ at Navigation tab and double-click ‘Connection1’. 6th Select connection method. Click ‘Connection Test’ and PLC Type displays Q02/Q02H. © Copyright Reserved Autonics Co., Ltd.
  • Page 21 2 GP-S070 Communication Setting 7th Select [Online] – [Write to PLC]. Click ‘Select All’ and ‘Execute’. © Copyright Reserved Autonics Co., Ltd.
  • Page 22 2 GP-S070 Communication Setting © Copyright Reserved Autonics Co., Ltd.
  • Page 23: Examples

    3 Examples Examples GP-S070 Drawing PLC Program © Copyright Reserved Autonics Co., Ltd.
  • Page 24: Gp-S070 - Plc Device Connection

    — ① Numeral input Counter target value — ② Touch key Input (Up) — ③ (momentary) Touch key Input (Down) — ④ (momentary) Lamp Counter output — ⑤ Touch key Reset — ⑥ (momentary) © Copyright Reserved Autonics Co., Ltd.
  • Page 25: Gp Editor Drawing

    3 Examples GP Editor Drawing Numeral display 3.4.1 Select [Draw]–[Numeral Display] at menu. Click ‘Device’ to set the device as below. Items Setting Channel [CH1]QHighP_EXT_MC Station Device © Copyright Reserved Autonics Co., Ltd.
  • Page 26: Numeral Input

    3 Examples Numeral input 3.4.2 Select [Draw]–[Numeral Input] at menu. Click ‘Device’ to set the device as below. Items Setting Channel [CH1]QHighP_EXT_MC Station Device © Copyright Reserved Autonics Co., Ltd.
  • Page 27: Touch Key (Up Key)

    3 Examples Touch key (Up key) 3.4.3 Select [Draw]–[Touch Key]–[Action]–[Bit]. Click ‘Device’ to set the device as below. Items Setting Channel [CH1]QHighP_EXT_MC Station Device Action Momentary © Copyright Reserved Autonics Co., Ltd.
  • Page 28: Touch Key (Down Key))

    3 Examples Touch key (Down key)) 3.4.4 Select [Draw]–[Touch Key]–[Action]–[Bit]. Click ‘Device’ to set the device as below. Items Setting Channel [CH1]QHighP_EXT_MC Station Device Action Momentary © Copyright Reserved Autonics Co., Ltd.
  • Page 29: Lamp

    3 Examples Lamp 3.4.5 Select [Draw]-[Lamp]. Click ‘Device’ to set the device as below. Item Setting Channel [CH1]QHighP_EXT_MC Station Device © Copyright Reserved Autonics Co., Ltd.
  • Page 30: Touch Key (Reset Key)

    3 Examples Touch key (Reset key) 3.4.6 Select [Draw]–[Touch Key]–[Action]–[Bit]. Click ‘Device’ to set the device as below. Item Setting Channel [CH1]QHighP_EXT_MC Station Device Action Momentary © Copyright Reserved Autonics Co., Ltd.
  • Page 31: Appendix

    Setting at Item Setting at GP-S070 GP Editor CH1 comm. setting Avaliable Avaliable CH2 comm. setting Unavailable Avaliable 1st Check the settings; Application of serial port, setup, menu key, configuration at [Common]- [Auxiliary Configuration]-[Project]. © Copyright Reserved Autonics Co., Ltd.
  • Page 32 4 Appendix 2nd At [Serial Port] tab, set CH1 port configuration. 3rd At [Setup] tab, set CH1 port, station settings. For CH2, the left port is automatically alloted. © Copyright Reserved Autonics Co., Ltd.
  • Page 33 4 Appendix © Copyright Reserved Autonics Co., Ltd.
  • Page 34 4 Appendix © Copyright Reserved Autonics Co., Ltd.
