1 Sicherheitshinweise Bitte lesen Sie vor erster Inbetriebnahme die Gebrauchsanweisung genau durch und beachten Sie die Sicherheits- hinweise, um Schäden durch falsche oder unsachgemässe Bedienung sowie unzulässige Umgebungsbedingungen zu vermeiden. Bewahren Sie diese zum späteren Nachschlagen gut auf. Kontrollieren Sie das Gerät nach dem Entfernen der Verpackung auf Beschädigungen. Setzen Sie das Gerät bei Verdacht auf eine Beschädigung nicht in Betrieb und wenden Sie sich an einen Fachmann.
2 Reinigung und Wartung 2.1 Reinigung Vor jeder Reinigung sollte das Gerät abgesteckt werden und abkühlen� Tauschen Sie das Gerät niemals in Wasser oder leeren Flüssigkeiten darüber� Reinigen Sie das Gerät nur mit weichen feuchten Tuch� Für Glasheizungen kann zusätzlich Glasreiniger verwendet werden� Stellen Sie sicher, dass das Gerät vor Inbetriebnahme vollständig trocken ist, wischen Sie die Heizung mit einem trockenen Tuch nach der Reinigung ab�...
3 Installation 1� Markieren Sie mit der mitgelie- ferten Schablone die Position der Löcher Wand� 2� Bohren Sie Lö- cher mit einem 8-mm- Bohrer� 3� Setzen Sie die Dübel in die Lö- cher ein� 4� Schrauben Sie die mitgelieferten Schrauben an die Wand�...
4 Bedienpanel und Display 1� Wochentag 1� AN/AUS-Taste 2� Offenes Fenster-Indikator 2� WLAN Taste 3� Timer Indikator 3� “+” Taste 4� WLAN Indikator 4� “-“ Taste 5� Zeit 5� Timer Taste 6� Temperatur 6� Heizungsstatus-Indikator 7� Modus 5 Bedienung 5.1 Generelle Einführung des Steuerungssystems Die Produkt-Serie verfügt über eine integrierte WIFI-Steuerbox, sodass zur Steuerung der Heizung kein weiteres Thermostat erforderlich ist�...
Page 7
5.2 Offene Fenstererkennung Diese Heizung ist mit einer Funktion zur Erkennung offener Fens- ter ausgestattet� Wenn unser Steuerungssystem feststellt, dass die Raumtemperatur in kurzer Zeit drastisch abnimmt, während sich das Heizgerät im Heizstatus befindet, erkennt es, dass ein Fenster geöffnet ist�...
Page 8
5.6 WIFI Steuerung Scannen Sie den folgenden QR-Code, um die App „Smart Remote King“ herunterzuladen, oder suchen Sie im App Store oder im Google Play Store nach der App „Smart Remote King“, um den Vorgang zum Herunterladen der App zu starten� Öffnen Sie die App und registrieren Sie sich mit Ihrer Telefonnummer oder E-Mail-Adresse�...
WLAN Symbol auf dem Bild- schirm langsam blinkt, und wiederholen Sie den Verbin- dungsvorgang� 6 Eigenschaften Modell Leistung Größe Montage IP Schutz- klasse ECO 500 500 W 600 x 800 Wand IP44 ECO 700 700 W 600 x 1150 Wand IP44...
7 Garantie / Entsorgung / Technische Änderung Garantie Die Geräte werden vor der Auslieferung genau kontrolliert� Sollte trotzdem einmal ein Mangel an Ihrem Gerät auftreten, wenden Sie sich vertrauensvoll an Ihren Verkäufer� Bitte bringen Sie den Kaufbeleg mit, denn dieser ist für jede Garantie- leistung vorzulegen�...
Page 11
ENTSORGUNGSHINWEISE FÜR DEN ELEKTRISCHEN TEIL DES PRODUKTS Gemäss Artikel 26 des Gesetzesvertretenden Dekrets vom 14. März 2014 zur Umset- zung der Richtlinie 2012/19/EG und des Gesetzes vom 4. März 2014 zur Umsetzung der Richtlinie 2011/65/EG zur Verringerung der Verwendung gefährlicher Stoffe in Elektro- und Elektronikgeräten und zur Abfallentsorgung.
1 Consignes de sécurité Avant la première mise en service, veuillez lire scrupuleusement le mode d‘emploi dans son Intégralité et tenir compte des consignes de sécurité afin d‘éviter les dommages liés à une commande mauvaise ou non conforme ainsi qu‘à des conditions d‘environnement non autorisées. Conservez ce mode d‘emploi afin de pouvoir le consulter de nouveau ultérieurement.
2 Nettoyage et Usage 2.1 Nettoyage Veillez à toujours débrancher le radiateur et à le laisser refroidir com- plètement avant de procéder au nettoyage� Ne jamais immerger dans l‘eau, ni asperger d‘eau� Utilisez un chiffon doux et humide pour net- toyer le radiateur�...
3 Assemblage 1� Utilisez le ga- barit fourni pour marquer l‘empla- cement des trous sur le mur� 2� Percez les trous avec une mèche de 8 millimètres� 3� Insérez les che- villes dans trous� 4� Insérez les vis fournies dans le mur�...
4 Panneau de commande et affichage 1� Jour de la semaine 1� Bouton « marche/arrêt » 2� Ouvrir la fenêtre Indicateur 2� Bouton de WIFI 3� Indicateur de minuterie 3� Bouton « + » 4� Indicateur WLAN 4� Bouton « - » 5�...
Page 19
5.2 Détection de fenêtres ouvertes Ce radiateur est équipé d‘une fonction de détection des fenêtres ouver- tes� Si le système de commande perçoit une baisse de la température de trois degrés en quinze minutes alors que le radiateur est en mode chauffage, il détecte qu‘une fenêtre est ouverte�...
Page 20
5.6 Fonctionnement du WIFI Scannez le code QR ci-dessous pour télécharger l‘application « Smartlife » ou cherchez l‘application « Smartlife » sur l‘App Store ou Google Play Store pour l’installer sur votre smartphone� Ouvrez l‘ap- plication et inscrivez-vous avec votre numéro de téléphone ou votre adresse email�...
6 Propriétés Modelle Puis- Dimensi- Montage Indice de sance protection ECO 500 500 W 600 x 800 IP44 ECO 700 700 W 600 x 1150 Mur IP44 ELEGANCE 500 500 W 600 x 850...
7 Garantie / élimination / modifications techniques Garantie L‘appareil sont contrôlés de manière précise avant la livraison. Si malgré tout un vice devait être constaté sur votre appareil, adressez-vous en toute confiance à notre revendeur. Veuillez join- dre la preuve d‘achat, car celle-ci doit être présentée pour la prestation de garantie. La période de garantie est de 24 mois à...
Page 23
INSTRUCTIONS D‘ÉLIMINATION DE LA PARTIE ÉLECTRIQUE DU PRODUIT Conformément à l‘article 26 du décret-loi du 14 mars 2014 portant application de la directive 2012/19/CE et de la loi du 4 mars 2014 portant application de la directi- ve 2011/65/CE concernant la réduction de l‘utilisation de substances dangereuses dans les équipements électriques et électroniques et la gestion des déchets.
Page 25
ECO 500-700 ELEGANCE 500-700 PANNELLI DI RISCALDAMENTO A INFRAROSSI Manuale di istruzioni N. Articolo: ECO 500: 21221002 ECO 700: 21221102 ELEGANCE 500: 21222002 ELEGANCE 700: 21222102...
Page 26
INDEX 1 Avvertenze di sicurezza ���������������������������������������������������������������������������������������� 27 2 Pulizia e manutenzione�����������������������������������������������������������������������������������������28 3 L‘installazione ������������������������������������������������������������������������������������������������������29 4 Pannello di controllo e display�����������������������������������������������������������������������������30 5 Funzionamento �����������������������������������������������������������������������������������������������������30 6 Dati tecnici ����������������������������������������������������������������������������������������������������������� 33 7 Garanzia / Smaltimento /Modifiche tecnche ���������������������������������������������������������34...
Page 27
1 Avvertenze di sicurezza Prima di mettere in funzione per la prima volta la stufa, si raccomanda di leggere con cura le istruzioni d’uso e di rispettare le avvertenze di sicurezza al fine di evitare un utilizzo improprio o sbagliato come pure condizioni ambi- entali non idonee.
Page 28
2 Pulizia e manutenzione 2.1 Pulizia Disconnettere sempre il radiatore e lasciarlo raffreddare completa- mente prima della pulizia� Non immergere in acqua e non schizzare acqua su di esso� Pulire il radiatore con un panno umido e morbido� Per i modelli in vetro usare un panno morbido e un detergente per vetro�...
Page 29
3 L‘installazione 1� Usare il mo- dello in dotazione per contrassegna- re la posizione dei fori sulla parete� 2� Praticare dei fori usando un trapano da 8 mm� 3� Inserire le spine nei fori� 4� Avvitare le viti in dotazione alla parete�...
Page 30
4 Pannello di controllo e display 1� Giorno della settimana 1� Pulsante di alimentazione 2� Aprire simbolo finestra 2� Pulsante WIFI 3� Simbolo timer 3� Pulsante “+” 4� Simbolo WIIF 4� Pulsante “-” 5� Ora 5� Pulsante timer 6� Temperatura 6�...
Page 31
5.2 Aprire rilevamento finestra Questo radiatore è dotato di una funzione di rilevamento a finestra aperta� Se il nostro sistema di controllo rileva che la temperatura de- lla stanza si è abbassata di 3 gradi entro 15 minuti quando il radiatore è...
Page 32
5.6 Funzionamento WIFI Scansionare il codice QR seguente per scaricare l‘app „Smart Remote King“ o cerca l‘app „Smart Remote King“ sull‘app store o Google Play store per avviare la procedura di download dell‘app, aprire l‘app e registrare il proprio numero di telefono o indirizzo e-mail� 1�Attivare l‘interruttore di alimen- tazione, premere il pulsante „Ali- mentazione“, il simbolo WIFI inizia...
Page 33
WIFI sullo schermo lampeg- gia lentamente e ripetere il processo di connessione� 6 Dati tecnici Modella Potenza Dimensi- Montag- Classe di protezione ECO 500 500 W 600 x 800 Parete IP44 ECO 700 700 W 600 x 1150 Parete IP44...
Page 34
7 Garanzia / Smaltimento /Modifiche tecnche Garanzia I prodotti vengono controllati attentamente prima della spedizione. Se dovesse comunque pre- sentarsi un vizio sul vostro apparecchio, vi invitiamo a rivolgervi in tutta tranquillità al vostro rivenditore. Vi rammentiamo di portare appresso la ricevuta d’acquisto, che deve essere presen- tata per ogni prestazione in garanzia.
Page 35
INFORMATIVA SMALTIMENTO RELATIVA ALLA PARTE ELETTRICA DEL PRODOTTO Ai sensi del D.L. 14 marzo 2014 art. 26, di attuazione della direttiva 2012/19/EU e del D.L. 27 del 4 marzo 2014, di attuazione della direttiva 2011/65/EU relativa alla riduzione dell‘uso di sostanze pericolose nelle apparecchiature elettriche ed elett- roniche, nonché...
Page 38
INDEX 1 Safety instructions �����������������������������������������������������������������������������������������������39 2 Cleaning and Maintenance �����������������������������������������������������������������������������������40 3 Installation ����������������������������������������������������������������������������������������������������������� 41 4 Controlpanel and Display ������������������������������������������������������������������������������������� 42 5 Operation ������������������������������������������������������������������������������������������������������������� 42 6 Technical data ������������������������������������������������������������������������������������������������������45 7 Warranty / Disposal / Technical change ���������������������������������������������������������������46...
Page 39
1 Safety instructions Please read before first commissioning the safety instructions carefully and observe the safety instructions to pre- vent damage due to misuse, improper operation, and improper environmental conditions to be avoided. Keep these for later reference. Check the device after removing the packaging for damage. Do not put the unit in case of suspected corruption in operation and consult a specialist.
Page 40
2 Cleaning and Maintenance 2.1 Cleaning Always unplug your heater and let it cool down completely before cle- aning� Never dip into water and never splash water on it� Clean the heater with a soft damp cloth� For glass models use a soft cloth and glass cleaner�...
Page 41
3 Installation 1� Use the sup- plied template to mark the position of the holes on the wall� 2� Drill holes using a 8mm drill� 3� Insert the do- wels into the ho- les� 4� Screw in the supplied screws to the wall�...
Page 42
4 Controlpanel and Display 1� Weekday 1� Power button 2� Open window Sign 2� WIFI button 3� Timer Sign 3� “+” button 4� WIFI Sign 4� “-“ button 5� Time 5� Timer button 6� Temperature 6� Heating status indicator 7� Modes 5 Operation 5.1 General introduction of the control system The product range has an integrated WIFI control box, meaning there is no...
Page 43
5.2 Open window detection This heater is equipped with an open window detection function� If our control system detects that the room temperature has decreased 3 degrees within 15 minutes when the heater is on the heating status, it will recognize that the window is open� The window sign on the screen will start to flash and the heater will power off for 30 minutes and get back to the previous setting automatically after 30 minutes�...
Page 44
5.6 WIFI Operation Scan the QR code below to download the “Smart Remote King” APP or search “Smart Remote King” APP on APP store or Google play store to start the procedure to download the APP, open the APP and register with your phone number or Email address�...
Page 45
6 Technical data Model Power Size Moun- IP Protecti- ting on Class ECO 500 500 W 600 x 800 Wall IP44 ECO 700 700 W 600 x 1150 Wall IP44 ELEGANCE 500 500 W 600 x 850...
Page 46
7 Warranty / Disposal / Technical change Warranty The Products are controlled just before delivery. If despite a lack of your product, try trustfully your seller. Please bring your receipt, as this is to be submitted for each warranty. The guaran- tee period is 24 months from date of purchase.
Page 47
DISPOSAL INSTRUCTIONS FOR THE ELECTRICAL PART OF THE PRODUCT In accordance with Article 26 of the Decree-Law of 14 March 2014 implementing Di- rective 2012/19/EC and the Law of 4 March 2014 implementing Directive 2011/65/ EC on the reduction of the use of hazardous substances in electrical and electronic equipment and on waste management.
